1999 BUICK LESABRE Owner's Manual

yellowblue
2-49
3. Press the COMPASS button on the bottom of the
mirror until the new zone number appears in the
display. After you stop pressing the button, the
display will show a compass direction within a few
seconds. (This is the automatic calibration mode.
Drive in a circle to calibrate the mirror. See
ªCompass Calibrationº explained previously.)
Manual Remote Control Mirror
To adjust the driver's side
outside mirror, rotate
the knob located on the
driver's door. The right
outside mirror must be
adjusted manually.
The outside rearview mirror should be adjusted so you
can just see the side of your vehicle when you are sitting
in a comfortable driving position.
To adjust your passenger's side mirror, sit in the driver's
seat and have a passenger adjust the mirror for you.

yellowblue
2-50 Power Remote Control Mirrors
(If Equipped)
If your vehicle has the
outside power remote
mirrors, the control
is located on the
driver's door.
Move the switch in the middle of the control to choose
the right or left mirror. Push the arrow controls in the
direction you want to move the mirror.
Adjust each mirror so you can see the side of your
vehicle and the area behind your vehicle.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Automatic Dimming/Heated Outside
Rearview Mirror (If Equipped)
If you have this feature, the outside mirrors will adjust
for the glare of headlamps behind you. This feature is
controlled by the on and off settings on the automatic
electrochromic day/night rearview mirror. See
ªElectrochromic Day/Night Rearview Mirrorº earlier in
this section.
When you operate the rear window defogger, a defogger
also warms the heated driver's and passenger's outside
rearview mirrors to help clear them of ice and snow.

yellowblue
2-51
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box. To
open, lift the latch release on the left side of the glove
box door.
Center Console Cupholder/Coinholder
The armrest between the front seats opens into a storage
area. To open it, press the lever at the front edge of the
armrest upward.Inside, a cupholder flips forward and unfolds to hold
two cups. The cupholder is designed to break away
should it receive excessive pressure. If it breaks away,
snap the edges back into place.
There is also a removable coinholder, cassette tape and
compact disc storage area.
Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
just inside the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops. For heavier loads, store them in
the trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Cigarette Lighter
The front center and rear ashtrays may be removed for
cleaning. Hold the sides of the ashtray and then pull the
ashtray up and out.

yellowblue
2-52
NOTICE:
Don't put papers or other flammable objects
into your ashtrays. Hot cigarettes or other
smoking materials could ignite them, causing
a damaging fire.
To use a lighter, push the center all the way in and let it
go. When it is ready, the center will pop back by itself.
Pull out the entire unit to use it.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
Illuminated Visor Vanity Mirrors
(If Equipped)
When you open the cover to either the passenger's or
driver's visor vanity mirror, the lamps will turn on. The
brightness of the lamp can be adjusted by sliding the
switch up or down.
Dual Sun Visors
Each sun visor has two parts, so that both the windshield
and door glass can be shaded at the same time. To use
the dual sun visors, flip the first visor down and turn
toward the window. Then, flip the second visor down
toward the windshield.

yellowblue
2-53
OnStar
System (Option)
Your vehicle may be equipped with the OnStar
Communications service. The following services are
available 24 hours a day from an OnStar representative:

Roadside Service with Location

Emergency Services Button

Remote Door Unlock

Theft Detection/Notification and Stolen
Vehicle Tracking

Automatic Notification of Air Bag Deployment

Concierge/Customer Conveniences Services
NOTE: Installation of aftermarket equipment is
possible, however, the features described above will not
be compatible with any portable phone other than the
OnStar cellular phone available from your dealer.
For more information, contact your dealer.

yellowblue
2-54
The Instrument Panel - Your Information System

yellowblue
2-55
1. Air Outlet
2. Instrument Panel Intensity Control
3. Twilight Sentinel
4. Turn Signal/Multifunction Lever
5. Tilt Steering Wheel Lever
6. Instrument Cluster/Gages
7. Hazard Warning Flasher Switch
8. Audio System9. Glove Box
10. Climate Control System
11. Ashtray and Cigarette Lighter
12. Ignition Switch
13. Traction Control Button
14. Trunk Release Button
15. Hood Release

yellowblue
2-56
Instrument Panel Clusters
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know how
fast you're going, how much fuel you're using, and many other things you'll need to drive safely and economically.
Your vehicle is equipped with one of these instrument panel clusters, which includes indicator warning lights and
gages that are explained on the following pages.
Standard Cluster
