1999 BUICK LESABRE Owner's Manual

yellowblue
6-61
Fuse Usage
4B Not Used
5B
Anti
-Lock Brake System, Computer
Command Control
6B Brake and Hazard Lamps
7B Not Used
8B Interior Lighting
9B Cigarette Lighter
1C Air Bag System
2C Spare
3C Not Used
4C Not Used
5C Cooling Fans, Transaxle
6C Parking Lamps, Interior Lamps
7C Not Used
8C Parking Lamps
9C Radio, Cluster
1D Telltale, Chime, Cluster, RAC, LCMFuse Usage
2D Spare
3D Heated Mirrors
4D Not Used
5D Manual A/C
6D Not Used
7D TCC
8D Radio
9D Not Used
1E Not Used
2E
Air Bag System, PASS
-Key
3E Not Used
4E Not Used
5E Rear Defog
6E Not Used
7E
Miscellaneous Engine
-Non OBD II
8E Wipers, Washer
9E Not Used

yellowblue
6-62
Passenger's Side Fuse Block
Additional fuses are located in the relay center, on the
passenger's side, below the instrument panel. You must
remove the sound insulator on the right side of the
passenger footwell to replace these fuses.
Since the replacement of these fuses can be difficult,
we recommend that you see your dealer for
fuse replacement.

yellowblue
6-63
Fuse Usage
1 Door Locks
2 Trunk Release, RAC
3 Horns
4 Not Used
5 Miscellaneous Engine Controls (OBD II)
6 Fuel Pump
7 Injectors
8 Powertrain Control Module
9 Not Used
10 Not Used
11 A/C Programmer
12 Not UsedReplacement Bulbs
Front Outside Lamps Bulb
Cornering Lamps 3156. . . . . . . . . . . . . . . . . . . . . .
Halogen Headlamps
Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . . . . .
High Beam 9005. . . . . . . . . . . . . . . . . . . . . . . . . .
Parking/Turn Signal Lamps 3057. . . . . . . . . . . . . .
Rear Outside Lamps
Back
-Up Lamps 3156. . . . . . . . . . . . . . . . . . . . . . .
Tail 194. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tail/Stop/Turn Signal lamps 3357. . . . . . . . . . . . . .
For service information on other bulbs, contact your
dealer's service department.

yellowblue
6-64
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the Index
for more information.
3800 Series II Engine (L36) Code K 3.8L V6
Automatic Transaxle (Overdrive)
Pan Removal and Replacement 6.0 quarts (5.6 L). . .
After Complete Overhaul 10 quarts (9.5 L). . . . . . . . .
When draining or replacing torque convertor, more fluid
may be needed.
Cooling System13 quarts (12.3 L) . . . . . . . . . . . . . . .
Engine Crankcase4.5 quarts (4.3 L) . . . . . . . . . . . .
Oil change with filter change
Fuel Tank18 gallons (68.1 L) . . . . . . . . . . . . . . . . . .
Tire Pressures
See Tire-Loading Information. . . . . . . . .
label on driver's door.
Wheel Nut Torque100 lb-ft (140 N´m) . . . . . . . . . .
R
-134a Air ConditioningSee refrigerant charge. . . . .
label under the hood.
All capacities are approximate. When adding, be sure
to fill to the appropriate level, as recommended in
this manual.
Engine Specifications
3800 Series II Engine (L36) Code K
VIN Engine Code K. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 3.8L. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 205
-hp . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.

yellowblue
6-65
Normal Maintenance
Replacement Parts
Air Cleaner Filter AC Type A-1096C . . . . . . . . . . . . .
Engine Oil Filter AC Type PF
-47 . . . . . . . . . . . . . . . .
Fuel Filter AC Type GF
-627 . . . . . . . . . . . . . . . . . . . .
Transaxle Filter GM Part No. 8651909. . . . . . . . . . . .
Spark Plugs AC Type 41
-921 . . . . . . . . . . . . . . . . . . .
Gap: 0.060 inch (1.52 mm)
Windshield Wiper Blades
Type Pin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 22 inches (56 cm). . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length 200 inches (508.0 cm). . . . . . . . . . . . . . . . . . .
Width 73.6 inches (186.9 cm). . . . . . . . . . . . . . . . . . .
Height 55.7 inches (141.5 cm). . . . . . . . . . . . . . . . . . .
Wheelbase 110.8 inches (281.4 cm). . . . . . . . . . . . . .
Tread Width
Front 60.4 inches (153.4 cm). . . . . . . . . . . . . . . . . .
Rear 60.2 inches (152.9 cm). . . . . . . . . . . . . . . . . . .

yellowblue
6-66 L36 Engine Accessory Belt
The L36 engine uses an engine accessory belt. This
diagram shows the features connected and the routing.
See ªMaintenance Scheduleº in the Index for when to
check the belt.
A. Power Steering
B. Generator
C. Air Conditioning
D. Crank
E. Coolant Pump
F. Tensioner

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-3 How This Section is Organized
7
-4 Part A: Scheduled Maintenance Services
7
-4 Using Your Maintenance Schedule
7
-4 Selecting the Right Schedule
7
-7 Short Trip/City Scheduled Maintenance7
-23 Long Trip/Highway Scheduled Maintenance
7
-33 Part B: Owner Checks and Services
7
-37 Part C: Periodic Maintenance Inspections
7
-39 Part D: Recommended Fluids and Lubricants
7
-41 Part E: Maintenance Record

yellowblue
7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
