1998 FORD WINDSTAR warning

Seating and Safety Restraints
189
*
[SS29100(ALL)05/96]
RWARNING
Carefully follow all of the manufacturer's instructions
included with the safety seat you put in your vehicle. If
you do not install and use the safety seat properly, the
child may be injured in a sudden stop or collision.
*
[SS29200(ALL)05/96]
RWARNING
Always keep the buckle release button pointing upward
and away from the child seat, with the tongue between
the child seat and the release button as shown in the
following illustration.
*
[SS29300(ALL)05/96]
Installing Child Safety Seats in the Front Seat and Rear
Window Passenger Seating Positions
[SS29400(ALL)12/95]
Your vehicle is equipped with a dual locking mode retractor on
the shoulder belt portion of the combination lap/shoulder safety
belt for the front seat passenger and for the rear window
passengers.
[SS29500(ALL)12/95]
If you choose to install a forward-facing child seat or infant
carrier in the front seating positions, move the seat as far back
as possible.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
199
%*
[SS32300(ALL)04/96]
Attaching Safety Seats With Tether Straps
*
[SS32400(ALL)04/96]
Some manufacturers make safety seats that include a tether
strap that goes over the back of the vehicle seat and attaches to
an anchoring point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of your child safety
seat for information about ordering a tether strap.
[SS32500(ALL)12/95]
You can attach a tether strap to the front passenger or second
row seats by using the built-in tether anchors provided on the
back of the seats as described below.
[SS32600(ALL)12/95]
Follow the child seat manufacturer's instructions to attach the
tether strap to the tether anchor.
[SS32700(ALL)12/95]
RWARNING
Use only the tether attachment locations shown below.
The tether anchor may not perform properly if the wrong
mounting location is used.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

204
[SS33500(ALL)12/95]
n
SECOND ROW BUCKET (if equipped) SEATING POSITION
Ð You must use the tether strap anchor location provided
on the back of the seat cushion. (Refer to Figure 4.)
[SS33600(ALL)12/95]
13-1/2 pica
art:0050178-A
Figure 4: Tether anchor location Ð second row bucket seat
*
[SS33700(ALL)01/96]
RWARNING
Only use the tether attachment hole locations shown in
the illustrations. The tether anchor may not perform
properly if the wrong mounting location is used.
[SS33800(ALL)12/95]
Once you have attached the safety seat, test the seat before you
place the child in it. Tilt the seat from side to side. Also try to
tug the seat forward. Check to see if the belt holds the seat in
place.
[SS33900(ALL)12/95]
RWARNING
If the safety seat is not anchored properly, the risk of a
child being injured in a collision or sudden stop greatly
increases.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

205
Starting
%*
[TO00200(ALL)01/96]
Fuel-Injected Engines
[TO00300(ALL)07/96]
Since your vehicle has a fuel-injected engine,the most
important thing to remember is to avoid pressing down on the
acceleratorwhile cranking the engine to start. Only use the
accelerator when you have problems getting your vehicle
started.
%*
[TO00400(ALL)01/96]
Preparing to Start Your Vehicle
*
[TO00500(ALL)02/96]
RWARNING
Do not start your vehicle in a closed garage or in other
enclosed areas. Exhaust fumes can be toxic. Always open
the garage door before you start the engine.
*
[TO00600(ALL)01/96]
Before you start your vehicle, always:
*
[TO00700(ALL)01/96]1.
Make sure you and all your passengers buckle your safety
belts. SeeSafety beltsin the Index for more details.
*
[TO00800(ALL)01/96]2.
Make sure the headlamps and other accessories are turned
off when starting.
[TO00900(ALL)12/95]3.
Make sure that the gearshift lever is in Park (P) and the
parking brake is set before you turn the key.
[TO01000(ALL)07/96]
Before you start your vehicle, you should test the warning lights
on the instrument cluster to make sure that they work. Refer to
theInstrumentationchapter.
[TO01100(ALL)12/95]
Starting the Engine
[TO01200(ALL)12/95]
To start the engine:
[TO01300(ALL)07/96]1.
Follow the steps underPreparing to Start Your Vehicle.
*
[TO01400(ALL)01/96]2.
Keep your foot on the brake pedal and turn the ignition key
to ON.
File:08wntos.ex
Update:Mon Oct 7 11:45:28 1996

