± BODY ELECTRICALTHEFT DETERRENT SYSTEM
2451 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. INSPECT THEFT DETERRENT INDICATOR LIGHT OP-
ERATION
Connect the positive (+) lead from the battery terminal 2 and
negative (±) lead to terminal 5, and check that the warning light
lights up.
If operation is not as specified, replace the light control rheostat.
2. INSPECT THEFT DETERRENT INDICATOR LIGHT
CIRCUIT
(See page DI±808)
3. INSPECT THEFT DETERRENT HORN OPERATION
Connect the positive (+) lead from the battery to the terminal 1
and negative (±) lead to theft deterrent horn body, and check
that the theft deterrent horn blows.
If operation is not as specified, replace the horn.
4. INSPECT THEFT DETERRENT HORN CIRCUIT
(See page DI±804)
5. INSPECT LUGGAGE COMPARTMENT DOOR KEY
LOCK AND UNLOCK SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
Not turned±No continuity
UNLOCK1 ± 2Continuity
If continuity is not as specified, replace the switch.
6. INSPECT LUGGAGE COMPARTMENT DOOR KEY
LOCK AND UNLOCK SWITCH CIRCUIT
(See page DI±794)
7. INSPECT ENGINE HOOD COURTESY SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
LOCK±No continuity
UNLOCK1 ± 2Continuity
If continuity is not as specified, replace the switch.
8. INSPECT ENGINE HOOD COURTESY SWITCH CIR-
CUIT
(See page DI±790)

BE0GN±01
BE±152
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2453 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
PRE±CHECK
Make the vehicle in the initialized condition:
The initialized condition is the condition when the following conditions are satisfied.
(1) Key plate has not been inserted in the ignition key cylinder.
(2) All the doors are closed. (Door warning light is OFF.)
(3) All the doors are locked.
(4) Wireless door lock control switch (Buzzer switch) is ON.
Under the standard operation, when repeating UNLOCK and LOCK switch 3 times or more alternately, check the
UNLOCK±LOCK operation from 3rd time onward.

Following procedures are standard operation.
(1) Keep about 1 M away to the right direction from the outside handle of a driver's seat.
(2) Face the transmitter toward the vehicle and press one of transmitter switches for about 1 sec.


As of the security function, even the wireless function is normal, there may be the case that only UNLOCK opera-
tion will not work.

As of the body customize function, if ºoperation twiceº has been set using LEXUS hand±held tester, only driver's
seat is unlocked by unlock operation performed once.
Normal


Operative distance may differ according to
an operator, the way of holding the transmitter
or position.

Because weak electric wave is used, when
there is strong wave or noise in the used
frequency ,operation distance might be
shortened.
No Yes
Only wireless function (Remote control) will not operate.
(If a new transmitter or a transmitter of the same type that works properly with the vehicle is not available.)
Check when pressing UNLOCK switch
and LOCK switch under standard
operation, that the transmitter LED
lights up once more.
NoYe s
Basic function check:
Transmitter LED inspection:

BE0G0±05
1
CLOCK WILL NOT OPERATEPASSENGER SEAT BELT WARNING LIGHT DOES NOT OPERATE
I04264
Wire Harness Side5
4
3
6
1RAD NO.2 Fuse
DOME Fuse
Combination
Meter
Body ECU
No.2
Ground ACC
+B
PBEW
ILL
E Clock Assembly
± BODY ELECTRICALCLOCK
BE±227
2528 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
CLOCK
TROUBLESHOOTING
HINT:
Troubleshoot the clock according to the table below.
TroubleshootingNo.
Passenger seat belt warning light does not light up.1
Clock will not operate1
Clock loses or gains time2
± 1.5 seconds / day
INSPECT CLOCK CIRCUIT
(See page DI±849)
TROUBLESHOOTING NO.1
(a) Check that the battery positive voltage is 10 ± 16 V.
If voltage is not as specified, replace the battery.
(b) Check that the DOME and RAD NO.2 fuses are not
blown.
If the fuse is blown, replace the fuse and check for short.
(c) Troubleshoot the clock as follows.
HINT:
Inspect the connector on the wire harness side.

