1997 NISSAN MAXIMA Owners Manual

1. Pull the hood lock release handleq1lo-
cated below the instrument panel; the hood
will then spring up slightly.
2. Pull the lever
q2at the front of the hood with
your fingertips and raise the hood.
3. When closing the hood, slowly close the
hood and make sure it locks into place.IMake sure the hood is completely
closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.
IIf you see steam or smoke coming
from the engine compartment, to
avoid injury, do not open the hood.
When locking or unlocking the glove box, use
the master key.
The glove box may be opened by pulling the
handle.
Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.
SPA0466SPA0092
HOOD RELEASE GLOVE BOX LOCK
2-8
Z01.2.1/A32-DX

Trunk lid release operation
Type A
The trunk lid release lever is located on the
outside of the driver's seat. To open the trunk
lid, pull up the trunk lid release lever. To close,push the trunk lid down securely.
Type B
The trunk lid release button is located under
the driver's arm rest.
To open the trunk lid, push the release button.
To close, push the trunk lid down securely.
Key operation
To open the trunk lid, turn the key clockwise.
To close, lower and push the trunk lid down
securely.
Do not drive with the trunk lid open. This
could allow dangerous exhaust gases to
be drawn into the vehicle. See ªExhaust
Gasº in the ªStarting and drivingº
section.SPA0093
SPA0094
TRUNK LID LOCK
2-9
Z01.2.1/A32-DX

OPENER CANCEL LEVER FOR
TRUNK LID
When the lever is in the ªCANCELº position,
the trunk lid cannot be opened with the trunk
lid release lever or handle. It can be opened
only with the key.
Opener lever
Type A
To open the fuel filler lid, pull the opener lever.
To lock, close the fuel filler lid securely.
Type B
To open the fuel filler lid, push the opener lever
down. To lock, close the fuel filler lid securely.
FUEL FILLER CAP
The fuel filler cap is a screw-on ratcheting
type. Tighten the cap clockwise until ratcheting
clicks are heard.
IGasoline is extremely flammable and
highly explosive under certain condi-
tions. You could be burned or seri-
ously injured if it is misused or mis-
handled. Always stop the engine and
do not smoke or allow open flames or
SPA0095SPA0096SPA0119
FUEL FILLER LID LOCK
2-10
Z01.2.1/A32-DX

sparks near the vehicle when refuel-
ing.
IFuel may be under pressure. Turn the
cap one-half turn and wait for any
ªhissingº sound to stop, to prevent
fuel from spraying out and possible
personal injury. Then remove the cap.
IUse only a genuine NISSAN fuel filler
cap as a replacement. It has a built-in
safety valve needed for proper opera-
tion of the fuel system and emission
control system. An incorrect cap can
result in a serious malfunction and
possible injury.
If fuel is spilled on the vehicle body,
flush it away with water to avoid paint
damage.
If the fuel filler cap is not tightened prop-
erly, the malfunction indicator light (MIL)
may come on.Put the fuel filler cap on the cap holder while
refueling.
SPA0120
2-11
Z01.2.1/A32-DX

IDo not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident
you could be thrown into it and re-
ceive neck or other serious injuries.
You could also slide under the lap
belt and receive serious internal
injuries.
IFor most effective protection when
the vehicle is in motion, the seat
should be upright. Always sit well
back in the seat and adjust the seat
belt properly. See ªPrecautions on
seat belt usageº later in this chapter.
SEAT ADJUSTMENT
IDo not adjust the driver's seat while
driving. The seat may move suddenly
and could cause loss of control of the
vehicle.
IAfter adjustment, gently rock in the
seat to make sure it is securely
locked.
SPA0472SPA0473
SEATS
2-12
Z01.2.1/A32-DX

Forward and backward
Pull the lever up while you slide the seat
forward or backward to the desired position.
Release the lever to lock the seat in position.
Reclining
To recline the seatback, pull the lever up and
lean back. To bring the seatback forward
again, pull the lever and move your body
forward. The seatback moves forward.
Seat lifter (Driver's seat)
Turn either dial to adjust the angle and height
of the seat cushion to the desired position.
SPA0097SPA0099
2-13
Z01.2.1/A32-DX

POWER SUPPORT SEAT (If so
equipped)
IDo not adjust the driver's seat while
driving in order that full attention may
be given to the driving operations.
IDo not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls.
Unattended children could become
involved in serious accidents.
Operating tips
IThe motor has an auto-reset overload pro-
tection circuit. If the motor stops during
operation, wait 30 seconds, then reactivate
the switch.
IDo not operate the power support seat
for a long period of time when the engine is
off. This will discharge the battery.
Forward and backward
Moving the switch forward or backward will
slide the seat forward or backward to the
desired position.
Reclining
Move the recline switch backward until the
desired angle is obtained. To bring the seat-
back forward again, move the switch forward
and move your body forward. The seatback
will move forward.
SPA0098
2-14
Z01.2.1/A32-DX

Seat lifter (Driver's seat)
Push the front or rear end of the switch up or
down to adjust the angle and height of the seat
cushion.
Lumbar support (Driver's seat)
Turn the lever forward or backward to adjust
the seat lumbar area.
HEAD RESTRAINT
To raise the head restraint, just pull it up. To
lower, push the lock knob and push the head
restraint down.
Adjust the top of the head restraints level with
the top of your ears.
Head restraints should be adjusted
properly as they may provide significant
protection against injury in an accident.
Do not remove them. Check the adjust-
SPA0100SPA0467SPA0014
