1998 FORD WINDSTAR warning

Seating and Safety Restraints
175
*
[SS22200(ALL)05/96]
RWARNING
Do not leave children, unreliable adults, or pets
unattended in your vehicle.
*
[SS22300(ALL)05/96]
RWARNING
Safety belts and seats can become hot in a vehicle that
has been closed up in sunny weather; they could burn a
small child. Check seat covers and buckles before you
place a child anywhere near them.
*
[SS22400(ALL)05/96]
When possible, put children in the rear seat of your vehicle.
Accident statistics suggest that children are safer when properly
restrained in the rear seating positions than in the front seating
positions.
%*
[SS22500(ALL)01/96]
Built-In Child Seat (If equipped)
[SS22600(ALL)08/96]
The second row bench seat may include two optional built-in
child safety seats (one on the driver side and one on the
passenger side). This child restraint is to be usedonlyby
children who are at least one year old, weigh between 10 and
27 kilograms (22 and 60 pounds) and whose shoulders (top) are
below the bottom of the headrest in thefull upposition.
*
[SS22700(ALL)03/96]
If your child is less than one year old or weighs less than
10 kilograms (22 pounds),alwaysuse a rear facing infant or
convertible seat because a child of that size is not sufficiently
developed to withstand crash forces in a front facing position.
Follow the specific manufacturer's instructions for weight and
height restrictions.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

176
*
[SS22800(ALL)01/96]
RWARNING
Always latch the vehicle seat to the floor, whether the
seat is occupied or empty. If not latched, the seat may
cause injury during a sudden stop.
*
[SS22900(ALL)08/95]
Children must be properly buckled before riding in the vehicle.
It is the law in every state and province. This child seat
conforms to all Federal/Canadian motor vehicle safety
standards.
[SS23000(ALL)04/96]
Built-in child seat belt retractors
[SS23100(ALL)04/96]
The belts on the built-in child seat are equipped with a retractor
that locks when both belt tongues are latched into the crotch
safety belt buckle.
[SS23200(ALL)04/96]
The retractor will switch from the emergency locking mode to
the automatic locking mode when the shoulder belts are pulled
all the way out. The retractor will switch back to emergency
locking mode when the belts are unbuckled and the shoulder
belts retract completely.
[SS23300(ALL)04/96]
The automatic locking mode must be used to hold small
children in position, particularly sleeping children and those
who may try to squirm out of the belts. The emergency locking
mode is also used while buckling the belts.
[SS23400(ALL)12/95]
Frequently check the child seat's lap and shoulder harness belts
for correct placement and tightness. Use the child seat only if
the harness belts will stay snug when belts are placed into the
lock mode with a child in the seat. If belts do not remain snug,
take the vehicle to the dealer for child seat repair.
*
[SS23500(ALL)01/96]
Always adjust the lap and shoulder harness belts provided with
this child seat snugly around your child.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
177
*
[SS23600(ALL)05/96]
RWARNING
Do not leave children, unreliable adults, or pets
unattended in your vehicle.
*
[SS23700(ALL)05/96]
RWARNING
Safety belts and seats can become hot in a vehicle that
has been closed up in sunny weather; they could burn a
small child. Check seat covers and buckles before you
place a child anywhere near them.
*
[SS23800(ALL)01/96]
RWARNING
Failure to follow all of the instructions on the use of this
child restraint system can result in your child striking the
vehicle's interior during a sudden stop or crash.
*
[SS23900(ALL)08/95]
How to use the Built-In Child Seat
*
[SS24000(ALL)01/96]
Read the following procedures and all of the labels on the
Built-In Child Seat before using the seat.
*
[SS24100(ALL)01/96]
RWARNING
Never use the Built-In Child Seat as a booster cushion
with the adult safety belts. A child using the adult belts
could slide forward and out from under the safety belts.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
179
[SS24600(ALL)12/95]2.
Read the information and warnings on the child seat cushion
protector flap and shoulder safety belt. Refer to Figure 2.
Check the child's size, weight and age to be sure the child is
not too small or too large for the child seat. Then fold the
flap down onto the adult seat cushion.
[SS24700(ALL)09/96]
17-1/2 pica art:0050136-E
Figure 2: Child seat information and warnings
[SS24800(ALL)12/95]3.
If connected, squeeze the top and the bottom of the right
half of the chest clip and pull to separate both halves.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

182
[SS25300(ALL)12/95]6.
Fasten both halves of the chest clip below the child's
shoulders and adjust it to comfortably hold the shoulder
belts in place on the child's chest. The color green must
appear in the indicator window when fastened. (The purpose
of this clip is to position the shoulder belts correctly on the
child's shoulders.) Refer to Figure 5.
*
[SS25400(ALL)01/96]
RWARNING
If both tongues do not latch in the buckle, do not use the
child seat. See your dealer for repairs.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

