1998 TOYOTA T100 Owners Manual

T100(U)193
Adding washer fluid
If any washer does not work, the wash-
er tank may be empty. Add washer
fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.NOTICE
5VZ
−FE engine vehicles for Canada:
When adding washer fluid, be careful
not to spill the fluid over the daytime
running light resistor.
Replacing light bulbs—
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if scratched
or dropped. Hold a bulb only by its
plastic or metal case. Do not touch
the glass part of a bulb with barehands.
NOTICE
Only use a bulb of the listed type.

T100(U)
194 Light bulbs
Bulb
No.WTy p e
Headlights900360/55A
Parking lights1685C
Front turn signal lights115627B
Rear turn signal lights115627B
Stop and tail lights115727/8B
Back-up lights115627B
High mounted stoplight1685C
License plate light1685C
Interior light—8D
Personal lights—5D
Glovebox light—5C
Step lights—5C
A: HB2 halogen bulbs
B: Single end bulbs
C: Wedge base bulbs
D: Double end bulbs —Headlights
1. Open the hood. Unplug the connec-
tor. Turn the plastic cover counter-
clockwise and remove it.
If the connector is tight wiggle it.2. Remove the rubber cover.

T100(U)195
3. Release the bulb retaining springand remove the bulb. Install a new
bulb and the bulb retaining spring.
To install a bulb, align the tabs of the
bulb with the cutout of the mounting hole.4. Install the rubber cover and snuggle on the boss.
Make sure the rubber cover fits snugly on
the connector and the headlight body.5. Install the plastic cover with the ”ON” mark upward and turn it clock-
wise. Insert the connector.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.

T100(U)
196
—Parking lights
Use a Phillips-head screwdriver.
—Front turn signal lights
Use a Phillips-head screwdriver.

T100(U)197
Use a Phillips-head screwdriver.a: Rear turn signal light
b: Stop and tail light
c: Back-up light —High mounted stoplightUse a Phillips-head screwdriver.
—Rear turn signal, stop and
tail and back-up lights

T100(U)
198
—License plate lights

T100(U)199
Part 8
SPECIFICATIONS
Dimensions and weight
Engine
Fuel
Service specifications

Ti r es
Fuses

T100(U)
200
Dimensions and weight
Normal cab modelsXtra-cab models
Two-wheel drive modelsFour-wheel drive modelsTwo-wheel drive modelsFour-wheel drive models
Overall length mm(in.)5310 (209.1)5310 (209.1)5310 (209.1)5310 (209.1)
Overall width mm(in.)1910 ( 75.2)1910 ( 75.2)1910 ( 75.2)1910 ( 75.2)
Overall height— mm(in.)
Unladen vehicle1710 ( 67.2)
1
1720 ( 67.6)
2
1730 ( 68.2)
31790 ( 70.6)
5
1820 ( 71.6)
71730 ( 68.2)
4
1740 ( 68.6)
51840 ( 72.6)
5
1870 ( 73.5)
7
Wheelbase mm(in.)3095 (121.9)3095 (121.9)3095 (121.9)3095 (121.9)
Front tread mm(in.)1565 ( 61.6)
4
1570 ( 61.8)
51605 ( 63.2)
5
1635 ( 64.4)
71565 ( 61.6)
4
1570 ( 61.8)
51605 ( 63.2)
5
1635 ( 64.4)
7
Rear tread mm(in.)1615 ( 63.6)
4
1625 ( 64.0)
51615 ( 63.6)
5
1650 ( 65.0)
71615 ( 63.6)
4
1625 ( 64.0)
51615 ( 63.6)
5
1650 ( 65.0)
7
Cargo weight rating
kg (lb.)498 ( 1100)
6
907 ( 2000)
3498 ( 1100)498 ( 1100)498 ( 1100)
1
: 1/2-ton models with P215/75R15 tires
2
: 1/2-ton models with P235/75R15 tires
3
: 1-ton models
4
: With P215/75R15 tires
5
: With P235/75R15 tires
6
: 1/2-ton models
7
: With P265/70R16 tires
