1999 BUICK LESABRE Owner's Manual

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-3
VENT: This setting directs outside air through the
middle instrument panel outlets. The air conditioning
compressor is not working when VENT is selected.
HTR: This button directs air out of the heater outlets.
Most of the air will come from the floor outlets while
some air will flow through the windshield and side
window outlets. The air conditioning compressor is not
working when HTR is selected.
BLEND: When BLEND is selected, the airflow will be
split between the windshield and the floor outlets. The
air conditioning compressor will be operating.
FRONT: This setting directs most of the airflow toward
the windshield.
OFF: The ventilation system always allows fresh air to
flow through your vehicle when it is moving. The
system will try to keep the air at a previously chosen
temperature. When the system is off, the blower fan is
also off.
MAX: This setting directs airflow through the middle
instrument panel outlets. The amount of outside air
entering your vehicle is limited with this setting. The air
conditioning compressor is on in this mode.NORM: This setting cools the outside air entering your
vehicle and directs it through the middle instrument
panel outlets. The air conditioner is on in this mode.
BI
-LEV: This setting directs warm air to the floor and
cooler air to the middle instrument panel outlets. The air
conditioner is on in this mode.
Dual Automatic Comfortemp
Climate Control (If Equipped)
If your vehicle has the Dual Automatic Comfortemp
Climate Control option, the following information tells
you how it works.
You will hear a beep each time a button is pushed and a
light on the button will indicate which function is active.
The lights are on all buttons except TEMP, FAN and
AIR FLOW. The display will show fan speed, comfort
level setting and airflow direction for a few seconds
whenever AUTO is selected, and then it will display the
outside temperature. The outside temperature reading is
most accurate when the vehicle is moving. During stops,
the display shows the previous temperature for best
accuracy and system control.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-4
C±43±2053±T
If the display is flashing after the climate control system
is started, there is a problem with the system and you
should see your dealer for service.
Sun and temperature sensors automatically adjust the air
temperature, the airflow direction and the fan speed to
maintain your comfort setting. The system may supply
cooler air to the side of the vehicle toward the sun. Be
careful not to put anything over the sensors on top of
the dash.Temperature Button
To adjust the comfort level you want maintained inside
the vehicle, push the TEMP button. If you want a
warmer comfort level, push the red arrow. If you want a
cooler comfort level, push the blue arrow. Your comfort
setting is shown in the display.
Fan Button
The speed of the blower fan is controlled automatically if
you have the system set for AUTO. Pressing the FAN
button will display and hold the current blower fan setting.
If you want the blower fan to run at a lower speed, push
the bottom of the FAN button. The fan speed will
decrease with every push of the button until the lowest
speed is reached. If you want to increase the fan speed,
push the top of the FAN button. Notice the fan
indicators in the display.
Mode Controls
Press the AIR FLOW button to deliver air through the
floor, middle or windshield outlets. The system will stay
in the selected mode until the AUTO button is pushed.
Use the up and down arrows on the AIR FLOW button
to cycle through the available modes.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-5
Automatic Operation
Press the AUTO button when you want the system to
automatically adjust to changes in the temperature inside
the vehicle, the outside temperature and the sun load on
the vehicle. When the system is set for automatic
operation, air will come from the floor, middle or
windshield outlets depending on the temperature inside
the vehicle, the outside temperature and sun load. Fan
speed will vary as the system gets to and maintains the
comfort setting you have selected through the use of the
TEMP button.
To find your comfort setting, start with the system in
AUTO mode and the TEMP button adjusted to 75
F
(24
C), give the vehicle about 20 minutes to stabilize,
and adjust your comfort setting if necessary, by using
the TEMP button. The display will show the comfort
setting for a few seconds and then it will display the
outside temperature. If you want to see your current
automatic fan speed, airflow direction and comfort
setting, press the AUTO button.
In cold weather, the system will delay turning on the
fan, to avoid blowing cold air. The length of the delay
depends on the engine coolant temperature and the
outside temperature. Pushing the FAN, AIR FLOW or
FRONT buttons will override this delay, turn off the
AUTO setting and change the fan speed.Manual Operation
You may also manually adjust the air delivery or
fan speed.
AIR FLOW: This button is used to change the direction
of the airflow. The airflow choices available are FLOOR,
FLOOR
-MID, MID and WINDSHIELD-FLOOR. If the
system is set for AUTO, pressing the AIR FLOW button
will display the current airflow direction and the comfort
setting. Press the AIR FLOW up or down button again to
change the direction of the airflow.
If the AIR FLOW up button is selected while in the
FRONT defrost mode, the system will direct the air
toward the windshield and the floor. If the AIR FLOW
down button is selected while in the FRONT defrost
mode, the system will direct the air toward the floor, and
the FRONT defrost mode will cancel. Notice the arrows
in the display.
OFF: If the passenger comfort control is turned on, it can be
turned off by pressing the OFF button once. Pressing the OFF
button a second time will turn off the main system. Turning
off the main system causes the fan to turn off and the airflow
to be directed toward the floor. The system will still try to
keep the interior of the vehicle at the previous chosen
comfort setting. The outside temperature will show on the
display when the system is OFF.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-6
The ventilation system always allows fresh air to flow
through your vehicle when the vehicle is moving even
with the system in the OFF mode.
VENT: The VENT button allows outside air to flow
through your vehicle without the air conditioning
compressor working. Selecting VENT and the AUTO
button at the same time allows the system to control
automatically without the use of the air conditioning
compressor or the use of the RECIRC mode. To turn off
the VENT selection, push the VENT button again.