186
*
[SS26800(ALL)01/96]
Inspection after a collision
*
[SS26900(ALL)01/96]
RWARNING
All built-in child restraints, including seats, buckles,
retractors, seat latches, interlocks, and attaching hardware
should be inspected by a qualified dealer technician after
any collision.
*
[SS27000(ALL)01/96]
If the child seat was in use during a collision, Ford recommends
replacing it. However, if the collision was minor and a qualified
technician finds that the child restraints do not show damage
and continue to operate properly, they do not need to be
replaced. If there is any bending of the vehicle seatback or seat
structure, it should also be replaced. Built-in child seats not in
use during a collision should also be inspected and replaced if
either damage or improper operation is noted.
*
[SS27300(ALL)08/95]
Built-in child seat maintenance
[SS27400(ALL)04/96]
Regularly inspect the lap and shoulder belts system of your
child seat. See your Ford Dealer if the shoulder belt webbing is
frayed, or if the buckle and tongue are damaged and/or do not
function properly.
%*
[SS27500(ALL)01/96]
Safety Belts for Children
*
[SS27600(ALL)01/96]
Children who are too large for child safety seats should always
wear safety belts. (See instructions with your child seat, or
contact its manufacturer, to determine maximum size of child
that will safely fit in the seat.)
*
[SS27700(ALL)01/96]
RWARNING
If safety belts are not properly worn and adjusted as
described, the risk of serious injury to the child in a
collision will be much greater.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
187
*
[SS27800(ALL)01/96]
If the shoulder belt portion of one of the lap and shoulder belts
can be positioned so that it does not cross or rest in front of the
child's face or neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the vehicle may
help provide a good shoulder belt fit.
*
[SS27900(ALL)01/96]
Lap belts and the lap belt portion of lap and shoulder belts
should always be worn snugly and below the hips, touching the
child's thighs.
*
[SS28000(ALL)05/96]
RWARNING
Children should always ride with the seatback in the
fully upright position.
%*
[SS28100(ALL)01/96]
Safety Seats for Children
*
[SS28200(ALL)01/96]
Use a safety seat that is recommended for the size and weight
of the child. Always follow the safety seat manufacturer's
instructions when installing and using the safety seat.
*
[SS28300(ALL)01/96]
Ford recommends the use of a child safety seat having a top
tether strap. Install the child safety seat in a seating position
which is capable of providing a tether anchorage. For more
information on top tether straps seeAttaching Safety Seats With
Tether Strapsin this chapter.
*
[SS28400(ALL)05/96]
When installing a child safety seat, be sure to use the correct
safety belt buckle for that seating position, and make sure the
tongue is securely fastened in the buckle. For a shoulder/lap
belt combination with a sliding tongue, make sure the retractor
is in the automatic locking mode.
[SS28500(ALL)04/96]
In rear-facing infant seats, the infant's head is closer to the
passenger air bag. The force of the rapidly inflating air bag
could push the top of the rear-facing seat against the vehicle
seatback. REAR-FACING INFANT SEATS MUST ALWAYS BE
SECURED IN THE REAR SEAT, and other child seats and
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

188infant seats should be secured in the rear seat whenever
possible. Forward-facing child seats used in the front seat must
have the passenger seat moved as far back from the instrument
panel as possible.
*
[SS28600(ALL)05/96]
Your vehicle is equipped with a right front passenger air bag.
Air bags deploy with great force, faster than the blink of an eye.
Front passengers, especially children and small adults, must
never sit on the front edge of the seat, stand near the glove
compartment of the instrument panel, or lean over near the air
bag cover when the vehicle is moving. All occupants should sit
with their backs against the seatback, move the seat to the most
rearward position if possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should use child or
infant seats.
%*
[SS28700(ALL)07/96]
RWARNING
When installing forward-facing child seats in the front
seat, always move the passenger seat as far back from the
instrument panel as possible. Never install rear-facing
child seats or rear-facing infant seats in the front seat.
*
[SS28800(ALL)05/96]
The force of the rapidly inflating passenger air bag could push
the top of the rear-facing seat against the vehicle seatback,
armrests or console. Rear-facing infant seats must always be
secured in the rear seat.
*
[SS28900(ALL)05/96]
All child restraint systems are designed to be secured in vehicle
seats by lap belts or by the lap portion of a lap-shoulder belt.
*
[SS29000(ALL)03/96]
RWARNING
If you do not properly secure the safety seat, the child
occupying the seat may be injured during a collision or
sudden stop. An unsecured safety seat could also injure
other passengers.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996
