1998 FORD WINDSTAR warning

Controls and Features
97
*
[CF19800(ALL)01/96]
Windshield Washer
[CF19900(ALL)01/96]
To clean the windshield, push in the washer button on the end
of the turn signal lever. For a constant spray, push and hold the
button. If the windshield wipers are off, one momentary push
results in one wipe and a longer push in three wipes and
activation of washer fluid. If the windshield wipers are in
interval mode a quick tap results in two wipe cycles and a
longer tap in three wipes and washer fluid activation.
*
[CF20000(ALL)01/96]
Do not try to clean the windshield when the washer fluid
container is empty and never activate the washers for more than
fifteen seconds continuously. This could damage the washer
pump system.
*
[CF20100(ALL)01/96]
RWARNING
Always warm up the windshield with the defroster
before you use the washer fluid. In freezing weather, the
washer solution may freeze on the windshield and
obscure your vision.
*
[CF20200(ALL)03/96]
For information about refilling the washer fluid or replacing
your windshield wiper blades, seeWindshield washer fluid and
Wipersin the Index.
%*
[CF20300(ALL)01/96]
Gearshift Lever
[CF20400(ALL)07/96]
The gearshift lever on your vehicle is mounted on the steering
column. On the end of the gearshift lever is the Overdrive
On/Off button and the OVERDRIVE OFF lamp. For additional
information about the gearshift lever and the Overdrive On/Off
button, see theDrivingchapter.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

102
%*
[CF22905(ALL)10/96]
To Turn Speed Control Off
*
[CF22907(ALL)10/96]
n
Press OFF,
*
[CF22909(ALL)10/96]
n
Turn off the vehicle ignition.
*
[CF22911(ALL)10/96]
Once speed control is switched off, the previously programmed
set speed will be erased.
*
[CF22913(ALL)10/96]
To Turn Speed Control On
*
[CF22915(ALL)10/96]
n
Press ON
*
[CF22921(ALL)10/96]
To Set a Speed
*
[CF22923(ALL)09/96]
Press SET ACCEL. For speed control to operate, the speed
control must be ON and the vehicle speed must be greater than
30 mph (48 km/h).
*
[CF22925(ALL)09/96]
If you drive up or down a steep hill, your vehicle speed may
vary momentarily slower or faster than the set speed. This is
normal.
*
[CF22927(ALL)09/96]
Speed control cannot reduce the vehicle speed if it increases
above the set speed on a downhill. If your vehicle speed is
faster than the set speed while driving on a downhill in
j
(Overdrive), you may want to shift to the next lower gear to
reduce your vehicle speed.
*
[CF22929(ALL)09/96]
If your vehicle slows down more than 10 mph (16 km/h) below
your set speed on an uphill, your speed control will disengage.
This is normal. Pressing RESUME will re-engage it.
*
[CF22931(ALL)09/96]
RWARNING
To keep your vehicle under control, do not use speed
control in heavy traffic or on roads that are winding,
slippery, or unpaved.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

