1998 FORD WINDSTAR display

Instrumentation
15
*
[IS04800(ALL)05/96]
Under certain conditions, the Service Engine Soon Light may
come on if the fuel cap is not properly installed. If the Service
Engine Soon Light comes on and you suspect that the fuel cap
is not properly installed, pull off the road as soon as it is safely
possible and turn off the engine. Remove and replace the cap,
making sure it is properly seated.
*
[IS04900(ALL)05/96]
After completing the three consecutive warm up cycles and on
the fourth engine start up, the Service Engine Soon Warning
Light should turn off. If the light does not go off after the
fourth engine re-start, have your vehicle serviced by your dealer
or a qualified technician.
%*
[IS05000(ALL)01/96]
Charging System Light
[IS05100(ALL)07/96]
This light indicates that your battery is not being charged. The
light illuminates briefly during the display self-test every time
you turn your ignition key to the ON position. The light will go
off when the key is turned to the START position. The light
should stay off when the self-test is done if the engine is
running and the alternator is charging.
*
[IS05200(ALL)03/96]
If the light stays on or illuminates when the engine is running,
have the electrical system checked as soon as possible.
[IS05300(ALL)12/95]
6 pica art:0050149-B
The charging system light
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

20
% [IS09200(ALL)09/96]
Low Fuel Indicator Light (If equipped)
[IS09300(ALL)12/95]
This light comes on when your fuel gauge indicates
approximately 1/16 of a tank. The ignition must be turned to
ON in order for this light to come on.
[IS09400(ALL)12/95]
6 pica art:0050189-A
The low fuel indicator light
[IS09500(ALL)08/96]
Cruise Control Indicator
[IS09600(ALL)08/96]
A CRUISE light is displayed in the instrument cluster when the
speed control system is engaged. The display will turn off when
the brake pedal is pressed or if speed control is shut off.
[IS09700(ALL)08/96]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
[IS09800(ALL)09/96]
6 pica art:0051002-A
The speed control light
*
[IS10200(ALL)04/96]
Gauges
%*
[IS10400(ALL)08/96]
Fuel Gauge
[IS10500(ALL)12/95]
The fuel gauge displays approximately how much fuel is in the
fuel tank only when the ignition is ON. For proper fuel gauge
indication after adding fuel, the ignition should be in the OFF
position while the vehicle is being refueled.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

30
%*
[AS01175(ALL)10/95]
Compact Disc Radio
*
[AS01250(ALL)10/95]
The Compact Disc Radio combines the Electronic Stereo Radio
with the Ford Compact Disc Player.
*
[AS01300(ALL)08/95]
Using the Controls on Your New Radio/CD Player
*
[AS01400(ALL)04/92]
Most of the features of this unit work for both radio and CD
operation, depending on which mode the unit is in. Also, some
of the buttons control several different functions, so be sure to
read all of the operating instructions carefully.
*
[AS01500(ALL)03/96]
How to turn the radio on and off
*
[AS01600(ALL)10/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS01625(ALL)03/96]
How to adjust the volume
*
[AS01650(ALL)03/96]
Press the (R/S) side of the ªVOLº button to increase/decrease
the volume. Bars illuminate in the display to show the relative
volume level.
*
[AS01675(ALL)02/96]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off, the volume will remain
in the position it was set at when radio power was
switched off.
*
[AS01700(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS01800(ALL)10/95]
Push the ªAM/FMº button to select the desired frequency band.
When in the radio mode, pushing the button more than once
will alternate between AM, FM1 and FM2. These functions are
used with the station memory buttons described underHow to
tune radio stations.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

Electronic Sound Systems
31
%*
[AS01900(ALL)03/96]
How to tune radio stations
*
[AS02000(ALL)10/95]
There are four ways for you to tune in a particular station. You
can manually locate the station using the ªSCAN/TUNEº
button, ªSEEKº the station, ªSCANº to the station or select the
station by using the memory buttons, which you can set to any
desired frequency. These four methods are described below.
*
[AS02100(ALL)10/95]
n
Using the ªSCAN/TUNEº button to manually tune
*
[AS02200(ALL)04/96]
You can change the frequency up or down one increment at
a time (FM changes in increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the ªSCAN/TUNEº
button twice (display shows ªTUNEº), then Ðwithin
approximately five secondsÐpressing and releasing either
the top
aor bottom
bhalf of the ªSEEKº button. To
change frequencies quickly, press andhold downeither the
top or bottom half of the ªSEEKº button. While you are
manually tuning, the display will show a blinking ªMº.
*
[AS02300(ALL)03/96]
Manual tuning adjusts your radio to any allowable broadcast
frequency, whether or not a station is present on that
frequency. (SeeAll About Radio Frequenciesin this section.)
*
[AS02400(ALL)04/96]
n
Using the ªSEEKº function
*
[AS02500(ALL)04/96]
This feature on your radio allows you to automatically select
listenable stations up or down the frequency band. Press the
top
ahalf of the ªSEEKº button to select the next listenable
station up the frequency band. Press the bottom
bhalf of
the button to select the next listenable station down the
frequency band. By pressing and holding the button,
listenable stations can be passed over to reach the desired
station.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

