1999 DODGE RAM Ignition system

WARNING: Wait about 2 minutes after disconnecting negative battery
cable before servicing air bag system. System reserve
capacitor maintains air bag system voltage for about 2
minutes after battery is disconnected. Servicing air bag
system before 2 minutes may cause accidental air bag
deployment and possible personal injury.
REMOVAL & INSTALLATION
WARNING: All models are equipped with Air Bag Restraint System (ABRS).
See AIR BAG PRECAUTIONS before working on vehicle. Use
caution when working around steering column (air bag could
deploy).
CAUTION: When battery is disconnected, vehicle computer and memory
systems may lose memory data. Driveability problems may exist
until computer systems have completed a relearn cycle. See
COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION
before disconnecting battery.
HORN PAD & STEERING WHEEL
Removal & Installation
1) Disable air bag system. See AIR BAG DISABLING. Ensure
steering wheel is in straight-ahead position. Remove nuts mounting air
bag module to steering wheel. Remove screws securing cruise control
switch to steering wheel (if equipped).
2) Disconnect wiring connectors. Remove air bag module and
cruise control switch assembly. Pry trim covers from back of steering
wheel and remove horn switch mounting screws. Disconnect horn wires.
Remove horn switch.
3) Remove steering wheel retaining nut. Reference mark
steering wheel and steering shaft. Using puller, remove steering
wheel. To install, reverse removal procedure. Align marks made during
removal. Tighten steering wheel retaining nut to specification.
STEERING COLUMN
Removal & Installation
1) Position front wheels straight ahead. Disconnect and
isolate negative battery cable. On column shift models, remove link
rod from bushing in shift lever. Discard bushing. On all models,
remove steering wheel using Puller (C-3428-B). See HORN PAD & STEERING\
WHEEL.
2) Remove steering column shaft-to-coupler retaining pin.
Push upper coupler shaft down into lower steering coupler. Remove dash
panel column cover. On column shift models, disconnect shift indicator
cable.
3) On all models, remove tilt lever (if equipped). Remove
upper and lower shroud. Remove lower fixed shroud. Disconnect
multifunction switch harness connector. Disconnect harness connectors
from ignition switch, key-in light, horn and cruise control (if
equipped).
4) Loosen upper support bracket nuts and allow column to drop
slightly. Remove upper fixed shroud. Disconnect wiring harness
retainers from column, and move harness to one side. Remove lower dash
panel. Remove lower steering column nuts. Remove column.
CAUTION: DO NOT reuse bushing in shift rod lever once shift rod is
removed. Always install a NEW bushing.
5) To install column, reverse removal procedure. Connect

STE ER IN G C O LU M N S W IT C HES
1999 D odge P ic ku p R 1500
1999 ACCESSORIES & EQUIPMENT
CHRY - Steering Column Switches
Dakota, Durango & Ram Pickup
WARNING: Deactivate air bag system before performing any service
operation involving steering column components. See
appropriate AIR BAG RESTRAINT SYSTEMS article. DO NOT apply
electrical power to any component on steering column without
first disconnecting air bag module. Air bag may deploy. Wait
at least 2 minutes after disconnecting negative battery cable
before servicing air bag system. System reserve capacitor,
integral to ACM, maintains air bag system voltage for about 2
minutes after battery is disconnected. Servicing air bag
system before 2-minute period may cause accidental air bag
deployment and possible personal injury.
DESCRIPTION
Turn signal, hazard flasher, headlight beam selector,
headlight flash-to-pass, windshield wipe, pulse wipe and windshield
wash systems use a common switch assembly (multifunction switch)
mounted within upper steering column housing.
Ignition switch and lock cylinder are incorporated into an
assembly attached to side of steering column. Ignition switch assembly
can be serviced as a separate unit, but requires removal of lock
cylinder.
COMPONENT LOCATIONS
COMPONENT LOCATIONS








\









\









\









\









\









\









\







Component Location
Combination Flasher Relay ........................... Junction Block
Horn ............................... In Right Front Corner Of Engine
Compartment
Horn Relay ............................ In Power Distribution Center
Junction Block ................. Under Left Side Of Instrument Panel
Power Distribution Center ...... In Left Side Of Engine Compartment,
On Left Inner Panel
Relay/Flasher Module ........ Under Right Side Of Instrument Panel,
Behind Glove Box