114
[CF34900(ALL)01/96]
To open a window, press the recessed area of the switch. To
close it, press the raised area of the switch.
*
[CF35000(ALL)01/96]
RWARNING
Do not let children play with the power windows.
[CF35100(ALL)09/96]
10-1/2 pica
art:0050030-C
The power window switches
[CF35200(ALL)01/96]
One-Touch-Down Power Window (If equipped)
[CF35300(ALL)09/96]
The one-touch-down power window feature allows you to
completely open the driver's window without holding down the
window switch. To open the window completely, press the
button all the way down until you hear a click. If the top of the
button is pressed firmly while the window is going down, the
window will stop at that position.
[CF35400(ALL)09/96]
To open the window only partially, press the lower half of the
switch lightly but not all the way down and hold it until the
window has opened to the desired position and then release the
switch.
[CF35500(ALL)01/96]
To close the window you must hold the upper half of the
button until the window closes.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
117
[CF37000(ALL)09/96]
10-1/2 pica
art:0050034-B
The power quarter window switches
%*
[CF37100(ALL)03/96]
Mirrors
*
[CF37200(ALL)01/96]
RWARNING
Make sure you can see clearly through the rearview
mirror at all times. Do not block your vision. If you
cannot see through the mirror, it could result in a
collision, injuring yourself and others.
%*
[CF37300(ALL)01/96]
Side View Mirrors
*
[CF37400(ALL)01/96]
Close your door and adjust the driver's seat to the most
comfortable position before you adjust the side view mirrors.
[CF37500(ALL)12/95]
If you have manually adjusting side view mirrors, you can
adjust them in any direction by moving the mirror glass. The
mirror heads should be folded rearward to prevent damage
when using an automatic car wash.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
123
[CF39900(ALL)01/96]
Make certain that you close the liftgate door before driving your
vehicle. Possible damage may occur to the liftgate door lift
cylinders and attaching hardware if the liftgate door is not
closed prior to driving.
*
[CF40000(ALL)01/96]
RWARNING
Make sure that the liftgate door and/or window are
closed to prevent exhaust fumes from being drawn into
the vehicle. This will also prevent passengers and cargo
from falling out. If you must drive with the liftgate door
or window open, keep the vents open so outside air
comes into the vehicle.
*
[CF40100(ALL)01/96]
Liftgate closing procedure
*
[CF40200(ALL)01/96]1.
To make the liftgate swing downward, reach up and pull the
lower edge of the liftgate (or the loop handle on the inner
trim panel of vehicles with this option) and pull downward.
*
[CF40300(ALL)01/96]2.
When you have pulled down the liftgate enough so that you
can reach the license plate light shield, push the shield down
and forward to close the latch and liftgate. At this point, the
latch is not locked.
[CF40400(ALL)09/96]3.
You can lock the liftgate latch by pushing down the
night-lock button (located on the inside of the liftgate at the
bottom of the window) before you pull down and close the
liftgate. You can also lock the liftgate latch by inserting your
vehicle's door key and turning it counterclockwise after you
have closed the liftgate, by pressing LOCK on your
remote (if equipped), or by using the power door locks on
the front doors or the power lock switch in the cargo area.
*
[CF40500(ALL)01/96]
The liftgate area is only intended for cargo, not passengers. You
can open and close the liftgate from outside the vehicle. It
cannot be opened from inside the cargo area.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

124
%*
[CF40600(ALL)10/96]
Cargo Net (If equipped)
*
[CF40700(ALL)10/96]
The cargo net is designed to hold your cargo upright between
the third row bench seat and the liftgate to prevent it from
moving around the cargo area.
*
[CF40800(ALL)10/96]
To install the cargo net:
*
[CF40900(ALL)10/96]
Attach the loops on the four corners of the net to the four
retainers on the cargo area rear quarter panels. Pull on the net
to be sure that it is fastened securely.
*
[CF41000(ALL)10/96]
RWARNING
Be sure to secure all four loops into the retainers. The
cargo restrained in the net must not exceed 50 lbs.
(22.5 kg) or the net may not stay secured.
*
[CF41100(ALL)10/96]
To remove the cargo net, remove the loops from the four
retainers.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

135
Seating and Safety Restraints
%*
[SS00200(ALL)05/96]
Seats
*
[SS00300(ALL)01/96]
Adjusting the Seats
[SS00400(ALL)01/96]
Adjusting the front seats manually
[SS00500(ALL)01/96]
To move the front seats forward or backward:
[SS00600(ALL)01/96]1.
Find the adjustment bar at the lower cushion of the front
seat.
[SS00700(ALL)01/96]2.
Pull the bar up to unlatch the seat.
*
[SS00800(ALL)01/96]3.
Move the seat to the desired position.
*
[SS00900(ALL)01/96]4.
Release the bar to latch the seat in its new position. Make
sure the seat locks securely in place.
*
[SS01000(ALL)05/96]
RWARNING
Never adjust the driver's seat or seatback when the
vehicle is moving.
*
[SS01100(ALL)07/96]
RWARNING
Do not pile cargo higher than the seatbacks to avoid
injuring people in a collision or sudden stop.
*
[SS01200(ALL)02/96]
RWARNING
Always drive and ride with your seatback upright and
the lap belt snug and low across the hips.
*
[SS01300(ALL)05/96]
RWARNING
Children should always ride with the seatback in the
fully upright position.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

136
*
[SS01350(ALL)09/96]
RWARNING
It is extremely dangerous to ride in a cargo area, inside
or outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured or
killed. Do not allow people to ride in any area of your
vehicle that is not equipped with seats and safety belts.
Be sure everyone in your vehicle is in a seat and using a
safety belt properly.
% [SS01400(ALL)01/96]
Using the power seats (if equipped)
[SS01500(ALL)01/96]
If your vehicle has the power seat option, you can adjust it in
several directions. The controls are on the outboard side of the
driver's seat.
[SS01600(ALL)09/96]
one third page
art:0050103-B
The power controls on the driver's seat
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996
