1998 FORD WINDSTAR warning

Maintenance and Care
279
*
[MC06700(ALL)01/96]
RWARNING
Continuous contact with USED motor oil has caused
cancer in laboratory mice.
*
[MC06800(ALL)01/96]
Protect your skin by washing with soap and water.
%*
[MC06900(ALL)05/96]
Brake Fluid
*
[MC07000(ALL)01/96]
Your vehicle is equipped with a brake fluid level indicator in
the master cylinder which lights the BRAKE warning light on
the instrument panel when the brake fluid level is low.
*
[MC07100(ALL)01/96]
Under normal circumstances, your vehicle should not use up
brake fluid rapidly. However, expect the level of the brake fluid
to slowly fall as you put more mileage on your vehicle and the
brake pads wear.
[MC07200(ALL)07/96]
Check the brake fluid at least once a year. You can do this by
looking at the fluid level in the plastic reservoir on the master
cylinder. The fluid level should be at or near the MAX mark.
Add fluid if level is 0.30" or more below the MAX line.
*
[MC07300(ALL)01/96]
RWARNING
Brake fluid is toxic.
*
[MC07400(ALL)01/96]
If brake fluid contacts eyes, flush eyes with running water for
15 minutes. Get medical attention if irritation persists. If taken
internally, drink water and induce vomiting. Get medical
attention immediately.
%*
[MC07500(ALL)03/96
]
If the fluid is low, carefully clean and remove the filler cap
from the reservoir. Fill the reservoir to the MAX line with Ford
High Performance DOT 3 Brake Fluid C6AZ-19542-AB or DOT 3
equivalent fluid meeting Ford specification ESA-M6C25-A.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

280
[MC07600(ALL)01/96]
13-1/2 pica
art:0050216-B
The brake fluid reservoir
*
[MC07700(ALL)01/96]
RWARNING
If you use a brake fluid that is not DOT 3, you will
cause permanent damage to your brakes.
[MC07750(ALL)09/96]
Add fluid if level is 0.30ª or more below the MAX line.
*
[MC07800(ALL)01/96]
Do not fill the reservoir above the MAX line.
*
[MC07900(ALL)01/96]
If you find that the fluid level is excessively low Ð below the
seam or ridge on the outside of the plastic reservoir Ð have the
brake system inspected.
*
[MC08000(ALL)01/96]
RWARNING
Do not let the reservoir for the master cylinder run dry.
This may cause the brakes to fail.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
281
%*
[MC08100(ALL)02/96]
Windshield Washer Fluid
%*
[MC08200(ALL)03/96]
Washer Fluid
[MC08300(ALL)01/96]
Check the level of the windshield washer fluid every time you
stop for fuel. The reservoir for washer fluid is located on the
front, passenger side of the engine compartment. This reservoir
contains the fluid for both the windshield and liftgate washers.
*
[MC08400(ALL)01/96]
RWARNING
Do not put windshield washer fluid in the container for
the engine coolant.
[MC08500(ALL)01/96]
13-1/2 pica
art:0050050-B
Windshield washer fill location
%*
[MC08600(ALL)02/96
]
Use specially formulated windshield washer fluid rather than
plain water, because specially formulated washer fluids contain
additives that dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such as methanol
should be used in freezing weather (temperatures below32ÊF
[0ÊC]). State or local regulations on Volatile Organic Compounds
(VOCs) may restrict use of the most common antifreeze,
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

282methanol. Washer fluids containing non-methanol antifreeze
agents should be used only if they provide cold weather
protection without damaging the vehicle's paint finish, wiper
blades, and windshield washer system.
*
[MC08700(ALL)03/96]
RWARNING
Windshield washer fluid contains methanol which is
poisonous.
[MC08800(ALL)01/96]
When adding windshield washer solution, be sure to observe all
warnings indicated on the washer solution container.
%*
[MC08900(ALL)01/96]
Engine Coolant
%*
[MC09000(ALL)01/96]
Checking the Engine Coolant
[MC09100(ALL)01/96]
Your vehicle's engine coolant protects the engine from
overheating in the summer and from freezing in the winter.
Check the level of the engine coolant at least once a month, but
preferably each time you stop for fuel. Simply check the coolant
reservoir, located in the engine compartment. The coolant
should stay slightly above the ºFULL COLDª mark.
*
[MC09200(ALL)05/96]
Adding Engine Coolant
*
[MC09300(ALL)05/96]
RWARNING
Do not put engine coolant in the container for the
windshield washer fluid.
*
[MC09400(ALL)05/96]
If sprayed to clean the glass, engine coolant or antifreeze could
make it difficult to see through the windshield.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

