± COOLING (2JZ±GE)RADIATOR
CO±23
1561 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
1. INSTALL ELECTRIC COOLING FAN TO RADIATOR
(a) Install the electric cooling fan with the 6 bolts.
Torque: 5.0 N´m (50 kgf´cm, 44 in.´lbf)
(b) Connect the radiator reservoir hose to the radiator.
2. INSTALL RADIATOR AND ELECTRIC COOLING FAN
ASSEMBLY
(a) Install the 2 lower radiator supports to the radiator.
(b) Attach the 2 lower radiator supports on the radiator to the
body bracket.
(c) Install the radiator and electric cooling fan assembly with
the 2 upper radiator supports and 2 nuts.
Torque: 13.5 N´m (135 kgf´cm, 10 ft´lbf)
(d) Connect these parts:
Upper radiator hose to radiator
Lower radiator hose to radiator
ECM outlet duct to ECM box
Wire for electric cooling fan to clamp on electric
cooling fan
2 electric cooling fan connectors
ECT switch connector for electric cooling fan
2 oil cooler hoses for A/T to radiator
3. INSTALL AIR CLEANER AND MAF METER AS-
SEMBLY
4. INSTALL AIR CLEANER INLET
5. FILL WITH ENGINE COOLANT
6. START ENGINE AND CHECK FOR ENGINE COOLANT
AND A/T FLUID LEAKS
7. INSTALL ENGINE UNDER COVER
Page 480 of 1111

B01900
CO0AD±03
B00922
ECT
Switch
Connector
B02072
B02073
Ammeter
Battery(+)
(±)
CO±24
± COOLING (2JZ±GE)ELECTRIC COOLING FAN
1562 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
ELECTRIC COOLING FAN
ON±VEHICLE INSPECTION
1. CHECK COOLING FAN OPERATION WITH LOW
TEMPERATURE (Below 83°C (181°F))
(a) Turn the ignition switch ON.
(b) Check that the cooling fan stops.
If not, check the cooling fan relay and ECT switch, and check
for a separated connector or severed wire between the cooling
fan relay and ECT switch.
(c) Disconnect the ECT switch connector.
(d) Check that the cooling fan rotates.
If not, check the fuses, radiator fan main relay, cooling fan relay,
cooling fan, and check for a short circuit between the cooling
fan relay and ECT switch.
(e) Reconnect the ECT switch connector.
2. CHECK COOLING FAN OPERATION WITH HIGH
TEMPERATURE (Above 93°C (199°F))
(a) Start the engine, and raise coolant temperature to above
93°C (199°F).
HINT:
Coolant temperature is the detected value by the ECT switch
on the radiator lower tank.
(b) Check that the cooling fan rotates.
If not, replace the ECT switch.
3. INSPECT COOLING FANS
(a) Disconnect the cooling fan connector.
(b) Connect battery and ammeter to the cooling fan connec-
tor.
(c) Check that the cooling fan rotates smoothly, and check
the reading on the ammeter.
Standard amperage: 8.5 ± 11.5 A at 20°C (68°F)
(d) Reconnect the cooling fan connector.
Page 481 of 1111
CO0AE±01
B02030
Electric Cooling
Fan Connector Upper Radiator Hose Air Cleaner Inlet
MAF Meter Connector Air Cleaner and MAF Meter Assembly
Intake Air ResonatorElectric Cooling Fan Assembly
Radiator Reservoir Hose
Wire Clamp ECM Outlet Duct
x 6
EVAP Hose
Engine
Wire Clamp
± COOLING (2JZ±GE)ELECTRIC COOLING FAN
CO±25
1563 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
COMPONENTS
Page 483 of 1111
CO0AF±03
B02071
± COOLING (2JZ±GE)ELECTRIC COOLING FAN
CO±27
1565 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REMOVAL
1. DRAIN ENGINE COOLANT
2. REMOVE AIR CLEANER INLET
3. REMOVE AIR CLEANER AND MAF METER AS-
SEMBLY
4. REMOVE ELECTRIC COOLING FAN
(a) Disconnect the upper radiator hose from the radiator.
(b) Disconnect the ECM outlet duct from the ECM box.
(c) Disconnect the wire for electric cooling fan from the clamp
on the electric cooling fan.
