1998 TOYOTA T100 Owners Manual

T100(U)1
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLS—
Chapter 1
−1
Overview of instruments
and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the
instrument panel

T100(U)
2
Instrument panel overview
1. Side vent
2. Instrument cluster
3. Center vents
4. Personal lights
5. Glovebox
6. Power door lock switch
7. Power window switches
8. Manual transmission gear shift lever
9. Front drive control lever
10. Lower vent
11. Hood lock release lever
12. Power rear view mirror control switch

T100(U)3
1. Clutch start cancel switch
2. Headlight and turn signal switch
3. Windshield wiper and washer switches
4. Automatic transmission selector lever
5. Emergency flasher switch
6. Clock
7. Cup holder
8. Air conditioning controls
9. Car audio
10. Ashtray
11. Cigarette lighter
12. Parking brake lever
13. Ignition switch
14. Cruise control switch
15. Tilt steering lock release lever
16. Instrument panel light control knob

T100(U)
4
1. Engine coolant temperature gauge
2. Service reminder indicators or indicator lights
3. Trip meter 4. Odometer
5. Speedometer
6. Fuel gauge
7. Trip meter reset knob
Instrument cluster overview
Without tachometer

T100(U)5
1. Engine coolant temperature gauge
2. Oil pressure gauge
3. Tachometer
4. Service reminder indicators or indicatorlights 5. Odometer
6. Speedometer
7. Trip meter
8. Voltmeter
9. Low fuel level warning light
10. Fuel gauge 11. Trip meter reset knob

With tachometer

T100(U)
6
Indicator symbols on the instrument panel
Automatic transmission fluid temparature warning
light

SRS airbag warning light
Unengaged ”Park” warning light
Anti-lock brake system warning light
Seat belt reminder light

(type A)
(type B)
Low oil pressure warnig light

Low fuel level warning light
Brake system warning light

Discharge warning light
Malfunction indicator lamp
Low windshield washer fluid level warning light
Headlight high beam indicator light
Overdrive-off indicator light
Turn signal indicator lights
”4WD” indicator light
Automatic transmission indicator lights
Cruise control indicator light
The indicators marked with
are service reminder indicators.
For details, see ”Service reminder indicators and warning buzze rs”
in Chapter 1 −5.

T100(U)7
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLS–
Chapter 1
−2
Keys and Doors
Keys
Side doors
Power windows
Quarter windows
Rear window
Tailgate
Hood
Fuel tank cap
Keys
The key works in every lock.
Since the doors can be locked without a
key, you should always carry a spare key
in case you accidentally lock your key
inside the vehicle.
Keep the key number plate in a safe
place such as your wallet, not in the
vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
You should also put a copy of the key
number with your important papers.

T100(U)
8
Side doors
LOCKING WITH KEY
Turn the key towards the front of the
vehicle to lock and towards the back to
unlock.
Vehicles with power door lock system—
Both doors lock and unlock simultaneously
with either door. In the driver’s door lock,
turning the key once will unlock the driv-
er’s door and twice in succession will un-
lock the driver ’s door and passenger ’s
door simultaneously.LOCKING WITH INSIDE LOCK KNOB
Turn the lock knob forward to lock and
backward to unlock the door.
Closing the door with the lock knob in the
lock position will also lock the door. Be
careful not to lock your keys in the ve-
hicle.
Vehicles with power door lock sys-
tem—The doors cannot be locked if you
leave the key in the ignition switch.LOCKING WITH POWER DOOR LOCK
SWITCH
To lock and unlock both doors simulta-
neously, push the power door lock
switch.
