2000 Citroen C5 Owner's Manual

Downloaded from www.Manualslib.com manuals search engine 206
AXLES
SUSPENSION
STEERING
2.0 HPi 3.0i V6
(Without Auto. gearbox) (With or without Auto. gearbox)
X-SX Exclusive Exclusive
Engine type RLZ XFX
TyreS195/65 R15 H XH1 ENERGY 1.920 m 215/55 R16W-PILOT PRIMACY1.953 m
Circumference
O
195/65 R15 H XH1 ENERGY 1.920 m
WheelT6 JX 15 H2-4.18(A) 6 JX 15-4.18 SYLVESTONE(A)6 JX 15-4.18 MONZA
A6 JX 15 H2-4.18 SYLVESTONE
Pressure Front/ Rear (1)2.3/2.3 2.5/2.3
(Bars) Front/ Rear (2)2.3/2.7 2.5/2.7
TyreS195/65 R15 XH1 ENERGY 1.920 m
215/55 R16W-PILOT PRIMACY 1.953 m
SpareCircumference
O195/65 R15 XH1 ENERGY 1.920 m
WheelT6 JX 15 H2-4.18(A) 6.5 JX 16-4.26 MONZA
wheel
T6 JX 15 H2-4.18
Pressure (Bars)2.7 2.6
ElectronicYes (except spare wheel) - (**)
under-inflation detection
No (*)
WHEELS AND TYRES
Symbols and abbreviations used S = Standard fittingT = Steel wheel.O = Option fittingA= Alloy wheel
(1) = Normal operating pressure(Max. 4 persons and 40 kg in the boot).
(2) = Pressure under load (More than 4 persons and «MAXI» load in the boot).
(*) = Possibility of «space saver»type spare wheel option.(**)= Fitting of tyre «not suitable for chains».

Downloaded from www.Manualslib.com manuals search engine 207
AXLES
SUSPENSION
STEERING
2.0 HDi 2.0 HDi
(Without Auto. gearbox) (With or without Auto. gearbox)
X X-SX Exclusive
Engine type RHY RHZ
TyreS195/65 R15H XH1 ENERGY 1.920 m
Circumference
O195/65 R15H XH1 ENERGY 1.920 m
WheelT6 JX 15 H2-4.18(A)6JX 15-4.18 SYLVESTONE
A6 JX 15 H2-4.18 SYLVESTONE
Pressure Front/ Rear (1)2.3/2.3
(Bars) Front/ Rear (2)2.3/2.3
TyreS195/65 R15H XH1 ENERGY 1.920 m
Sparecircumference
O195/65 R15H XH1 ENERGY 1.920 m
WheelT6 JX 15 H2-4.18
wheel
T6 JX 15 H2-4.18
Pressure (Bars)2.7
Electronic
under-inflation detection
No (*)
WHEELS AND TYRES
Symbols and abbreviations used S = Standard fittingT = Steel wheel.O = Option fittingA= Alloy wheel
(1) = Normal operating pressure(Max. 4 persons and 40 kg in the boot).
(2) = Pressure under load (More than 4 persons and «MAXI» load in the boot).
(*) = Possibility of «space saver»type spare wheel option.

Downloaded from www.Manualslib.com manuals search engine 208
AXLES
SUSPENSION
STEERING
2.2 HDi
(With or without Auto. gearbox)
SX Exclusive
Engine type4HX
TyreS205/65 R15H XH1 ENERGY-1.959m 215/55 R16W PILOT PRIMACY-1.953m
Circumference
O215/55 R16W PILOT PRIMACY-1.953m 205/65 R15H XH1 ENERGY 1.959m
WheelT6.5 JX 15 CH-4.25-IMOLA 6.5 JX 16-4.26-MONZA
A6.5 JX 16-4.26-MONZA 6.5 JX 15 CH-4.25-IMOLA
Pressure Front/ Rear (1)205/65-2.3/2.1 – 215/55-2.5/2.3
(Bars) Front/ Rear (2)205/65-2.3/2.5 – 215/55-2.5/2.3
TyreS205/65 R15H XH1 ENERGY-1.959m 215/55 R16W PILOT PRIMACY-1.953m
Sparecircumference
O215/55 R16W PILOT PRIMACY-1.953m 205/65 R15H XH1 ENERGY-1.959m
WheelT6.5 JX 15 CH-4.25-IMOLA 6.5 JX 16-4.26-MONZA
wheel
T6.5 JX 16-4.26-MONZA 6.5 JX 15 CH-4.25-IMOLA
Pressure (Bars)205/65-2.5 – 215/22-2.6
Electronic Yes (except spare wheel) (O)= (**)
under-inflation detection
WHEELS AND TYRES
Symbols and abbreviations used S = Standard fittingT = Steel wheel.O = Option fittingA= Alloy wheel
(1) = Normal operating pressure (Max. 4 persons and 40 kg in the boot).
(2) = Pressure under load (More than 4 persons and «MAXI» load in the boot).
(**) = Fitting of tyre «not suitable for chains».

