1998 TOYOTA T100 Owners Manual

T100(U)105
Fan speed selector
Move the lever to adjust the fan speed—
to the right to increase, to the left to
decrease.
Temperature selector
Move the lever to adjust the tempera-
ture—to the right to warm, to the left to
cool.
Air flow selector
Move the lever to select the vents used
for air flow.
1. Panel— Air flows mainly from the
instrument panel vents.
2. Bi −level— Air flows from both the floor
vents and the instrument panel vents.
3. Floor— Air flows mainly from the floor
vents.
4. Floor/Windshield— Air flows mainly
from the floor vents and windshield
vents.
5. Windshield— Air flows mainly from the
windshield vents. For details about air flow selector settings,
see the illustration after ”A/C” button.
Vehicles with ”A/C” button—
Moving the air flow selector lever to the
windshield position turns on the defroster
−
linked air conditioning. This is to clear up
the front view more quickly.
When the ”A/C” button is not pressed in,
moving the air flow selector lever to
another position turns off the air condition-
ing.

T100(U)
106
Air intake selector
Move the lever to select the air source. 1. Recirculate —Recirculates the air inside
the vehicle.
2. Fresh —Draws outside air into the sys-
tem. ”A/C” button
To turn on the air conditioning, press the
”A/C” button. The ”A/C” button indicator
will come on. To turn the air conditioning
off, press the button again.

T100(U)107
—Air flow selector settings
—Operating tips
To cool off your Toyota after it has
been parked in the hot sun, drive with
the windows open for a few minutes.
This vents the hot air, allowing the air
conditioning to cool the interior more
quickly.
Make sure the air intake grilles in front
of the windshield are not blocked (by
leaves or snow, for example).
On humid days, do not blow cold air
on the windshield. The windshield could
fog up because of the difference in air
temperature on the inside and outside
of the windshield.
Keep the area under the front seats
clear to allow air to circulate through-
out the vehicle.
On cold days, move the fan speed to
”HI” for a minute to help clear the in-
take ducts of snow or moisture. This
can reduce the amount of fogging on
the windows.

T100(U)
108
Heating
For best results, set controls to:
Fan speed —Any setting except ”OFF”
Temperature —Towards WA R M
(red zone)
Air intake —FRESH (outside air)
Air flow —FLOOR
Air conditioning —OFF
For quick heating, select recirculated
air for a few minutes. To keep the
windows from fogging, select fresh af-
ter the vehicle interior has been
warmed.
Press the ”A/C” button on for dehumidi-
fied heating.
Choose floor/windshield air flow to heat
the vehicle interior while defrosting or
defogging the windshield. Air conditioning
For best results, set controls to:
Fan speed —Any setting except ”OFF”
Temperature —Towards COLD
(blue zone)
Air intake —FRESH (outside air)
Air flow —PA N E L
Air conditioning —ONFor quick cooling, move the air intake
selector to recirculate for a few min-
utes.
Ventilation
For best results, set controls to:
Fan speed —Any setting except ”OFF”
Temperature —Towards COLD
(blue zone)
Air intake —FRESH (outside air)
Air flow —PA N E L
Air conditioning —OFF
Defogging
The inside of the windshield
For best results, set controls to:
Fan speed —Any setting except ”OFF”
Temperature —Towards WARM
(red zone) to heat; COLD (blue zone) to
cool
Air intake —FRESH (outside air)
Air flow —WINDSHIELD
Vehicles with ”A/C” button—
Moving the air flow selector lever to the
windshield position turns on the defroster −
linked air conditioning. This is to clear up
the front view more quickly.
When the ”A/C” button is not pressed in,
moving the air flow selector lever to
another position turns off the air condition-
ing.
On humid days, do not blow cold air
on the windshield—the difference be-
tween the outside and inside tempera-
tures could make the fogging worse.

T100(U)109
Defrosting
The outside of the windshield
For best results, set controls to:
Fan speed —Any setting except ”OFF”
Temperature —Towards WA R M
(red zone)
Air intake —FRESH (outside air)
Air flow —WINDSHIELD
Vehicles with ”A/C” button—
Moving the air flow selector lever to the
windshield position turns on the defroster −
linked air conditioning. This is to clear up
the front view more quickly.
When the ”A/C” button is not pressed in,
moving the air flow selector lever to
another position turns off the air condition-
ing.
To heat the vehicle interior while de-
frosting the windshield, choose
floor/windshield air flow. —Instrument panel vents
If air flow control is not satisfactory, check
the instrument panel vents. The instrument
panel vents may be opened or closed as
shown.

T100(U)
11 0

T100(U)111
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLS—
Chapter 1
−8
Other equipment
Clock
Cigarette lighter and ashtray
Glovebox
Auxiliary box
Cup holder
Floor mat
Clock
The digital clock indicates the time with
the ignition key at the ”ACC” or ”ON”
position. To reset the hour, depress the
”H” button. To reset the minutes, de-
press the ”M” button. To adjust the
time to a full hour, depress the ”:00”
button.
For example, if the ”:00” button is de-
pressed when the time is between
1:01—1:29, the time will change to 1:00.
If the time is between 1:30—1:59, the
time will change to 2:00.
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced. Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (one
o’clock).

T100(U)
11 2
Cigarette lighter and ashtray
To operate the cigarette lighter, press it
in. When it becomes heated, it automat-
ically pops out ready for use.
If the engine is not running, the key must
be in the ”ACC” position.
Do not hold the cigarette lighter pressed
in.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull out.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.
Glovebox
To open the glovebox door, pull the
lever.
On some models, the glovebox light will
come on when the door is open with the
headlight switch on.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glovebox door closed
while driving.