32
*
[AS02600(ALL)02/96]
n
Using the ªSCAN/TUNEº button to scan radio stations
*
[AS02700(ALL)04/96]
Pressing the ªSCAN/TUNEº button once enters the scan
mode (display will indicate ªSCNº). Pushing the top
ahalf
of the ªSEEKº button will begin the scan mode up the
frequency band, stopping on each listenable station for
approximately five seconds. Pushing the bottom
bhalf of
the ªSEEKº button will begin the scan mode down the
frequency band, again stopping on each listenable station for
approximately five seconds.
*
[AS02800(ALL)03/96]
To stop the scan mode on the presently sampled station,
press the ªSCAN/TUNEº button again.
*
[AS03000(ALL)03/96]
n
Setting the station MEMORY PRESET buttons
%*
[AS03100(ALL)06/96]
Your radio is equipped with 5 station memory buttons.
These buttons can be used to select up to 5 preset AM
stations and 10 FM stations (5 in FM1 and 5 in FM2). Follow
the easy steps below to set these buttons to the desired
frequencies.
*
[AS03200(ALL)06/96]1.
Select a band, then select a frequency.
*
[AS03400(ALL)06/96]2.
Press one of the memory preset buttons and hold the button
until the sound returns. That station is now held in memory
on that button.
*
[AS03500(ALL)06/96]3.
Follow the two steps above for each station memory preset
button you want to set.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

Electronic Sound Systems
33
[AS03600(ALL)04/92]
Using the Automatic Memory Load and Automatic
Memory Store features
[AS03700(ALL)09/95]
NOTE: If no stations are in memory presets, you can activate
the feature by pressing and holding the ªAUTO
PRESETº button for approximately three seconds.
Auto Memory Load sets all memory buttons in AM,
FM1 and FM2 sequentially by seeking out the first
five strong stations for the respective band and storing
them in memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM band.)
*
[AS03800(ALL)05/96]
With Auto Memory Store, you can continually set strong
stations into your memory buttons without losing your existing
memory presets, which is especially helpful while traveling.
Your radio will automatically set your memory buttons to the
strong local stations so you don't have to continually manually
tune to existing stations.
*
[AS03900(ALL)02/96]
Activate Auto Memory Store by pushing the ªAUTO PRESETº
button once. Your radio will set the first five strong stations of
the band you are in (AM, FM1 or FM2) into the memory
buttons. The display will show ªAUTO,º then run through the
frequencies, stopping momentarily on the stations being set into
the memory buttons. The radio is now in the ªAUTOº mode
and the display will show ªAUTOº each time a preset is
activated.
*
[AS04000(ALL)10/95]
NOTE: If there are fewer than five strong stations in the
frequency band, the remaining unfilled buttons will
store the last strong station detected on the band.
*
[AS04100(ALL)03/96]
After all stations have been filled, the radio will begin playing
the station stored on memory button 1.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

34
*
[AS04200(ALL)02/96]
To deactivate the Auto Memory Store mode and return to the
manually-set memory button stations (or those stations set using
Auto Memory Load), simply push the ªAUTO PRESETº button.
Display will show ªAUTOº then ªOFF.º The next time Auto
Memory Store is activated on that band, the radio will store the
next set of five strong stations.
*
[AS04400(ALL)08/95]
Using the ªAUDIOº button to adjust the tone balance
and speaker output
*
[AS04500(ALL)02/96]
n
Increasing or decreasing bass response
*
[AS04600(ALL)08/95]
Push the ªAUDIOº button repeatedly until the display reads
ªBASS.º Push the ª+º side of the ªVOLº button to increase
bass (more ªlowsº), and push the ª-º side to decrease bass
(less ªlowsº).
*
[AS04700(ALL)02/96]
n
Increasing or decreasing treble response
*
[AS04800(ALL)08/95]
Push the ªAUDIOº button repeatedly until the display reads
ªTREB.º Push the ª+º side of the ªVOLº button to increase
treble (more ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS05100(ALL)02/96]
n
Adjusting speaker balance
*
[AS05200(ALL)08/95]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Push the ªAUDIOº
button repeatedly until the display reads ªBAL.º Push the
ª+º side of the ªVOLº button to shift the sound to the right
speakers, and push the ª-º side to shift the sound to the left
speakers.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

Electronic Sound Systems
35
*
[AS05300(ALL)04/96]
n
Adjusting speaker fader
*
[AS05400(ALL)08/95]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Push the ªAUDIOº
button repeatedly until the display reads ªFADE.º Push the
ª+º side of the ªVOLº button to shift the sound to the front
speakers, and push the ª-º side to shift the sound to the rear
speakers.
[AS05500(ALL)09/95]
NOTE: Illuminated bars in the display show relative levels of
bass and treble and positions of speaker balance and
fader functions for five seconds after adjustments are
made, then revert to volume level set.
%*
[AS05600(ALL)08/95]
Clock operation
*
[AS05700(ALL)08/95]
When in the radio mode, push the ªCLOCKº button to switch
from radio frequency to clock. Only the clock numerals will be
displayed in the clock mode Ð there is no A.M./P.M.
indication. When in the clock mode, the time will be displayed
until the button is pushed again. However, if you retune the
radio while it is in the clock mode, the new radio frequency
will be displayed for approximately ten seconds and then
change back to clock.
*
[AS05800(ALL)08/95]
When in the CD mode, push the ªCLOCKº button to change
the display from elapsed time mode to track number mode to
clock mode. If the CD track selection is changed when you are
in the clock or elapsed time mode, the new track number will
be displayed for approximately ten seconds and then revert
back to the previous mode.
*
[AS05900(ALL)08/95]
To set the clock, simultaneously press the ªCLOCKº button and
either the bottom (
b) half of the ªSEEKº button to set hours,
or the top (
a) half of the ªSEEKº button to set minutes.
[AS06000(ALL)04/96]
NOTE: The clock can be set with the radio and/or ignition on
or off.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996
