1997 NISSAN PATHFINDER Owners Manual

Be sure the ignition key is ªOFFº. The
engine could rotate unexpectedly.
1. Visually inspect each belt for signs of un-
usual wear, cuts, fraying or looseness. If
the belt is in poor condition or loose, have it
replaced or adjusted by your NISSAN
dealer.2. Have the belts checked regularly for condi-
tion and tension in accordance with the
maintenance schedule in this manual.
Be sure the engine and ignition switch
are off and that the parking brake is
engaged securely.
1. Disconnect spark plug cables. Keep track
of the original cable location.
When disconnecting, always hold the
boots Ð not the cables. Mark all cables to
identify their original location.
SDI0424DI0064
DRIVE BELTS SPARK PLUG REPLACEMENT
7-14
Z01.2.1/R50-DX

2. Remove spark plugs with a spark plug
wrench. (Type A or B)
Be sure to use the correct wrench to
remove the plugs. An incorrect wrench
can cause damage.
3. Check each new spark plug gap with a
feeler gauge. Correct it as required.
4. Install spark plugs.
When installing a plug, turn it in two or
three turns by hand and then tighten with a
spark plug wrench. Be careful not to over-
tighten it.
Tightening torque:
14 to 22 ft-lb (20 to 29 N×m)
5. Reconnect the spark plug cables to their
original positions.
SDI0392SDI0390
SDI0391
DI0065
7-15
Z01.2.1/R50-DX

The filter element should not be cleaned and
reused as it is given a special treatment. We
recommended it be replaced according to the
maintenance intervals shown in the ªMainte-
nance scheduleº section. When replacing the
filter, wipe the inside of the air cleaner housing
and the cover with a damp cloth.
Operating the engine with the air cleaner
off can cause you or others to be
burned. The air cleaner not only cleans
the air, it stops flame if the engine back-fires. If it is not there, and the engine
backfires, you could be burned. Do not
drive with it off, and be careful working
on the engine with the air cleaner off.
SDI0393
AIR CLEANER FILTER
7-16
Z01.2.1/R50-DX

1) CLEANING
If your windshield is not clear after using the
windshield washer of if a wiper blade chat-
ters when running, wax or other material
may be on the blade or windshield.
Clean the outside of the windshield with a
washer solution or a mild detergent. Your
windshield is clean if beads do not form
when rinsing with clear water.
Clean the blade by wiping it with a cloth
soaked in a washer solution or a mild
detergent. Then rinse the blade with clear
water. If your windshield is still not clearafter cleaning the blades and using the
wiper, replace the blades.
2) REPLACEMENT
1. Pull the wiper arm.
2. Push the lock pin, then remove the wiper
blade.
3. Insert the new wiper blade to the wiper arm
until a click sounds.
After wiper blade replacement, return
the wiper arm to its original position.
Otherwise it may be damaged when the
engine hood is opened.
Make sure the wiper blade contacts the
glass. Otherwise, the arm may be dam-
aged from wind pressure.
DI0155MA
WIPER BLADE
7-17
Z01.2.1/R50-DX

If you wax the surface of the hood, be
careful not to let wax get into the washer
nozzle. This may cause clogging or im-
proper windshield washer operation. If wax
gets into the nozzle, remove it with a needle
or small pin.Pull the parking brake lever up. If the number
of clicks is out of the range as listed above, see
your NISSAN dealer.With the engine running, check distance A
between the upper surface of the pedal and
the dash lower panel.
Distance A
M/T models
2-1/2 in (65 mm) or more
A/T models
2-3/4 in (70 mm) or more
If it is out of the range shown above, see your
NISSAN dealer.
SDI0425
DI1010-CDI0453
PARKING BRAKE BRAKE PEDAL
7-18
Z01.2.1/R50-DX

Self-adjusting brakes
Your vehicle is equipped with self-adjusting
brakes.
The front disc-type brakes self-adjust every
time the brake pedal is applied. The rear
drum-type brakes self-adjust every time the
parking brake is applied. If the brake pedal
goes down farther than normal, it may be due
to a lack of adjustment of the rear drum
brakes. Apply the parking brake several times.
See your NISSAN dealer and have it
checked if the brake pedal height does
not return to normal.
Brake pad wear indicators
The disc brake pads on your vehicle have
audible wear indicators. When a brake pad
requires replacement, it will make a high
pitched scraping or screeching sound when
the vehicle is in motion whether or not the
brake pedal is depressed. Have the brakes
checked as soon as possible if the wear indi-
cator sound is heard.
Under some driving or climate conditions, oc-casional brake squeak, squeal or other noise
may be heard. Occasional brake noise during
light to moderate stops is normal and does not
affect the function or performance of the brake
system.
The rear drum brakes (if so equipped) do not
have audible wear indicators. Should you ever
hear an unusually loud noise from the rear
drum brakes, have them inspected as soon as
possible by your NISSAN dealer.
Proper brake inspection intervals should
be followed.For more information regarding
brake inspections, see the appropriate main-
tenance schedule information in the ªMainte-
nance Scheduleº section of this manual.Check the brake booster function with the
following steps:
1. With the engine off, press and release the
brake pedal several times. When brake
pedal movement (distance of travel) re-
mains the same from one pedal application
to the next, continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a
little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without
depressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradu-
ally with each depression as the vacuum is
released from the booster.
If the brakes do not operate properly, have the
brake checked by your NISSAN dealer.
BRAKE BOOSTER
7-19
Z01.2.1/R50-DX

Press the pedal by hand and be sure the free
travel is within the above limit. If free travel is
out of the range shown above, see your
NISSAN dealer.Engine compartment (Headlight
fuses)
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.1. Be sure the ignition key and the headlight
switch are ªOFFº.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse opens again, have the elec-
trical system checked and repaired by your
NISSAN dealer.
DI0070-BSDI0395
CLUTCH PEDAL FUSES
7-20
Z01.2.1/R50-DX

Passenger compartment
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are ªOFFº.2. Pull to open the fuse box cover/coin tray.
3. Pull the fuse box cover/coin tray horizon-
tally to remove it.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse opens again, have the elec-
trical system checked and repaired by your
NISSAN dealer.
HEADLIGHTS
Semi-sealed beam type
The headlight is a semi-sealed beam type
which uses a replaceable headlight (halogen)
bulb. A bulb can be replaced inside the engine
compartment without removing the headlight
assembly.
High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
SDI0447DI0156
LIGHT BULBS
7-21
Z01.2.1/R50-DX
