2000 Acura RL display

Instrument
s an d Control s

This section gives information about the controls and displays thatcontribute to the daily operation of
your Acura. All the essential controls are within easy reach.
Control Locations............................ 52
Indicator Lights................................ 53
Gauges.............................................. 58
Speedometer................................ 58

Tachometer.................................. 58
Odometer...................................... 59

Trip Meter/Outside Temperature Indicator............ 59
Temperature Gauge.................... 60 Fuel Gauge................................... 60
Maintenance Required Indicator.................................... 61
Controls Near the Steering Wheel........................................ 62

Headlights.................................... 63

Automatic Lighting..................... 64
Daytime Running Lights............. 65

Instrument Panel Brightness..... 66

Turn Signals................................. 66

Fog Lights.................................... 67 Windshield Wipers...................... 68
Windshield Washers................... 70

Hazard Warning........................... 70

Rear Window Defogger.............. 71
Steering Wheel Adjustments..... 71
Steering Wheel Controls ................ 73 Cruise Control.............................. 73
Remote Audio Controls .............. 76
Keys and Locks................................ 77 Keys............................................... 77
Immobilizer System..................... 78
Ignition Switch............................. 80
Power Door Locks....................... 81
Remote Transmitter.................... 82
Childproof Door Locks............... 85

Trunk............................................86
Glove Box..................................... 87

HomeLink Universal Transmitter......... 88
Customer Assistance.................. 88

Important Safety Precautions.... 88

Training the Transmitter............ 89
Training With a Rolling Code System....................................... 91
Erasing Codes.............................. 92

Seat Adjustments............................. 93
Driver's Seat Adjustments.......... 93
Driver's Lumbar Support............ 95

Front Passenger's Seat

Adjustments............................. 95

Head Restraints........................... 95

Armrest............................................. 96
Mirrors.............................................. 98

Adjusting the Power Mirrors..... 98

Driving Position Memory

System......................................... 100

Seat Heaters................................... 102

Ski Sleeve........................................ 103

Power Windows............................. 105

Moonroof........................................ 106

Parking Brake................................ 108

Digital Clock................................... 108
Sunglasses Holder......................... 110
Beverage Holder............................111

Console Compartment.................. 112

Coin Box......................................... 112
Sun Visor......................................... 113
Vanity Mirror................................. 113
Accessory Power Socket.............. 114 Cigarette Lighter........................... 115

Ashtrays.......................................... 116
Ceiling Lights................................. 117
Courtesy Lights............................. 118

Instrument s an d Control s

Indicato
r Light s
Doo r an d Brak e Lam p Monito r
The appropriate light comes on in this display if the trunk or any dooris not closed tightly. If a brake light
does not work, the BRAK E LAM P
indicator comes on when you push
the brake pedal with the ignition switch ON (II).
A burned out brake light is a hazard when drivers behind you cannot tell
you are braking. Have your brakelights repaired right away.
All the lights in the monitor display come on for a few seconds when you
turn the ignition switch ON (II). Tur
n Signa l an d
Hazar d Warnin g
Indicator s
The left or right turn signal light blinks when you signal a lane changeor turn. If the light does not blink or
blinks rapidly, it usually means one of the turn signal bulbs is burned out (see page 248). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signalling.
When you turn on the Hazard
Warning switch, both turn signal lights blink. All turn signals on the outside of the vehicle should flash.
Low Fue l Indicato r
This light comes on as a reminder that you must refuel soon. Hig
h Bea m Indicato r
This light comes on with the high beam headlights. See page 63 for
information on the headlight

controls.

On Canadian models, this indicator
conies on with reduced brightness
when the Daytime Running Lights (DRL) are on (see page 65).
"Daytim e Runnin g
Lights " Indicato r

Canadian models only

This indicator lights when you turn the ignition switch to ON (II) with
the headlight switch off and the
parking brake set. It should go off if
you turn on the headlights or release the parking brake. If it comes on atany other time, it means there is a
problem with the DRL. There may also be a problem with the high

beam headlights.

Instrument s an d Control s
D R L

Gauge
s

Odomete r
The odometer shows the total dis- tance your car has been driven. It
measures miles in U.S. models and
kilometers in Canadian models.
It is illegal under U.S. federal law and Canadian provincial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles or kilometers

indicated.
Tri
p Meter/Outsid e Temperatur e

Indicato r

SELECT

BUTTO N

RESE T

BUTTO N
The trip meter and the outside temperature indicator use the samedisplay. To switch the display
between the trip meter and the outside temperature, press the
Select button. When you turn the
ignition switch to ON (II), what you
last selected is displayed.
Trip Meter

The trip meter shows the number of
miles (U.S.) or kilometers (Canada)driven since you last reset it.
There are two trip meters, Trip A and Trip B. Switch between theseand the outside temperature display
by pressing the Select button
repeatedly. Each trip meter works
independently, so you can keep track
of two different distances.
To reset a trip meter, display it and then press the Reset button until you
hear a beep. Both trip meters will re- set if the car's battery goes dead or
is disconnected.
CONTINUED
Instrument s an d Control s

