1997 NISSAN PATHFINDER Owners Manual

Cooling
This mode is used to cool and dehumidify.
1. Push the air recirculation button OFF.
2. Turn the air control dial to the ª
º posi-
tion.
3. (Manual mode)
Turn on the fan control dial (1 to 3).
(Auto mode)
Turn the fan control dial to the AUTO
position.
IThe fan speed will be maintained automati-
cally.
4. Push the air conditioner button on. The
indicator light will come on.
5. Turn the temperature control dial to set the
desired temperature.
IAdjust the temperature control dial to about
75ÉF (24ÉC) for normal operation.
IThe temperature will be maintained auto-
matically.
IFor quick cooling when the outside tem-
perature is high, push the air recirculation
button on. Be sure to turn off the air recir-
culation button for normal cooling.
Dehumidified heating
This mode is used to heat and dehumidify.
1. Push the air recirculation button OFF.
2. Turn the air control dial to the ª
º posi-
tion.
3. (Manual mode)
Turn on the fan control dial (1 to 3).
(Auto mode)
Turn the fan control dial to the AUTO
position.
IThe fan speed will be maintained automati-
cally.
4. Push on the air conditioner button. The
indicator light will come on.
5. Turn the temperature control dial to set the
desired temperature.
IAdjust the temperature control dial to about
75ÉF (24ÉC) for normal operation.
IThe temperature will be maintained auto-
matically.
Dehumidified defogging
This mode is used to defog the windows and
dehumidify.1. Push the air recirculation button OFF to
improve the defogging performance.
2. Turn the air control dial to the ª
º
position.
3. (Manual mode)
Turn on the fan control dial (1 to 3).
(Auto mode)
Turn the fan control dial to the AUTO
position.
4. Turn the temperature control dial to the
desired position.
Operating tips
IKeep windows and sun roof closed while
the air conditioner is in operation.
IAfter parking in the sun, drive for two or
three minutes with the windows open to
vent hot air from the passenger compart-
ment. Then, close the windows. This will
allow the air conditioner to cool the interior
more quickly.
IThe air conditioning system should be op-
erated for about ten minutes at least once a
month. This helps prevent damage to the
system due to lack of lubrication.
IIf the coolant temperature gauge exceeds
3-10
Z01.2.1/R50-DX

the ªHOTº position, turn the air conditioner
off. See ªIf your vehicle overheats ºin the ªIn
case of emergencyº section for additional
information.
IIf the engine coolant reaches an extremely
high temperature, the air conditioning sys-
tem will automatically turn off. This may
happen for example if the engine is run at
idle for a long time on a hot day.
AIR FLOW CHARTS
The following charts show the button and dial
positions forMAXIMUM AND QUICKheating,
cooling or defrosting.The air recirculation
switch should always be in the ªOFFº po-
sition for heating and defrosting.
3-11
Z01.2.1/R50-DX

SAA0154ASAA0155A
3-12
Z01.2.1/R50-DX

SAA0156ASAA0157A
3-13
Z01.2.1/R50-DX

The sensor on the instrument panel helps
maintain a constant temperature. Do not put
anything on or around this sensor.
Servicing air conditioner
The air conditioning system in your NISSAN
vehicle is charged with a refrigerant designed
with the environment in mind.
This refrigerant will not harm the earth's
ozone layer.
However, special charging equipment and lu-
bricant are required when servicing your
NISSAN air conditioner. Using improper refrig-
erants or lubricants will cause severe damage
to your air conditioning system. See ªAir Con-
ditioning system refrigerant and lubricant rec-
ommendationsº in the ªTechnical and con-
sumer informationº section of this manual.
Your NISSAN dealer will be able to service
your environmentally ªfriendlyº air conditioning
system.
SAA0158
3-14
Z01.2.1/R50-DX

To turn the radio on, turn the ignition key to
ªACCº or ªONº. If you listen to the radio with
the engine not running, turn the key to the
ªACCº position.
Radio reception is affected by station signal
strength, distance from radio transmitter, build-
ings, bridges, mountains, and other external
influences. Intermittent changes in reception
quality normally are caused by these external
influences.
AM-FM RADIO WITH COMPACT
DISC PLAYER
The electronic tuning radio has an FM Diver-
sity reception system, which employs two an-
tennas. One is a rod type antenna; the other is
an antenna printed on the window. This sys-
tem automatically switches to the antenna
which is receiving less noise.
Radio operation
Pushthe FM/AM button to listen to the radio
and tune in the desired station.
Pushing the FM/AM button while the com-pact disc is playing will turn off the com-
pact disc player and turn on the radio.
Turnthe ON.VOL knob to adjust the volume.
Clock set (Adjustment)
Depressing the ªCLOCKº and the ªº but-
tons together will set hours. Depressing the
ªCLOCKº and ª
º buttons together will set
minutes.
Clock operation
By pressing the ªCLOCKº button, you can
alternate the clock and the radio/cassette tape
options in the display.
SAA0247
RADIO
3-15
Z01.2.1/R50-DX

Clock priority mode
In this mode the clock will be shown in the
display. If any radio or CD functions are acti-
vated, the radio or CD display will illuminate for
ten seconds then return to the clock mode.
After clock adjustment, the radio is in the
clock priority mode.
Selecting the desired band
Push the AM/FM button to change from AM to
FM reception.
The FM stereo indicator ªSTº will glow during
FM stereo reception. When the stereo broad-
cast signal is weak, the radio will automatically
change from stereo to monaural reception.
Tuning
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.
Manual tuning
Push either side of the manual tuning button
ª
º.SCAN tuning
Push the SEEK/SCAN tuning button ª
º
for more than 1.5 seconds. SCAN tuning be-
gins from low to high frequencies and stops at
each broadcasting station for five seconds.
Pushing the button again during this five sec-
ond period will stop SCAN tuning and the radio
will remain tuned to that station.
SEEK tuning
Push the SEEK/SCAN tuning button ª
º
for less than 1.5 seconds. SEEK tuning begins
from low to high frequencies and stops at the
next broadcasting station.
Station memory operations
Six stations can be set for each band.
1. Tune to the desired station.
2. Push the desired select button for more
SAA0162
3-16
Z01.2.1/R50-DX

than 1.5 seconds. (For example in the
diagram ch2 is to be memorized. The radio
ceases emitting sounds when the select
button is pushed.)
3. The indicator, ªch2º will then come on and
the sound will resume.
Memorization is now complete.
4. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if the
fuse blows, the radio memory will be canceled.
In that case, reset the desired stations.
Adjusting tone quality and speaker
sound balance
To adjust BASS, TREB (treble), FADER, and
BAL (balance) the control knobs must be re-
leased from their stowed positions. Pushing
the knobs once moves them to the released
position.
In the released position, the knobs control tone
quality. Turn the control knobs to adjust BASS
and TREB to the most pleasing level.
From the released position, the knobs must be
pulled out in order to control FADER and BAL.
FADER adjusts the sound level between thefront and rear speakers, and BAL adjusts the
sound level between the right and left speak-
ers.
Once sound quality is set to the desired levels,
return the control knobs to the stowed position
by pushing them in completely and releasing.
SAA0185
