1998 HONDA CIVIC COUPE Owners Manual

Moonroof, Mirrors

Moonroof

On EX model in the U.S., and Si model

in Canada

Use the switches on the dashboard
under the left vent to operate the
moonroof. The ignition must be ON

(II).

To lift the rear of the moonroof for ventilation, push the button.
To slide the moonroof back, push the switch. Hold it until the
moonroof reaches the desired position, then release the switch.
To close the moonroof, press and hold the switch.

If you try to open the moonroof in below-freezing temperatures, or whenit is covered with snow or ice, you can
damage the moonroof panel or motor.
Mirrors

Keep the inside and outside mirrors
clean and adjusted for best visibility.
Be sure to adjust the mirrors before
you start driving.
The inside mirror has day and night positions. The night position reduces
glare from headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night

position.

Instruments and Controls

NOTICE

Closing the moonroof on
someone's hands or fingers can
cause serious injury.
Make sure passengers are
clear of the moonroof before

closing it.
TABMain Menu Table of Contents s t

Mirrors, Parking Brake

Adjusting the Power Mirrors
On HX and EX models in the U.S., and Si
model in Canada
Adjust the outside mirrors with the adjustment switch on the left side of
the dashboard:
1. Turn the ignition switch ON (II).
2. Move the selector switch to L (driver's side) or R (passenger's

side).
3. Push the appropriate edge of the
adjustment switch to move the

mirror right, left, up or down.
4. When you finish, move the
selector switch to the center (off)

position. This turns off the
adjustment switch so you can't
move a mirror out of position by

accidentally bumping the switch. Parking Brake
To apply the parking brake, pull the lever up fully. To release it, pull upslightly, push the button, and lower
the lever. The parking brake light on
the instrument panel should go out
when the parking brake is fully released (see page 53).
Instruments and Controls

SELECTOR SWITCH

ADJUSTMENT SWITCH

PARKING BRAKE LEVERMain Menu Table of Contents s t

Parking Brake, Glove Box

Driving the vehicle with the parking brake applied can damage the rear
brakes and axles.
Glove Box
Open the glove box by pulling the
handle. Close it with a firm push.

Instruments and Controls

NOTICE

An open glove box can causeserious injury to your passengerin a crash, even if the
passenger is wearing the seat
belt.
Always keep the glove box
closed while driving.
GLOVE BOXMain Menu Table of Contents s t

Beverage Holder

To open the beverage holder, push on the top. The beverage holder lid
is spring-loaded and will swing open.
To close it, push it down until it latches. Use the beverage holder only when
the vehicle is parked. If you place
cups in the holder while driving, the
liquid may spill when you go over
bumps or around corners.
Be careful when you are using the
beverage holder. A spilled liquid that
is very hot can scald you or your
passengers. Spilled liquids can also damage the upholstery, carpeting,
and electrical components in the
interior.
Instruments and Controls
PushMain Menu Table of Contents s t

Accessory Power Socket, Ashtrays

Accessory Power Socket

To use the accessory power socket,
pull down the cover. The ignition
switch must be in ACCESSORY (I)

or ON (II). This socket is intended to supply
power for 12 volt DC accessories
that are rated 120 watts or less (10
amps).

It will not power an automotive type
cigarette lighter element. Ashtrays
(Optional)
Front and rear ashtrays are available
as options. The front ashtray fits in
the beverage holder.
The rear ashtray fits in the rear of the center armrest.
Open the rear ashtray by swinging
the upper edge down. To remove the ashtray for emptying, open the
ashtray and then lift it up and out.
Use the ashtray only for cigarettes,
cigars, and other smoking materials. To prevent a possible fire and damage
to your vehicle, don't put paper or
other things that can burn in the

ashtray.

Instruments and Controls
ACCESSORY POWER SOCKET

NOTICEMain Menu Table of Contents s t

Interior Light

(U.S.: EX, Canada: Si)

The interior light has a three- position switch. In the OFF position,
the light does not come on. In thecenter position, the interior lightcomes on when you open any door.
In the ON position, the interior light stays on continuously.
(U.S.: DX, HX, Canada: DX)

On U.S. vehicles with remote

transmitter

The interior light (with the switch in the center position) also comes on
when you unlock the door with the
remote transmitter (see page 70).
If you installed a non-Honda radio in
your vehicle, the interior light will no longer work.
(U.S.: EX)

Turn on the spotlight by pushing the button next to each light. Push the
button again to turn it off. You canuse the spotlights at all times.
Instruments and Controls

DOOR ACTIVATED

OFF ON

DOOR ACTIVATED

ON
OFFMain Menu Table of Contents s t

Comfort and Convenience Features

The heating and air conditioning* systems in your Honda provide a
comfortable driving environment in
all weather conditions.
The standard audio system has many features. This section de-
scribes those features and how to
use them. (If you selected an optional audio system, refer to the
operating instructions that came
with it.)
* Air conditioning is standard on the
EX model in the U.S. It is optional on
other models.
Heating and Cooling........................ 86
What Each Control Does............ 86How to Use the System............... 88
To Turn Everything Off............. 93
Audio System................................... 94 Operating the Radio.................... 94
Adjusting the Sound.................... 96 Radio Frequencies....................... 97
Radio Reception........................... 97
Digital Clock................................. 99Operating the Cassette Player...................................... 100
Tape Search Functions............. 100 Caring for the Cassette Player...................................... 102
Operating the Optional
CD Player/Changer.............. 103
Protecting Compact Discs........ 105
CD Changer Error Indications.............................. 106
Comfort and Convenience FeaturesMain Menu s t

Heating and Cooling

Proper use of the Heating and
Cooling system can make the

interior dry and comfortable, and

keep the windows clear for best

visibility.

If your vehicle does not have air

conditioning, it can be installed at

any time. Your dealer will install a
Genuine Honda air conditioning

system that meets Honda's high

quality standards and is designed to

exactly fit your vehicle. Please

contact your dealer for more

information.
What Each Control Does Fan Control Lever
Sliding this lever to the right
increases the fan's speed, which
increases air flow.
Comfort and Convenience Features MODE BUTTONS
RECIRCULATION
BUTTON AIR CONDITIONING
BUTTON

TEMPERATURE
CONTROL LEVER FAN CONTROL

LEVER

Temperature Control Lever
Sliding this lever to the right
increases the temperature of the air

flow.

Air Conditioning (A/C) Button
This button turns the air condi- tioning ON and OFF. The indicatorin the button lights when the A/C is

on.
Recirculation Button
This button controls the source of the air going into the system. When
the indicator in this button is lit, air
from the vehicle's interior is sent through the system again (Recircula-
tion mode). When the indicator is off,air is brought in from outside the
vehicle (Fresh Air mode).Main Menu Table of Contents s t
