1997 NISSAN PATHFINDER Owners Manual

1. Turn the key counterclockwise to unlock the
back door.
2. Pull the opener handle to open the back
door.
3. To lock the back door, push it down firmly
and turn the key clockwise.
IAlways check the back door has been
closed securely to prevent it from
opening while driving.
IDo not drive with the back door open.This could allow dangerous exhaust
gases to be drawn into the vehicle.
See ªExhaust gasº in the ªStarting
and drivingº section.
To open the rear window, turn the key fully
clockwise and pull the opener handle. To
close, lower and push the rear window down
securely.
Do not drive with the rear window open.
This could allow dangerous exhaust
gases to be drawn into the vehicle. See
ªExhaust gasº in the ªStarting and driv-
ingº section.
SPA0462SPA0338
BACK DOOR LOCKS REAR WINDOW LOCKS
2-8
Z01.2.1/R50-DX

Do not open the rear window unless the
wiper is in the stowed position.
1. Pull the hood lock release handle located
below the instrument panel; the hood will
then spring up slightly.
2. Raise the lever at the front of the hood with
your fingertips and raise the hood.3. Insert the assist bar into the slot in the front
edge of the hood.
4. When closing the hood, reset the assist bar
to its original position, then slowly close the
hood and make sure it locks into place.
IMake sure the hood is completely
closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.
IIf you see steam or smoke coming
SPA0387
HOOD RELEASE
2-9
Z01.2.1/R50-DX

from the engine compartment, to
avoid injury, do not open the hood.
The glove box may be opened by turning the
key as shown.
Keep glove box lid closed while driving
to prevent injury in an accident or during
a sudden stop.
Opener lever
To open the fuel filler lid, push the opener lever
down. To lock, close the fuel filler lid securely.
SPA0388
SPA0389
GLOVE BOX LOCK FUEL FILLER LID LOCK
2-10
Z01.2.1/R50-DX

The fuel filler cap is a screw-on ratcheting
type. Tighten the cap clockwise until ratcheting
clicks are heard.
IGasoline is extremely flammable and
highly explosive under certain condi-
tions. You could be burned or seri-
ously injured if it is misused or mis-
handled. Always stop the engine and
do not smoke or allow open flames or
sparks near the vehicle when refuel-
ing.IFuel may be under pressure. Turn the
cap one-half turn and wait for any
ªhissingº sound to stop, to prevent
fuel from spraying out and possible
personal injury. Then remove the cap.
IUse only a genuine NISSAN fuel filler
cap as a replacement. It has a built-in
safety valve needed for proper opera-
tion of the fuel system and emission
control system. An incorrect cap can
result in a serious malfunction and
possible injury.
If fuel is spilled on the vehicle body,
flush it away with water to avoid paint
damage.
If the fuel filler cap is not tightened prop-
erly, the Malfunction indicator light (MIL)
may come on.Put the fuel filler cap on the cap holder while
refueling.
SPA0341SPA0342
FUEL FILLER CAP
2-11
Z01.2.1/R50-DX

Do not ride in a moving vehicle when the
seatback is reclined. This can be dan-
gerous. The shoulder belt will not be
against your body. In an accident you
could be thrown into it and receive neck
or other serious injuries. You could also
slide under the lap belt and receive se-
rious internal injuries.
For most effective protection when the
vehicle is in motion, the seat should be
upright. Always sit well back in the seat
and adjust the seat belt properly. See
ªPrecautions on seat belt usageº later in
this chapter.
SEAT ADJUSTMENT
IDo not adjust the driver's seat while
driving. The seat may move suddenly
and could cause loss of control of the
vehicle.
IAfter adjustment, gently rock in the
seat to make sure it is securely
locked.
SPA0472SPA0473
FRONT SEATS
2-12
Z01.2.1/R50-DX

Forward and backward
Pull the lever up while you slide the seat
forward or backward to the desired position.
Release the lever to lock the seat in position.
Reclining
To recline the seatback, pull the lever up and
lean back. To bring the seatback forward
again, pull the lever and move your body
forward. The seatback will move forward.
Seat lifter (Driver's seat)
Turn either dial to adjust the angle and height
of the seat cushion to the desired position.
SPA0097SPA0099
2-13
Z01.2.1/R50-DX

POWER SUPPORT SEAT
IDo not adjust the driver's seat while
driving in order that full attention may
be given to the driving operations.
IDo not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches and controls.
Operating tips
IThe motor has an auto-reset overload pro-
tection circuit. If the motor stops during
operation, wait 30 seconds, then reactivate
the switch.
IDo not operate the power support seat
for a long period of time when the engine is
off. This will discharge the battery.
Forward and backward
Moving the switch forward or backward will
slide the seat forward or backward to the
desired position.
Reclining
Move the recline switch backward until the
desired angle is obtained. To bring the seat
back forward again, move the switch forward
and move your body forward. The seat back
will move forward.
SPA0463
2-14
Z01.2.1/R50-DX

Seat lifter (Driver's seat)
Push the front or rear end of the switch up or
down to adjust the angle and height of the seat
cushion.
Lumbar support (Driver's seat)
Turn the lever forward or backward to adjust
the seat lumbar area.
HEAD RESTRAINT
Head restraints should be adjusted
properly as they may provide significant
protection against injury in an accident.
Do not remove them. Check the adjust-
ment after someone else uses the seat.
Adjust the top of the head restraints level with
the top of your ears.
To raise the head restraint, just pull it up. To
SPA0464SPA0465SPA0014
2-15
Z01.2.1/R50-DX
