1997 TOYOTA TACOMA Owners Manual

208
ENGINE LUBRICATION Oil capacity (drain and refill), L (qt., Imp. qt.):
Two-wheel drive models 2RZ-FE engine
With filter 5.5 (5.8, 4.8)
Without filter 4.8 (5.0, 4.2)
5VZ-FE engine
With filter 5.4 (5.7, 4.8)
Without filter 5.1 (5.4, 4.5)
Four-wheel drive models 3RZ-FE engine
With filter 5.4 (5.7, 4.8)
Without filter 4.7 (5.0, 4.1)
5VZ-FE engine With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
Oil grade:
API SH, Energy-Conserving IIº multi-
grade engine oil or ILSAC multigrade en-
gine oil is recommended. Recommended oil viscosity (SAE):
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Two-wheel drive models With manual transmission
2RZ-FE engine
8.0 (8.5, 7.0)
5VZ-FE engine 9.7 (10.3, 8.5)
With automatic transmission
2RZ-FE engine 7.8 (8.2, 6.9)
5VZ-FE engine 9.5 (10.0, 8.4) Four-wheel drive models With manual transmission
3RZ-FE engine
8.3 (8.8, 7.3)
5VZ-FE engine 10.1 (10.7, 8.9)
With automatic transmission
3RZ-FE engine 8.2 (8.7, 7.2)
5VZ-FE engine 10.0 (10.5, 8.8)
Coolant type: With ethylene-glycol antifreeze (Do not use alcohol type.)
BATTERY Open voltage* at 20 C (68 F):
12.7 V Fully charged 12.3 V Half charged
11.9 V Discharged
*Voltage that is checked 20 minutes after
the key is removed with all the lights
turned off Charging rates: 5 A max.

209
CLUTCH
Pedal freeplay, mm (in.):
5' 15 (0.2 '0.6)
Fluid type: SAE J1703 or FMVSS No. 116 DOT 3
MANUAL TRANSAXLE
Oil capacity, L (qt., Imp. qt.):
2RZ-FE engine 2.6 (2.7, 2.3)
3RZ-FE engine 2.5 (2.6, 2.2)
5VZ-FE engine
Two-wheel drive models 2.6 (2.7, 2.3)
Four-wheel drive models 2.2 (2.3, 1.9)
Oil type:
Multipurpose gear oil API GL-4 or GL-5
Recommended oil viscosity:
SAE 75W-90 AUTOMATIC TRANSMISSION Fluid capacity (drain and refill), L (qt., Imp. qt.):
Two-wheel drive models 2RZ-FE engine
Up to 2.4 (2.5 2.1)
5VZ-FE engine Up to 1.6 (1.7, 1.4)
Four-wheel drive models Up to 2.0 (2.1, 1.8)
Fluid type:
Automatic transmission fluid D-II or DEXRON [
III (DEXRON [
II)
TRANSFER
Oil capacity, L (qt., lmp. qt.): 1.0 (1.1, 0.9)
Oil type: Multipurpose gear oil API GL-4 or
GL-5 Recommended oil viscosity: SAE 75W-90 DIFFERENTIAL
Oil capacity, L (qt., lmp. qt.):
Two-wheel drive models
2RZ-FE engine 1.35 (1.4, 1.2)
5VZ-FE engine 2.55 (2.7, 2.2)
Four-wheel drive models Front A.D.D. 1.15 (1.2, 1.0)
Except A.D.D. 1.1 (1.2, 1.0)
Rear Short wheel base
With rear differential lock system 2.65 (2.8, 2.3)
Without rear differential lock system 2.55 (2.7, 2.2)
Extra long wheel base
With rear differential lock system 2.95 (3.1, 2.6)
Without rear differential lock system 2.05 (2.2, 1.8)
Oil type: Hypoid gear oil API GL-5

210
Recommended oil viscosity:
Front A.D.D.
SAE 75W-90
Except A.D.D. Above -18 C (0 F)
SAE 90
Below -18 C (0 F)
SAE 80W or 80W-90
Rear Above -18 C (0 F)
SAE 90
Below -18 C (0 F)
SAE 80W or 80W-90 CHASSIS LUBRICATION Wheel bearings:
Lithium base wheel bearing grease, NLGI No. 2
Front drive shaft thrust bushings:
Synthetic oil and lithium soap basechassis grease, NLGI No. 1
Propeller shafts:
SpidersLithium base chassis grease, NLGI No. 2
Slide youke and double cardan joint
Molybdenum-disulfide lithiumbase chassis grease, NLGI No. 2
BRAKES Minimum pedal clearance when de- pressed with the pressure of 490 N (50
kgf, 110 lbf) with the engine running, mm(in.): 72 (2.8)
Pedal freeplay, mm (in.):
3' 6 (0.12 '0.24)
Pad wear limit, mm (in.):
1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with the force of 196 N (20 kgf, 44 lbf):
12'18 clicks
Fluid type:
SAE J1703 or FMVSS No. 116 DOT 3 STEERING Wheel freeplay:
Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON [
II or III

211
Engine compartment (U.S.A.) Fuses (type A)
1. STOP 15 A: Stop lights, high-
mounted stoplight, cruise control sys- tem
2. ALT-S 7.5 A: Charging system
3. STA 7.5 A: Multiport fuel injction sys-
tem/sequential multiport fuel injection
system, starting system, gauges and meters
4. OBD 10 A: On-board diagnosis sys-
tem
5. EFI 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection system
P195/75R14 200 (2.0, 29) 240 (2.4, 35) 14 x 5J
P215/70R14 200 (2.0, 29) 200 (2.0, 29) 14 x 6J
14 x 6JJ
P225/75R15 180 (1.8, 26) 200 (2.0, 29) 15 x 6J 15 x 7JJ
31x10.5R15LT 180 (1.8, 26) 200 (2.0, 29) 15 x 7JJ) Tire size
Tire pressure
kPa (kgf/cm 2
or bar, psi)
Front RearWheel size
Wheel nut torque, N
m (kg fm, ft lbf):
110 (11.5, 83)
Tires
Fuses

212
Engine compartment (Canada)
6. HORN 15 A: Emergency flashers,
horns
7. DOME 15 A: Car audio system, power
antenna, interior light, clock, ignition
switch light, personal ligths, door cour-
tesy lights
8. TAIL 10 A: Tail lights, license plate
lights
9. PANEL 10 A: Emergency flashers,
heater cotnrol system, air conditioning
cooling system, gauges and meters,
clock, car audio system overdrive indi-
cator light, glovebox light, cigarette
lighter, instrument panel lightsInstrument panel
10. A/C 10 A: Air conditionin cooling sys-
tem
11. HEAD (RH) 10 A: Right-hand head-
light
12. HEAD (LH) 10 A: Left-hand headlight
13. HEAD (HI RH) 10 A: Right-hand
headlight (high beam), hi-beam indi-
cator light
14. HEAD (HI LH) 10 A: Left-hand head-
light (high beam)
15. HEAD (LO RH) 10 A: Right-hand
headlight (low beam)
16. HEAD (LO LH) 10 A: Left-hand head-
light (low beam) 17. DRL 7.5 A:
Daytime running light sys-
tem
18. 4WD 15 A: A.D.D. control system,
four-wheel drive control system, rear
differential lock system
19. GAUGE 10 A: Gauges and meters,
back-up lights, cruise control system,
power antenna, power door lock con- trol system, electronically controlled
automatic transmission system, start-
ing system, charging system, heater control system
20. TURN 10 A: Turn signal lights
21. ECU-IG 15 A: Cruise control system,
anti-lock brake system, shift lock sys-tem
22. WIPER 20 A: Windshield wipers and
washer
23. IGN 7.5 A: Discharge warning light,
SRS airbag system
24. RADIO 7.5 A: Car audio system, pow-
er antenna
25. CIG 15 A: Cigarette lighter, clock,
power rear view mirrors, back-up lights, shift lock system
26. ECU-B 15 A: SRS airbag warning
light, daytime running light system, cruise control syste, anti-lock brake system

213
Fuses (type B)
27. HEATER 40 A:
A.Cº fuse
28.AM1 40 A: All components in STAº,
ECU-Bº, POWERº' RADIOº, CIGº,
GAUGEº, TURNº, ECU-IGº, WIP- ERº and 4WDº fuses
29.AM2 30 A: All components in IGNº
fuse
30. POWER 30 A: Power windows, pow-
er door lock control system
Fuses (type C)
31. ABS 60 A: Anti-lock brake system
32. ALT 80 A: All components in ABSº,
AM1º, STAº, ECU-Bº, POWERº,
RADIOº, CIGº, GAUGEº, TURNº,
ECU-IGº, WIPERº, 4WDº, HEAT-
ERº, A/Cº, TAILº, PANELº, STOPº
and ALT-Sº fuse

214

Part 9Reporting safety defects for
U.S. ownersUniform tire quality grading
(except vehicles with 31 x
10.5R 15LT tires)
215
REPORTING SAFETY DEFECTS FOR U.S.OWNERS, UNIFORMTIRE GRADING AND CAMPER
INFORMATION
Reporting safety defects for
U.S. owners
Uniform tire quality grading
Camper information
If you believe that your vehicle has
a defect which could cause a crash
or could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Toyota Motor Sales,
U.S.A., Inc. (Toll-free: 1-800-331-4331).
If NHTSA receives similar
complaints, it may open a
investigation, and if it finds that asafety defect exists in a group of
vehicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved in
individual problems between you,
your dealer, or Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may either
call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123
in Washington D.C. area) or w
rite to:
NHTSA. U.S. Department of
Transportation. Washington D.C.
20590. You can also obtain other
information about motor vehiclesafety from the Hotline. This
information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this information.
DOT quality gradesÐAll passenger
vehicle tires must conform to Federal
Safety Requirements in addition to these grades. These quality grades are
molded on the sidewall.
Treadwear ÐThe treadwear grade is a
comparative rating based on the wear
rate of the tire when tested under con-
trolled conditions on a specified govern-
ment test course. For example, a tire
graded 150 would wear one and a half
(1-1/2) times as well on the government course as a tire graded 100. The relative
performance of tires depends upon the
actual conditions of their use, however,
and may depart significantly from the norm due to variations in driving habits,
service practices and differences in road characteristics and climate.