BE19B±01
± BODY ELECTRICALTROUBLESHOOTING
BE±3
2304 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
Ignition Switch:
SymptomSuspect AreaSee page
Ignition switch is not set to each position.4. Ignition switch
5. Power source circuitBE±31
±
Key Unlock Warning Switch:
SymptomSuspect AreaSee page
Key unlock warning system does not operate.
(The buzzer does not sound when the driver's door is opened with
the ignition OFF and key inserted)1. Key Unlock Warning Switch
2. Door Courtesy Switch
3. Wire HarnessBE±31
BE±60
±
Key unlock warning system does not operate.
(The buzzer sounds when the ignition key is ACC or ON)1. Ignition Switch
2. Wire HarnessBE±31
±
HEADLIGHT AND TAILLIGHT SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
HINT:
To inspect the bulb and light control ECU, replace them with the ones working normally and judge whether
they work normally or not.
SymptomSuspect AreaSee page
ºAutomatic light control systemº does not operate.
1. Automatic Light Control Sensor
2. Light Control Switch
3. Door Courtesy Switch
4. Wire Harness
5. Body No.2 ECUBE±37
BE±37
BE±60
±
DI±820
Auto turn±off system does not operate when the driver's door is
opened.1. Drivers Door Courtesy SwitchBE±60
Auto turn±off system:
Headlight and taillight do not come on.1. Body ECU No.2
2. Wire HarnessDI±820
±
Auto turn±off system:
Headlight and taillight stay on.1. Body ECU No.2
2. Wire HarnessDI±820
±
USA:
SymptomSuspect AreaSee page
Only one headlight comes on.
1. Bulb
2. *Light Control ECU
3. Wire Harness±
±
±
ºLO±Beamº does not light (All).
1. Headlight Control Relay
2. *Light Control ECU
3. Wire HarnessBE±37
±
±
ºLO±Beamº does not light (One side).
1. Bulb
2. H±LP L±LWR Fuse
3. H±LP R±LWR Fuse
4. *Light Control ECU
5. Wire Harness±
BE±21
BE±21
±
±
ºHI±Beamº does not light (All).1. Headlight Dimmer Switch
2. Wire HarnessBE±37
±

BE±6
± BODY ELECTRICALTROUBLESHOOTING
2307 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
HEADLIGHT BEAM LEVEL CONTROL SYSTEM
SymptomSuspect AreaSee page
Beam axis is not controlled. (It is not initialized.)
Headlight Beam Level Control System does not operate.
1. ECU±IG Fuse
2. Headight Beam Level Control Actuator
3. Headlight Beam Level Control ECU
4. Wire Harness SideBE±21
BE±50
BE±50
±
Beam axis is not controlled. (It is initialized.)
Headlight Beam Level Control System does not operate.1. Height Control Sensor
2. Headlight Beam Level Control ECU
3. Wire Harness SideBE±50
BE±50
±
Controlled angle of head light is unusual.
(The angle is controlled.)
1. Height Control Sensor
2. Headlight Beam Level Control ECU
3. Headlights
4. Wire Harness Side±
BE±50
BE±3
±
Beam axis position is not stable during driving.
1. ABS System
2. Headlights
3. Wire HarnessDI±387
BE±3
±
FOG LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Fog light does not light up with light control SW HEAD
(Headlight is normal.)
1. FOG Fuse
2. Fog Light Relay
3. Fog Light Switch
4. Wire Harness
5. Body No.2 ECUBE±21
BE±53
BE±53
±
±
Fog light does not light up with light control SW HEAD
(Headlight does not light).1.*1 Other Parts
2. Wire Harness±
±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
*1: Inspect Headlight System
TURN SIGNAL AND HAZARD WARNING SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. GAUGE Fuse
2. TURN HAZ Fuse
3. Ignitioin Switch
4. Turn Signal Flasher Relay
5. Wire HarnessBE±21
BE±21
BE±31
BE±56
±
Hazard warning light does not light up.
(Turn is normal)1. Hazard Warning Switch
2. Wire HarnessBE±56
±
Turn signal does not light up.
(Hazard is normal)1. Turn Signal Switch
2. Wire HarnessBE±56
±
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE±56
±
Only one bulb does not light up.1. Bulb
2. Wire Harness±
±

± BODY ELECTRICALTROUBLESHOOTING
BE±9
2310 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) Washer fluid does not operate.
Washer Hose and Nozzle±

When wiper switch is in HI position, the wiper blade is in contact
with the body.

When the wiper switch is OFF, the wiper blade does not retract
or the retract position is wrong.
1. Wiper Motor *1
2. Wire harness *1BE±77
±
*1: Inspect wiper arm and blade set positions.
COMBINATION METER
This system uses the multiplex communication system, so check diagnosis system of the multiplex
communication system before you proceed with troubleshooting.
Refer to DI section for warning light or indicator light not described in the table below.
SymptomSuspect AreaSee page
Driver seat belt warning light does not light up.
1. Bulb
2. Driver Buckle Switch CIrcuit
3. Meter Circuit Plate
4. Wire Harness
5. Body No.2 ECU±
BE±92
BE±92
±
DI±820
Passenger seat belt warning light does not light up.
1. Clock System
2. Passenger Buckle Switch CIrcuit
3. Occupant Detection Sensor
4. Meter Circuit Plate
5. Wire Harness
6. Body No.1 ECUBE±227
BE±92
BE±92
BE±92
±
DI±776
SRS warning light does not light up.
1. MPX±B Fuse
2. SRS±B Fuse
3. Bulb
4. Meter Circuit Plate
5. Wire Harness
6. Airbag Sensor AssemblyBE±21
BE±21
±
BE±92
±
DI±550
Hi±beam indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. Headlight System±
BE±92
±
BE±3
Turn indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. Turn Signal and Hazard Warning System±
BE±92
±
BE±3
ABS warning light does not light up.
1. GAUGE Fuse
2. Bulb
3. Meter Circuit Plate
4. Wire Harness
5. ABS, TRAC and VSC ECUBE±21
±
BE±92
±
DI±387
TRAC warning light does not light up.
1. GAUGE Fuse
2. Bulb
3. Meter Circuit Plate
4. Wire Harness
5. ABS, TRAC and VSC ECUBE±21
±
BE±92
±
DI±473