Downloaded from www.Manualslib.com manuals search engine 209
WHEELS AND TYRES
Inflation pressures Wheel bolts
The label giving the recommended inflation pressures is affixed to the
front left hand door pillar.
a - Type of tyre.
b -Tyre specifications.
c -Recommended tyre inflation pressures(unladen and laden)
d -Recommended tyre inflation pressures for the spare wheel.(1)Wheel bolt
(For all rim types).
(2) Wheel in light alloy or steel alloy
(3) Spare wheel («Space-saver»type ).
Tightening torque
9 ± 0.5 m.daN.
AXLES
SUSPENSION
STEERINGB2GPOONDB2GPOOJD

Downloaded from www.Manualslib.com manuals search engine 210
AXLES
SUSPENSION
STEERING
WHEELS AND TYRES
Special features.
- The contact faces of the fixing bolts on «steel alloy» wheels are flat.
- Silverstone, Imola,and Monzaalloy wheels can be equipped with an under-inflation detection device.
- «Space-saver» type spare wheels are composed of :
- 4 JX 15 4,0red-coloured rim on which is affixed a label indicating a speed limit of80 km/h (50 mph).
- AMICHELIN 125/90 R15 TEXtyre: pressure 3,5 ± 0,5 Bars.
NOTE : These wheels are available only to replace the 195/65 R15 Htyre fitting.
- For 2,2 HDi (4HX)Exclusive, there is a special option called chain option for non-chainable versions.
- The vehicle therefore has identical 205/65 R 15tyres, four IMOLAtype rims and a steel alloy spare wheel.
- The bolts for fixing SILVERSTONEand IMOLAtype alloy rims have chrome caps.
B2GPOOUC

Downloaded from www.Manualslib.com manuals search engine 211
AXLES
SUSPENSION
STEERING
WHEELS AND TYRES
Special features (continued)
Under-inflation detection device.
- Vehicles equipped with the under-inflation detection system are identifiable by the presence of aluminium
valves.
- The under-inflation detection option is possible only on vehicles equipped with aluminium rims.
Composition :
- Four HFtransmitter modules(4)incorporated in the wheels in place of the valves, each including a lithium
battery with 10 yearsguaranteed life.
- AHF receiver incorporated in the communication module under the steering wheel (COM 2000).
- The tightening torque for the nut (5) is 0.6 ± 0.1 m.daN.
WARNING :
- Each time a tyre is replaced, the valve (6) must be replaced.
- Each time a rim is replaced, the seal (7) must be replaced.
- Each time a valve is replaced, it is necessary to have the transmitter recognised by the BSI, with
the aid of a diagnostic tool.
B2GPOOUC

Downloaded from www.Manualslib.com manuals search engine 212
AXLES
SUSPENSION
STEERING
L1
The dimension«L1» for checking front height is between the level of
the front subframe «b» and the wheel axis «a».
This method eliminates all the variations in measurement due to :
Different wheel fiittings.
Vehicle loading.
Wear or incorrect inflation of tyres.
(Measuring from the wheel axis : tool 8006-T)
AXLE GEOMETRY
General adjustment conditions
Rear height Front height
NOTE : After each movement of the vehicle body, and before each mea-
surement :
- Move the vehicle slightly forwards and backwards, by turning the road
wheel by hand.- Check the tyre pressures.
- Release the handbrake.
- Place the manual height control in the «NORMAL» position.
- Engine running.
L2
The dimension«L2»for checking rear height is between the measuring
zone «b» and the wheel axis «a».
H1 = R1 - L1
H1 = Front height(± 6 mm).
R1 =Wheel radius(mm).
L1 = Theoretical dimension between the level of the front subframe and
the wheel axis.H2 = R2 + L2
H2 = Rear height (± 6 mm).
R2 = Wheel radius(mm).
L2 = Theoretical dimension between the measuring zone on the cross-
member support and the wheel axis.

Downloaded from www.Manualslib.com manuals search engine 213
AXLES
SUSPENSION
STEERING
AXLE GEOMETRY
Measuring front height
The measurement of the front dimension «H1» is between ground level
and the measuring zone on the front subframe
(to the rear of the front yokes fixing the suspension arm).
L1 (mm)
Theoretical dimension between the level of the front subframe and
the wheel axis.
140L1 (mm)
Theoretical dimension between the measuring zone on the cross-
member support and the wheel axis.
140 Measuring rear height
B3BP166DB3BP168D