Gauge
s

Outside Temperature Indicator
This indicator displays the outside temperature in Fahrenheit in U.S.
models, and in Centigrade inCanadian models.
The temperature sensor is located in the front bumper. Therefore, the
temperature reading can be affected
by heat reflection from the road sur-
face, engine heat, and the exhaust
from the surrounding traffic. This can cause the temperature reading
not to be correct when your speed is
under 19 mph (30 km/h).
In certain weather conditions,
temperature readings near freezing (32°F, 0°C) could mean that ice is
forming on the road surface. Temperatur
e Gaug e
This shows the temperature of the engine's coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe driving conditions, such as very hot
weather or a long period of uphill driving, the pointer may rise to near
the upper white mark. If it reaches
the red (Hot) mark, pull safely to the side of the road. Turn to page 280 for
instructions and precautions on checking the engine's cooling

system.
Fue
l Gaug e
This shows how much fuel you have. It is most accurate when the car is on
level ground. It may show slightly more or less than the actual amount
when you are driving on curvy or hilly roads.
The gauge stays at the same fuel level reading after you turn off theignition. When you add fuel, the
gauge slowly changes to the new
reading after you turn the ignitionswitch back ON (II).
Instrument s an d Control s

Control
s Nea r th e Steerin g Whee l

Instrumen t Pane l Brightnes s
The dial on the dashboard to the left of the instrument panel is used to
adjust the brightness of the lights in
the controls and displays. Turn the dial to adjust the brightness. To reduce glare at night, the instru-
ment panel illumination dims when you turn the light switch to or
Turning the instrument panel
brightness control fully to the left, past the detent, will return the instru-
ment panel to its full brightness. Tur
n Signal s
Signal a turn or lane change with this
lever. Push down on the lever to signal a left turn, and up to signal a
right turn. If you push it up or down all the way, the turn signal continues
to blink even when you release the lever. It shuts off automatically as
you complete the turn.
Instrument s an d Control s TUR
N SIGNA L LEVE R
INSTRUMEN
T PANE L
BRIGHTNES S DIA L

Parkin
g Brake , Digita l Cloc k

Parkin g Brak e
To apply the parking brake, depress the pedal fully. To release it, pull therelease lever. The parking brake
light on the instrument panel should
go out when the parking brake is
fully released with the engine running (see page 54). If you try to
drive the car without releasing the
parking brake, the ABS indicator may come on, and the ABS may not
work properly. The VSA system indicator will also come on along
with the ABS indicator (see page

187).

Driving the car with the parking brake applied can damage the rear brakes
and axles.
Digita
l Cloc k

3.5 RL without Navigation System

The digital clock displays the time with the ignition switch ON (II). To see the time with the ignition off,
press and hold the wide button to the right of the clock.
Instrument s an d Control s

RELEAS
E LEVE R
PARKIN G

BRAK E PEDA L
NOTIC
E

Digita
l Cloc k

To set the clock: 1. Turn the ignition switch ON (II) to
display the time.

2. Swing down the front cover of the wide button to the right of the
clock display. You will see HOUR,

MIN., and RESET buttons.
3. Press and hold the HOUR button
until the hour advances to the

desired hour.

4. Press and hold the MIN. button until the numbers advance to the
desired time.
You can use the RESET button to
quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing RESET
button sets the clock back to the
previous hour. If the displayed time is after the half hour, pressing the
RESET button sets the clock for-
ward to the beginning of the next
hour.
For example: 1:06 would RESET to 1:00.
1:52 would RESET to 2:00.

Instrument s an d Control s

HOU
R
MIN.
RESET

Climat
e Control System

3.5 RL without Navigation System

Fully-automati c Operatio n
To put the Automatic Climate Control in fully-automatic mode,
press the AUTO button and set the fan control dial to AUTO, then set
the desired temperature by turning
the temperature control dial. You willsee FULL AUTO in the system's
display. The light above either the or button also goes
on to show you which is selected.
The system automatically selects the proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature from its current level to
the set temperature.
When you set the temperature to its lower limit (60°F/18°C) or its upper
limit (90°F/32°C), the system runs
at full cooling or heating only. It does
not regulate the interior temperature.
When the temperature is set between the lower and upper limits,
the system regulates the interior
temperature to the set value.
In cold weather, the fan will not
come on automatically until the car
has been driven for a short time and
the heater starts to develop warm air. Pressing the OFF button shuts the
climate control system completely
off. Keep the system completely off
only for short periods. To keep stale
air and mustiness from collecting,
you should have the fan running at all times.
Comfor t an d Convenienc e Feature s
TEMPERATUR
E

CONTRO L DIA LFUL
L AUT O

DISPLA Y
FA
N CONTRO L

DIA L

AUT O
BUTTO NOF
F
BUTTO N