\









\









\









\









\









\









\







TROUBLE SHOOTING
TURN SIGNAL AND HAZARD FLASHER SYSTEM
Bulbs Burn Out Rapidly
Check charging system. See appropriate GENERATORS &
REGULATORS article in STARTING & CHARGING SYSTEMS.
Hazard Flashers Inoperative
Blown fuse. Faulty hazard flasher. Open circuit in feed wire
to hazard switch. Faulty turn signal/hazard switch. Open or grounded
circuit in wiring to external lights.

relay terminal No. 86 and ground to relay terminal No. 85. Continuity
should exist between terminals No. 30 and 87. Continuity should not
exist between relay terminals No. 87A and 30. If continuity is not as
specified, replace relay. If continuity is as specified, relay is
okay. Go to HORN RELAY CIRCUIT test under SYSTEM TESTS.
Fig. 1: Identifying Horn Relay Terminals
Courtesy of Chrysler Corp.
IGNITION SWITCH
NOTE: For ignition switch circuit identification, see IGNITION
SWITCH CIRCUIT FUNCTIONS table.
Remove ignition switch. See IGNITION SWITCH under REMOVAL &
INSTALLATION. Check continuity between appropriate ignition switch
terminals with switch in specified position. See IGNITION SWITCH
CONTINUITY table. See Fig. 2.
IGNITION SWITCH CONTINUITY









\









\









\









\









\









\









\







Switch Position Continuity Between Terminals
ACC .......................................................... 6 & 7
OFF ............................................................ ( 1)
RUN ............................................ 2 & 7; 4 & 5; 6 & 7
START ............................................. ( 2) 1 & 7; 2 & 7
( 1) - Continuity should not exist between any terminals with key
removed.
( 2) - Continuity should also exist between terminal No. 3 and case

switch connector. See Fig. 4. If continuity does not exist, repair
open Black/Red wire. If continuity exists, go to next step.
3) Check continuity between ground and Black/Red wire at
steering column horn switch connector. If continuity does not exist,
go to next step. If continuity exists, repair short to ground in
Black/Red wire.
4) Continuity between horn switch terminal and ground.
Continuity should exist with horn switch depressed. Continuity should
not exist without horn switch depressed. If continuity is not as
specified, replace horn switch. If continuity is as specified, install
horn relay and go to HORN under COMPONENT TESTS.
TURN SIGNAL & HAZARD WARNING SYSTEMS
1) If bulbs burn out rapidly, check charging system for
overcharging condition. See appropriate GENERATORS & REGULATORS
article in STARTING & CHARGING SYSTEMS. If charging system is okay, go
to next step. If charging system is not okay, repair as necessary.
2) If problem is turn signals failing to cancel after a turn,
inspect multifunction switch or cancelling cam lobes on clockspring
for damage or improper installation. If problem exists, repair as
necessary. If problem does not exist, go to next step.
3) Turn ignition on. Actuate turn signal switch or hazard
warning switch. Observe turn signal indicator light(s) in instrument
cluster. If flash rate is very high, check for a bulb that is not lit
or is dimly lit. Repair circuit or replace bulb as necessary. If turn
signals fail to light, go to next step.
4) Turn ignition off. Check turn signal fuse in junction
block and/or hazard warning fuse in PDC. If fuses are okay, go to next
step. If either fuse is blown, repair short circuit and replace fuse.
5) Check for battery voltage at hazard warning fuse in PDC.
Turn ignition on. Check for battery voltage at turn signal fuse in
junction block. If battery voltage exists, go to next step. If battery
voltage does not exist, repair open circuit to battery or ignition
switch as necessary.
6) Turn ignition off. Disconnect negative battery cable.
Remove combination flasher from junction block and replace with a
known good unit. Connect battery cable and test operation of turn
signal and hazard warning systems. If operation is okay, discard
faulty flasher. If operation is not okay, go to next step.
7) Turn ignition on. Check for battery voltage at combination
flasher terminals No. 51 and 48 in junction block. If battery voltage
exists, go to next step. If battery voltage does not exist, repair
open circuit to fuse in junction block or PDC as necessary.
8) Disconnect negative battery cable. Check continuity
between combination flasher terminal No. 50 and ground. If continuity
exists, go to next step. If continuity does not exist, repair open
ground circuit.
9) Disconnect multifunction switch harness connector. Check
continuity between junction block terminal No. 4 and multifunction
switch terminal No. 13 (Pink wire). If continuity exists, go to next
step. If continuity does not exist, repair open in Pink wire between
multifunction switch and junction block.
10) Check continuity between junction block terminal No. 13
and multifunction switch terminal No. 17 (Red/White wire). If
continuity exists, test multifunction switch. See MULTIFUNCTION SWITCH
under COMPONENT TESTS. If continuity does not exist, repair open in
Red/White wire between junction block and multifunction switch.
REMOVAL & INSTALLATION
WARNING: Deactivate air bag system before performing any service