BE±10
± BODY ELECTRICALTROUBLESHOOTING
2311 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) Malfunction indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. ECM (2JZ±GE)
5. ECM (1UZ±FE)±
BE±92
±
DI±1
DI±156
Fuel level warning light does not light up.
1. Bulb
2. Fuel level warning sensor
3. Meter Circuit Plate
4. Wire Harness±
±
BE±92
±
ELECTRIC TENSION REDUCER SYSTEM
SymptomSuspect AreaSee page
Tension Reducer does not operate.
(Driver's and Passenger's)1. ECU±IG Fuse
2. Wire HarnessBE±21
±
Tension Reducer does not operate.
(Only one side)1. Buckle Switch
2. Tension Reducer Solenoid
3. Wire HarnessBE±92
BE±92
±
DEFOGGER SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Rear window defogger does not operate.
1. HTR Fuse
2. DEF M±Fuse
3. Defogger Relay Circuit
4. Defogger Switch (in A/C Panel Switch)
5. Defogger Wire
6. Wire Harness
7. Body No.1 ECUBE±21
BE±21
DI±812
BE±108
BE±108
±
DI±776
Mirror defogger does not operate.
1. MIR±HTR Fuse (Passenger SIde J/B)
2. Mirror Heater Relay
3. Mirror Heater
4. Wire HarnessBE±21
BE±108
BE±108
±
POWER WINDOW CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the power windows do not operate.
(Power Door Lock System is normal.)
1. PWS terminal circuit
2. Power Window Master Switch
3. Wire Harness
4. Driver Door ECU
5. Body No.1 ECUDI±818
BE±117
±
DI±856
DI±776
Only the driver's window does not operate.
1. Power Window Master Switch
2. Power WIndow Switch
3. Power Window Motor
4. Wire HarnessBE±117
BE±117
BE±117
±
ºWindow lock functionº does not operate.1. Power Window Master SwitchBE±117
Window does not operate with power window master switch.
(Manual or Automatic operation can be performed.)TROUBLESHOOTING NO.1BE±111
Remote control of all windows (Except driver's) does not functions
with master switch.
(Windows operate normally with each of master switch.)
TROUBLESHOOTING NO.2BE±111

± BODY ELECTRICALTROUBLESHOOTING
BE±11
2312 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) The Key related power window operations does not operate with
driver side door key cylinder.
(Master switch operation is normal.)
TROUBLESHOOTING NO.3BE±111
Power window does not operate with multi±function transmitter.
(Windows operate normally with master switch.)TROUBLESHOOTING NO.4BE±111
Window moves down without being ordered during the up opara-
tion.TROUBLESHOOTING NO.5BE±111
POWER DOOR LOCK CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the doors cannot be locked or unlocked.
(Power Window Control System is normal.)1. Door Lock Control Switch
2. Wire Harness
3. Body No.1 ECUBE±131
±
DI±776
Only one side door lock control does not operate.
1. Door Lock Motor
2. Wire Harness
3. Each Door ECUBE±131
±
±
Door key related function does not operate.
1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Each Door ECU
4. Body No.1 ECUBE±131
±
±
DI±776
Key confinement prevention function does not operate.
1. Key Unlock Warning Switch
2. Door Courtesy Switch
3. Wire Harness
4. Each Door ECUBE±31
BE±60
±
±
Luggage compartment door opener function does not operate.
1. Luggage Compartment Door Opener Switch
2. Luggage Compartment Door Opener Motor
3. Wire Harness
4. Body No.1 ECUBE±131
BE±131
±
DI±776
THEFT DETERRENT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
The system cannot be set.
1. Indicator Light
2. Key Unlock Warning Switch
3. Door Unlock Detection Switch
4. Engine Hood Courtesy Switch
5. Luggage Compartment Door Courtesy Switch
6. Wire Harness
7. Each Door ECU
8. Body No.1 ECUBE±150
BE±31
BE±131
BE±150
BE±60
±
±
DI±776
The system cannot be canceled when the ignition switch is turned
to ON with key.
1. Key Unlock Warning Switch
2. Ignition Switch
3. RAD NO.2 Fuse
4. Wire Harness
5. Body No.1 ECUBE±31
BE±31
BE±21
±
DI±776
The system cannot be canceled when the luggage compartment
door is unlocked with key.1. Luggage Compartment Door Courtesy Switch
2. Wire Harness
3. Body No.1 ECUBE±60
±
DI±776
The system does not operate when the engine hood is opened.
1. Engine Hood Courtesy Switch
2. Wire Harness
3. Body No.1 ECUBE±150
±
DI±776