(d) Disconnect the 2 electric cooling fan connector.
(e) Disconnect the radiator reservoir hose from the radiator.
(f) Remove the 6 bolts and electric cooling fan.
Page 486 of 1111
CO09Y±01
A02724
Air Cleaner Inlet
Upper Radiator Support
MAF Meter Connector Air Cleaner and MAF
Meter AssemblyLower Radiator Hose
Radiator
Assembly
ECM Outlet Duct
ECT
Switch
Engine Wire Clamp EVAP Hose
Lower Radiator Support
Intake Air Resonator
PS Pump
Front Bracket
Water Pump Pulley
Drive Belt
Engine Under CoverPS Vane Pump
Oil Cooler Hose
for A/T Electric Cooling
Fan Connector
Upper Radiator
Hose
x 18
58 (590, 43)
52 (530, 38)
N´m (kgf´cm, ft´lbf)
Non±reusable part: Specified torqueWire Clamp
Upper Radiator
Support
± COOLING (2JZ±GE)WATER PUMP
CO±3
1541 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
WATER PUMP
COMPONENTS
Page 487 of 1111
B01985
Water Bypass Outlet
O±Ring
Engine Wire
Water
Pump
Connector Bracket
Idler PulleyGasket
Timing Belt GuideNo.2 Water Bypass Pipe
Drain Hose
Timing Belt Tensioner
Timing Belt
Drive Belt TensionerOil Filler Cap
No.3 Timing Belt Cover
No.1 Water
Bypass Pipe
Gasket
Crankshaft PulleyDust Boot
x 5 Thermostat
O±Ring
O±Ring
No.2 Timing Belt Cover
Gasket
No.1 Timing Belt Cover
Gasket
Water Inlet
x 6
35 (350, 26)
21 (210, 15)
21 (210, 15)
27 (270, 20)
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
Precoated part
330 (3,300, 243)
Clamp Bracket
Crankshaft Position
Sensor Connector
Gasket
CO±4
± COOLING (2JZ±GE)WATER PUMP
1542 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
Page 488 of 1111
CO0AI±03
B02071
CO±30
± COOLING (2JZ±GE)ELECTRIC COOLING FAN
1568 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
1. INSTALL ELECTRIC COOLING FAN
(a) Install the electric cooling fan with the 6 bolts.
Torque: 5.0 N´m (50 kgf´cm, 44 in.´lbf)
(b) Connect the upper radiator hose to the radiator.
(c) Connect the ECM outlet duct to the ECM box.
(d) Connect the wire for electric cooling fan to clamp on the
electric cooling fan.
(e) Connect the 2 electric cooling fan connectors.
(f) Connect the radiator reservoir hose to the radiator.
2. INSTALL AIR CLEANER AND MAF METER AS-
SEMBLY
3. INSTALL AIR CLEANER INLET
4. FILL WITH ENGINE COOLANT
5. START ENGINE AND CHECK FOR COOLANT LEAKS
Page 489 of 1111
B02035
ECT Switch
Connector
ECT
Switch
O±Ring
CO0AJ±01
P05962
Ohmmeter
± COOLING (2JZ±GE)ENGINE COOLANT TEMPERATURE (ECT) SWITCH
CO±31
1569 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
ENGINE COOLANT
TEMPERATURE (ECT) SWITCH
INSPECTION
1. DRAIN ENGINE COOLANT
2. REMOVE ECT SWITCH
(a) Disconnect the connector.
(b) Remove the ECT switch.
(c) Remove the O±ring from the ECT switch.
3. INSPECT ECT SWITCH
(a) Using an ohmmeter, check that there is no continuity be-
tween the terminals when the coolant temperature is
above 93°C (199°F).
If there is continuity, replace the switch.
(b) Using an ohmmeter, check that there is continuity be-
tween the terminals when the coolant temperature is be-
low 83°C (181°F).
If there is no continuity, replace the switch.
4. REINSTALL ECT SWITCH
(a) Install a new O±ring to the ECT switch.
(b) Install the ECT switch.
(c) Connect the connector.
5. REFILL WITH ENGINE COOLANT
6. START ENGINE AND CHECK FOR COOLANT LEAKS