operation involving steering column components. See
appropriate AIR BAG RESTRAINT SYSTEMS article. DO NOT apply
electrical power to any component on steering column without
first deactivating air bag system. Air bag may deploy.
CAUTION: When battery is disconnected, vehicle computer and memory
systems may lose memory data. Driveability problems may exist
until computer systems have completed a relearn cycle. See
COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION
before disconnecting battery.
HORN SWITCH
NOTE: Horn switch removal and installation information for Dakota
and Durango is not provided by manufacturer.
Removal & Installation
Disconnect negative battery cable. Remove 4 air bag nuts from
back of steering wheel. Pull air bag module back far enough to
disconnect wiring connectors. Remove air bag module. To install,
reverse removal procedure. Tighten air bag nuts to 90-97 INCH lbs. (9-
11 N.m).
IGNITION SWITCH
CAUTION: DO NOT bump, jolt or hammer on steering shaft and gearshift
tube.
Removal
Remove lock cylinder. See LOCK CYLINDER. Remove 3 tamper-
proof Torx screws. See Fig. 5. Gently pull switch away from column.
Release connector locks on wiring connectors and remove switch from
connectors.
Fig. 5: Removing Ignition Switch Mounting Screws
Courtesy of Chrysler Corp.
Installation
1) Rotate flag on ignition switch to RUN position. This

TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS








\









\









\









\









\









\









\







Application INCH Lbs. (N.m)\
Air Bag Retaining Nuts ................................ 90-97 (9-11)\
Ignition Switch Mounting Screw ..................... 22-30 (2.5-3.5)\
Multifunction Switch Connector Screw ........................ 17 (2)\
Multifunction Switch Mounting Screw ......................... 17 (2)\
Steering Column Cover Screw ................................. 17 (2)\









\









\









\









\









\









\









\







WIRING DIAGRAMS
Fig. 9: Horn System Wiring Diagram (Dakota)

Fuel Transfer Pump Output Pressure
1) Remove 2 existing filter plug fittings at top of fuel
filter housing. Install 2 spring-loaded one-way check valve fittings
at inlet and outlet port. Install Fuel Pressure Test Gauge (6828) to
inlet port fitting. Prevent engine from starting by removing fuel
injection pump relay. Relay is located in Power Distribution Center
(PDC) next to left battery. Relay location is notated on PDC lid.
2) Crank engine while observing fuel pressure test gauge.
Fuel pressure should be 5-7 psi (0.35-0.49 kg/cm

). Reinstall fuel
system relay to PDC. Start engine. Fuel pressure should be minimum of
10 psi (0.7 kg/cm

). Because fuel injection pump relay was removed, a
Diagnostic Trouble Code (DTC) may have been set. Use DRB scan tool to
erase DTC. Go to PRESSURE DROP test.
Pressure Drop
Turn engine off. Remove Fuel Pressure Test Gauge (6828) from
inlet port and attach to outlet port. Start engine and note fuel
pressure. Pressure should not be more than 5 psi (0.35 kg/cm