Starting
207
*
[TO02500(ALL)12/95]
NOTE: Your vehicle has an interlock that prevents you from
shifting out of P (Park) unless your foot is on the
brake pedal.
*
[TO02600(ALL)01/96]
If the engine still does not start after two attempts:
[TO02700(ALL)04/96]1.
Turn the key to the OFF position and wait about two
minutes.
*
[TO02800(ALL)01/96]2.
Press the accelerator all the way to the floor and hold it.
[TO02900(ALL)12/95]3.
Turn the key to the START position.
[TO03000(ALL)12/95]4.
Release the key when the engine starts.
*
[TO03100(ALL)03/96]5.
Release the accelerator gradually as the engine speeds up.
*
[TO03200(ALL)05/96]
If the engine still does not start, the fuel pump shut-off switch
may have been activated. For directions on how to reset the
switch seeFuel Pump Shut-Off Switchin the index.
[TO03300(ALL)12/95]
A computer system controls the engine's idle rpm. When you
start your vehicle, the engine's idling rpm normally runs high.
These faster engine speeds will make your vehicle move slightly
faster than when the engine is at its normal warm engine idle
speed. It should, however, slow down when the vehicle warms
up. If it does not, have the idle rpm checked.
*
[TO03400(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
File:08wntos.ex
Update:Mon Oct 7 11:45:28 1996

208
%*
[TO03500(ALL)01/96]
Using the Engine Block Heater (If equipped)
[TO03600(ALL)12/95]
Using your engine block heater is strongly recommended if you
live in a region where temperatures consistently reachs20ÊF
(s29ÊC) orbelow during the winter months. An engine block
heater warms the engine coolant which improves starting,
warms up the engine faster, and allows the heater-defrost
system to respond more quickly.
*
[TO03700(ALL)01/96]
RWARNING
To prevent electrical shock, do not use your heater with
ungrounded electrical systems or two-pronged (cheater)
adapters.
*
[TO03800(ALL)01/96]
For best results, plug the heater in at least three hours before
you start your vehicle. Using the heater for longer than three
hours will not damage the engine, so you can leave it plugged
in all night to start your vehicle the following morning.
*
[TO03900(ALL)12/95]
Guarding Against Exhaust Fumes
[TO04000(ALL)12/95]
Carbon monoxide, although colorless and odorless, is present in
exhaust fumes.
*
[TO04100(ALL)02/96]
RWARNING
Do not start your vehicle in a closed garage or in other
enclosed areas. Exhaust fumes can be toxic. Always open
the garage door before you start the engine.
*
[TO04200(ALL)01/96]
RWARNING
If you ever smell exhaust fumes of any kind inside your
vehicle, have your dealer inspect and fix your vehicle
immediately. Do not drive if you smell exhaust fumes.
These fumes are harmful and could kill you.
File:08wntos.ex
Update:Mon Oct 7 11:45:28 1996

211
Driving
%*
[GF00200(ALL)05/96]
Brakes
*
[GF00300(ALL)01/96]
When the foot (service) brake pedal is depressed, the
high-mount brake lamp should illuminate.
*
[GF00400(ALL)01/96]
Front Disc Brakes
[GF00500(ALL)01/96]
The front disc brakes are self-adjusting. They only require
periodic inspection for pad wear.
[GF00600(ALL)01/96]
Rear Disc Brakes (If equipped)
[GF00700(ALL)01/96]
The rear disc brakes are self-adjusting. They only require
periodic inspection for pad wear.
[GF00800(ALL)01/96]
The rear disc parking brakes need to be adjusted manually.
*
[GF00900(ALL)03/96]
Rear Drum Brakes
*
[GF01000(ALL)01/96]
The rear drum brakes are self-adjusting. Automatic adjustment
occurs through normal use of the brakes.
*
[GF01100(ALL)05/96]
Four-Wheel Anti-lock Brakes
*
[GF01200(ALL)01/96]
The Anti-lock Brake System (ABS) prevents wheels from
completely locking up by automatically releasing and
re-applying the brakes. During ABS braking, slight brake pedal
pulsations may be felt on the driver's foot. These pulsations
represent the rapid cycling of the ABS valves. The pedal
pulsations are considered normal ABS operation, and will stop
when normal braking is resumed or when the vehicle comes to
a stop.
[GF01300(ALL)09/96]
During ABS activation, a mechanical noise may be heard as the
ABS cycles. This is normal ABS operation.
[GF01400(ALL)09/96]
The ABS has self-check capabilities. The system turns on the
ABS warning light each time you start the engine. After the
engine is started and the ABS warning light turns off, the
system performs another test the first time the vehicle reaches
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996

2124 mph (6 km/h). A mechanical noise may be heard as the ABS
performs a self test. This is a normal part of the self test feature.
If a malfunction is found during this check, the ABS warning
light will come on.
[GF01500(ALL)01/96]
6 pica art:0050147-B
The anti-lock brake system light
[GF01600(ALL)09/96]
You should always be careful when braking, even if your
vehicle has the ABS. Heavy braking on roads with loose
surfaces such as snow or gravel, or roads with severe pavement
irregularities could also cause you to lose control of your
vehicle.
*
[GF01700(ALL)03/96]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
*
[GF01800(ALL)03/96]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
*
[GF01900(ALL)01/96]
Ford Motor Company has not found any negative effects of
mobile radio transmitting equipment installed on vehicles with
the ABS system providing that the radio is installed according
to the radio manufacturer's instructions. However, if you have
had a mobile radio transmitter installed and the ABS light
comes on (at any time other than immediately after turning the
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996