RECIRC: When RECIRC is selected, the system will
limit the amount of outside air entering your vehicle. This
is helpful when you are trying to cool the interior of the
vehicle quickly or limit the amount of outside air entering
your vehicle. RECIRC and AUTO may be selected at the
same time. The system will remain in RECIRC until the
ignition is turned off, then the system will return back to
the previously selected mode. Deselecting the RECIRC
button will also turn off the RECIRC function. RECIRC
can be selected in all manual airflow modes except
FRONT defrost and VENT.
FRONT: This selection is used to defrost the windshield
by directing the airflow toward the windshield.If FRONT is selected while in the AUTO mode, the fan
speed and the air temperature from the front defroster will
vary. If a manual fan speed setting is selected, the fan
speed will remain at that selection until another fan speed
selection is made or the AUTO mode is selected. To turn
off FRONT, press the AUTO or AIR FLOW button.
FRONT defrost will work better if any ice or snow is
cleared from the hood and the air inlet area between the
base of the windshield and the hood.
Air Conditioning
On hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
If you have the electronic touch system, for quick
cool
-down on very hot days, use MAX with the
temperature and fan speed adjusted to COOL and
HIGH. If this setting is used for long periods of time, the
air in your vehicle may become too cold and dry.
For normal cooling on hot days, use NORM and adjust
the temperature and fan speed for your comfort. If
RECIRC is selected while in the NORM air
conditioning mode, the system works like MAX and
recirculates the air.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-7
On sunny days, when the air is moderately warm or
cool, use BI
-LEV to deliver warm air to the floor and
cooler air to the middle instrument panel outlets. On
days like these, the sun may adequately warm your
upper body, but your lower body may not be warm
enough. To warm or cool the air delivered, adjust the
TEMPERATURE lever.
The amount of fresh air entering the vehicle is limited
when RECIRC is selected. This is helpful when you are
trying to cool the air in your vehicle or limit the air
entering the vehicle.
If your vehicle has the Dual Automatic Comfortemp
system and it is set for AUTO, on very hot days, the
system will automatically enter the RECIRC mode and
the temperature door will be positioned at the full cold
position for maximum cooling. If the system is not in
the AUTO mode, RECIRC should be selected to provide
maximum cooling. You can choose the extreme comfort
setting of 60
F (16
C), but the system will not cool any
faster by choosing the extreme comfort setting.
When the air conditioner is on, you may sometimes
notice slight changes in your vehicle's engine speed and
power. This is normal because the system is designed to
cycle the compressor on and off to keep the
desired temperature.Heating
If your vehicle has the electronic touch system, on
cold days, use HTR with the TEMPERATURE lever
toward WARM.
If your vehicle has the Dual Automatic Comfortemp
system, and on cold days, if the AUTO mode is selected,
the system will automatically direct the air toward the
floor and the temperature door will be positioned at the
full hot position. You can choose the extreme comfort
setting of 90
F (32
C) but the system will not warm up
any faster by selecting the extreme comfort setting. If
the outside temperature is cold, the fan will be delayed
to avoid blowing cold air. Pushing the FAN, AIR FLOW
or FRONT buttons will override this delay, turn off the
AUTO mode and change the fan speed.
With each system, outside air will be brought in and sent
through the floor outlets. The heater works best if you
keep your windows closed while using it.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-8 Defogging and Defrosting
If you have the electronic touch system, adjust the
TEMPERATURE lever toward WARM and the FAN
lever toward HIGH.
If you have the Dual Automatic Comfortemp system,
use the FRONT button to defog or defrost the
windshield. By choosing this button, the airflow will be
directed at the windshield. Adjust your comfort level by
pressing the TEMP up or down arrow. The fan speed
will be controlled by the system. You can change the fan
speed by pressing the top of the FAN button to increase
speed, and the bottom of the button to decrease speed.
To reduce the chance of fogging your windows in cold
weather, using the electronic touch system, select HTR
to supply air through the floor outlets. Then move the
FAN lever to HIGH for a few moments before driving
away. This will blow moist air from the intake outlets
toward the floor, not the windshield. If you have the
Dual Automatic Comfortemp system, the AUTO setting
will do this for you. Manual operation of the automatic
comfortemp system in the FLOOR mode will also
supply air through the floor outlets.
Rear Window Defogger
C±43±0375±S
The lines you see on the
rear window warm the
glass. Press this button to
start warming your window.
After 10 minutes it will turn off by itself, or pressing the
button during the heating cycle will turn it off. If you
need additional warming time, push the button again.
The system will then operate for five minutes before
going off by itself.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-9
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the rear defogger grid. The repairs wouldn't be
covered by your warranty.
Passenger Control (If Equipped)
C±43±5387±M
If you have the Dual
Automatic Comfortemp
system, the front seat
passenger can control the
air temperature in their
seating area.
The temperature can be set up to 5
F or 3
C cooler or
warmer than the primary setting. To activate the
passenger control, simply press the COOL or WARM
buttons located on the passenger's door.
The indicator lights above the control will show the
difference from the main temperature setting.
If the passenger control has been turned on, it can be
turned off by pressing the OFF button once. Pressing the
OFF button a second time will turn off the main system.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-10 Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use VENT (on the electronic touch
system or manual operation on the Dual Automatic
Comfortemp system) to direct outside air through your
vehicle. Air will flow through the middle instrument
panel outlets.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it's moving. When the
vehicle is not moving, you can get outside air to flow
through by selecting any air choice (except the rear
window defogger) and any fan speed.
H±43±0384±N
Adjust the direction of
airflow by moving the
louvered vents.
H±43±0385±P
If you have the rear passenger comfortemp option,
you can adjust the direction of the airflow to the rear
seating area.