292
*
[MC15700(ALL)01/96]
7-1/2 pica art:0040201-A
Battery recycling symbol
*
[MC15800(ALL)02/96]
RWARNING
The gases around the battery can explode if exposed to
flames, sparks, or lit cigarettes. An explosion could result
in injury or vehicle damage.
%*
[MC15900(ALL)05/96
]
RWARNING
Batteries contain sulfuric acid which burns skin, eyes,
and clothing.
*
[MC16000(ALL)02/96]
If the acid touches someone's skin, eyes, or clothing,
immediately flush the area with water for at least 15 minutes. If
someone swallows the acid, have him or her drink lots of milk
or water first, then Milk of Magnesia, a beaten egg, or vegetable
oil. Call a doctor immediately.
%*
[MC16100(ALL)02/96
]
RWARNING
Applying too much pressure on the ends when lifting a
battery could cause acid to spill. Lift the battery with a
carrier or with your hands on the opposite corners.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

294
*
[MC17200(ALL)08/95]3.
Attach a new wiper blade to the wiper arm and press it into
place until you hear it click.
%*
[MC17300(ALL)01/96]
Tires
[MC17400(ALL)04/96]
Look at your tires each time you fill your fuel tank. If one tire
looks lower than the others, check the pressure in all of them.
[MC17500(ALL)01/96]
n
Keep your tires inflated to the recommended pressures. See
Checking the pressure of the tireslater in this chapter.
*
[MC17600(ALL)01/96]
n
Stay within the recommended load limits. SeeDriving with a
heavy loadin the Index.
*
[MC17700(ALL)03/96]
n
Make sure the weight of your load is evenly distributed.
*
[MC17800(ALL)03/96]
n
Adjust tire pressure to recommended specifications found on
the Safety Compliance Certification Label.
*
[MC17900(ALL)03/96]
If you do not take these precautions, your tires may fail or go
flat.
*
[MC18000(ALL)01/96]
RWARNING
Always obey posted speed limits. If you drive too fast
for road conditions, you could lose control of your
vehicle. Under some circumstances, driving at very high
speeds for extended periods of time may damage vehicle
components, creating a risk of component failure and a
potential loss of vehicle control. Any time you lose
control of your vehicle, it may result in injury.
[MC18100(ALL)01/96]
At least once a month, check the pressure in all your tires,
including the spare. Use an accurate tire pressure gauge. Check
the tire pressure when tires are cold, that is, after the vehicle
has been parked for at least one hour or has been driven less
than 3 miles (5 km). You can find the proper cold tire pressure
on the Safety Compliance Certification Label located on the
driver's door pillar.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
295
*
[MC18200(ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle handling and
can fail suddenly, possibly resulting in loss of vehicle
control.
%*
[MC18300(ALL)01/96]
Tire Rotation
*
[MC18400(ALL)01/96]
Because your vehicle's front and rear tires perform different
jobs, they often wear differently. To make sure your tires wear
evenly and last longer, rotate them as indicated in the following
diagram.
[MC18500(ALL)01/96]
10-1/2 pica
art:0050224-A
Rotating the tires
*
[MC18600(ALL)01/96]
If your vehicle has the optional full-size spare tire, you may
rotate the spare tire into the rotation pattern.
[MC18700(ALL)01/96]
If your vehicle has aluminum wheels, you may remove the
full-size (if equipped) spare tire from the wheel and remount it
on an aluminum wheel to rotate the spare tire into your
vehicle's rotation pattern.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

296
%*
[MC18800(ALL)01/96]
Replacing the Tires
*
[MC18900(ALL)01/96]
Replace tires that show wear bands. When your tire shows a
wear band, it has only 1/16 of an inch (1.59 mm) of tread left.
*
[MC19000(ALL)01/96]
7-1/2 pica art:0040200-A
A worn-out tire
*
[MC19100(ALL)02/96]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread.
*
[MC19200(ALL)01/96]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
*
[MC19300(ALL)03/96]
RWARNING
Make sure that all replacement tires are of the same size,
type, load-carrying capacity, and tread design (e.g. ºAll
Terrainª, etc.), as originally offered by Ford.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996