) less
than inlet port pressure in Fuel Transfer Pump Outlet Pressure test.
See FUEL TRANSFER PUMP OUTPUT PRESSURE test. If fuel pressure is not
to specification, replace fuel filter. Go to FUEL SUPPLY RESTRICTION
test.
NOTE: Following test requires use of DRB scan tool and Periphal
Expansion Port (PEP) module. Ensure transfer pump pressure is\
okay before performing following test.
Fuel Supply Restriction
1) Disconnect fuel supply line quick-connect fitting at left
rear side of engine compartment. After disconnecting fuel line,
plastic clip will remain attached to metal fuel line at engine. Remove
clip from metal line. Snap clip into fuel supply hose. Install Rubber
Adapter Hose (6631) into ends of disconnected fuel supply line.
2) Install transducer from PEP module to brass "T" fitting on
rubber adapter hose. Connect DRB scan tool to transducer. Start engine
and record vacuum reading with engine speed at wide open throttle.
3) If vacuum reading is less than 6 in. Hg, check for
restriction in fuel supply line or fuel tank module. Repair fuel
supply line or module for restrictions as necessary. Also check fuel
pump inlet filter at bottom of module for obstructions. Go to AIR LEAK
IN FUEL SUPPLY LINE test.
NOTE: Following test requires use of a 3-foot section of 1/4" I.D.
clear tubing and 1/8" fitting.
Air Leak In Fuel Supply Line
1) Locate 2 test port plug fittings at top of fuel filter
housing. Clean fitting area. Remove test port fitting at fuel inlet
side of housing toward rear of filter housing. Install 1/8" fitting
with 1/4" O.D. nipple in place of test port. Clamp clear tubing to
fitting nipple. Place other end of hose into clear container.
2) To put fuel transfer pump into a 25 second run mode, turn
ignition switch to CRANK position, then release back to RUN position
without starting engine. Wait for air to purge from empty hose before
checking whether air bubbles are present. If bubbles are present,
check for leaks in supply line to fuel tank. If supply line is not
leaking, remove fuel tank module. Remove filter at bottom of module.
Check for leaks between supply nipple at top of module and filter
opening at bottom of module. Replace module as necessary.
Overflow Valve
1) Clean area around overflow valve and fuel return line at
injection pump. Remove overflow valve from pump and banjo fitting.

See appropriate DTC P0505: IAC MOTOR CIRCUIT in SELF-
DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article.
IGNITION SYSTEM
NOTE: For basic ignition checks, see TEST NS-SEL: NO START TEST
SELECTION in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS
article.
EMISSION SYSTEMS & SUB-SYSTEMS
NOTE: To locate emission components, refer to emission control
information label in engine compartment.
AIR INJECTION
No Air Supply (Ram Pickup 5.9L & 8.0L)
1) Start engine, and increase engine speed to 1500 RPM. Check
air supply at rubber hoses. If air supply increases with RPM, air pump
operation is okay.
2) If air pump is okay, check for leakage at hoses and
fittings. Repair or replace hoses as necessary.
3) If hoses are okay, check pressure relief valve for
leakage. If air is expelled through pressure relief valve at idle,
replace relief valve.
4) If relief valve is okay on 5.9L, test is complete. On 8.
0L, check inlet air filter. Repair air filter if plugged. If air
filter is okay, test is complete.
CRANKCASE VENTILATION (CCV)
8.0L
1) CCV system does NOT use a PCV valve. System consists of a
fixed orifice (Gray color) that is calibrated to a specific flow rate.\
The fixed orifice (located on intake manifold) is connected by a tube
to right valve cover.
2) A similar orifice is used on left cylinder head, but is
Black in color and cannot be interchanged with Gray orifice. Ensure
orifice, tubes and fittings are clean and in good condition. No
further information is available from manufacturer.
EXHAUST GAS RECIRCULATION (EGR)
EGR Valve
See TEST NTC-2: CHECKING EGR SYSTEM in SELF-DIAGNOSTICS -
JEEP, TRUCKS & RWD VANS article.
FUEL EVAPORATION
EVAP Canister
EVAP canister is located in engine compartment. Canister has
no moving parts. Check for loose, missing, cracked or broken
connections and parts. Repair or replace as necessary. No liquid
should be in canister.
LEAK DETECTION PUMP (LDP)
LDP
See appropriate DTC P1494: LEAK DETECTION PUMP SWITCH OR
MECHANICAL FAULT test in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS
