1997 TOYOTA TACOMA Owners Manual

104
Air Intake selector Move the lever to select the air source.
1. RecirculateÐRecirculates the air in-
side the vehicle.
2. FreshÐ Draws outside air into the sys-
tem. A/Cº button
To turn on the air conditioning, press the
A/Cº button. The A/Cº button indicator
will come on. To turn the air conditioning
off, press the button again.
If the A/Cº button indicator flashes, there
is a problem in the air conditioning system
and the air conditioning automatically
shuts off. If this happens, take your ve-
hicle to a Toyota dealer for service.

105

To cool off your Toyota after it has been
parked in the hot sun, drive with the
windows open for a few minutes. This
vents the hot air, allowing the air condi-
tioning to cool the interior more quickly.
Make sure the air intake g rilles in front
of the windshield are not blocked (by
leaves or snow, for example).
On humid days, do not blow cold air on
the windshield. The windshield could
fog up because of the difference in airtemperature on the inside and outside
of the windshield.
Keep the area under the front seats
clear to allow air to circulate through-out the vehicle.
On cold days, move the fan speed to
HIº for a minute to help clear the in-
take ducts of snow or moisture. This
can reduce the amount of fogging onthe windows.
ÐAir flow selector settings
-Operating tips

106Heating
For best results, set controls to:
Fan speed ÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone)
Air intake ÐFRESH (outside air)
Air flowÐFLOOR Air conditioning ÐOFF
For quick heating, select recirculated
air for a few minutes. To keep the win-
dows from fogging, select fresh after the vehicle interior has been warmed.
Press the A/Cº button on for dehumid-
ified heating.
Choose floor/windshield air flow to heat the vehicle interior while defrost- ing or defogging the windshield. Air conditioning For best results, set controls to:
Fan speed ÐAny setting except OFFº
Temperature Ð Towards COLD
(blue zone)
Air intake ÐFRESH (outside air)
Air flow ÐPANEL
Air conditioning ÐON For quick cooling, move the air intake
selector to recirculate for a few min-utes.
Ventilation
For best results, set controls to:
Fan speed ÐAny setting except OFFº
Temperature Ð Towards COLD
(blue zone)
Air intake ÐFRESH (outside air)
Air flow ÐPANEL
Air conditioning ÐOFF
Defogging The inside of the windshield For best results, set controls to:
Fan speed ÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone) to heat; COLD (blue zone) to
cool
Air intake ÐFRESH (outside air)
Air flow ÐWINDSHIELD
Vehicles withA/Cº button-
Moving the air flow selector lever to the windshield position turns on the defrost-
er-linked air conditioning. At this time, the
A/Cº button indicator comes on regard-less of whether or not the A/Cº button ispressed in. This is to clear up the front
view more quickly. When the A/Cº button is not pressed in,
turning the air flow selector lever to anoth-
er position turns off the air conditioning. On humid days, do not blow cold air on
the windshieldÐthe difference be-tween the outside and inside tempera-
tures could make the fogging worse.

107
Defrosting The outside of the windshield For best results, set controls to:
Fan speed ÐAny setting except OFFº
Temperature ÐTowards WARM
(red zone)
Air intake ÐFRESH (outside air)
Air flow ÐWINDSHIELD
Vehicles with A/Cº buttonÐ
Moving the air flow selector to the wind-
shield position turns on the defroster-
linked air conditioning. At this time, the
A/Cº button indicator comes on regard-less of whether or not the A/Cº button is pressed in. This is to clear up the front
view more quickly. When the A/Cº button is not pressed in,
moving the air flow selector lever to anoth-
er position turns off the air conditioning. To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.
If air flow control is not satisfactory, check
the side vents. The side vents may be
opened or closed as shown.
ÐSide vents

108

Part 1Clock
109
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-8 Other equipment
Clock
Cigarette lighter and ashtray
Glovebox
Cup holder
Floor mat
The digital clock indicates the time.
The key must be in the ``ACCº or ``ON'' position.
To reset the hour: Push the Hº button.
To reset the minutes: Push the Mº button.
If quick adjustment to a full hour is de- sired, push the :00º button. When the instrument panel lights are turned
on, the brightness of the time indi-
cation will be reduced.
For example, if the :00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the time
will change to 2:00. Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (oneo'clock). When the instrument panel lights turned
on, the brightness of the time indication
will be reduced.

11 0
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automati-
cally pops out ready for use.
If the engine is not running, the key must be in the ACCº position.
Do not hold the cigarette lighter pressed in.
Use a Toyota genuine cigarette lighter or equivalent for replacement.ASHTRAY
To use the ashtray, pull it out. When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the
ashtray, close the ash-
tray cover completely.
To remove the ashtray, press down on the lock spring plate and pull out.To reduce the chance of injury in
case of an accident or sudden stop
while driving, always close the ash-
tray cover completely after use. CAUTION
!
To open the glovebox door, pull the le- ver
.
On some models, the glovebox light will come on when the glovebox is open withthe instrument panel lights on.
To reduce the chance of injury in
case of an accident or sudden stop,
always keep the glovebox door
closed while driving. CAUTION
!
Cigarette lighter and ashtray
Glovebox

111
The cup holder is designed for holding
cups or drinkÐcans fit snugly in its holes.
To use the cup holder, pull it out.
Do not place anything else on the
cup holder, as such items may be
thrown about and possible injure people in the vehicle during sud-
den braking or accident.
Keep the cup holder shut when not
in use.
CAUTION!
The cup holder is designed for holding
cups fit snugly in its holes.
To use the cup holder, raise the folding
table under the right-rear seat. Stand the
table by compressing and turning down the table legs.
Do not place anything else on the
cup holder, as such item may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or
an accident.
Keep the cup holder shut when not
in use.
CAUTION!
Cup holder (all models) Cup holder (Xtra-cab models)
