1997 NISSAN MAXIMA Owners Manual

Be careful not to burn yourself, as the
engine oil may be hot.
4. Wipe the engine oil filter mounting surface
with a clean rag.
Be sure to remove any old rubber gasket
remaining on the mounting surface of the
engine.
5. Coat the rubber gasket on the new filter
with clean engine oil.
6. Screw in the oil filter until a slight resistance
is felt, then tighten additionally more than
2/3 turn.
Oil filter tightening torque:
10.85 to 15.19 ft-lb
(14.7 to 20.6 N×m)
7. Start the engine and check for leakage
around the oil filter. Correct as required.
8. Turn the engine off and wait several min-
utes. Check the oil level. Add engine oil if
necessary.
IWhen engine is running, keep hands,
jewelry and clothing away from any
moving parts such as cooling fan and
drive belt.
IAutomatic transmission fluid is poi-
sonous and should be stored care-
fully in marked containers out of the
reach of children.
TEMPERATURE CONDITIONS
FOR CHECKING
IThe fluid level should be checked using the
ªHOTº range on the dipstick after the follow-
ing conditions have been met:
Ð The engine should be warmed up to oper-
ating temperature.
Ð The vehicle should be driven at least 5
minutes.
Ð The automatic transmission fluid should be
warmed to between 122 and 176ÉF (50 and
80ÉC).
IThe fluid can be checked at fluid tempera-
tures of 86 to 122ÉF (30 to 50ÉC) using the
ªCOLDº range on the dipstick after the
engine is warmed up and before driving.
However, the fluid should be re-checked
using the ªHOTº range.
1. Park the vehicle on a level surface and set
the parking brake.
2. Start the engine and then move the selector
lever through each gear range. Move the
shift lever to ªPº after you have moved it
through all ranges.
SDI0117
AUTOMATIC TRANSMISSION
FLUID
7-10
Z01.2.1/A32-DX

3. Check the fluid level with the engine idling.
4. Remove the dipstick and wipe it clean with
lint-free paper.
5. Reinsert the dipstick into the charging pipe
as far as it will go.
6. Remove the dipstick and note the reading.
If the level is at the low side of either range,
add fluid to the charging pipe.
IDO NOT OVERFILL.
IUSE ONLY NISSAN Matic ªDº (Conti-
nental U.S. and Alaska) or Genuine
NISSAN Automatic Transmission
Fluid (Canada). Dexron
TMIII/MerconTM
or equivalent may also be used. Out-
side the continental United States
and Alaska contact a NISSAN dealer
for more information regarding suit-
able fluids, including recommended
brand(s) of Dexron
TMIII/MerconTMor
DexronTMIIE/MerconTMAutomatic
Transmission Fluid.
NOTE:
If the vehicle has been driven for a long
time at high speeds, or in city traffic in hot
weather, or if it is being used to pull a
trailer, the accurate fluid level cannot be
read. You should wait until the fluid has
cooled down (about 30 minutes).Check the fluid level in the reservoir tank.
The fluid level should be checked using the
ªHOTº range at fluid temperatures of 122 to
176ÉF (50 to 80ÉC) or using the ªCOLDº range
at fluid temperatures of 32 to 86ÉF (0 to 30ÉC).
IDo not overfill.
IUse type DEXRONTMIIE, DEXRONTMIII
or equivalent.
SDI0496SDI0118
POWER STEERING FLUID
7-11
Z01.2.1/A32-DX

Check the fluid level in the reservoir. If the fluid
is below the Min. line or the brake warning light
comes on, addDOT 3fluid up to the Max. line.
If fluid must be added frequently, the system
should be thoroughly checked by your NIS-
SAN dealer.
Use only new fluid. Old, inferior, or con-
taminated fluid may damage the brake
and clutch systems. The use of im-
proper fluids can damage the brake sys-
tem and affect the vehicle's stoppingability.
Do not spill the fluid on painted sur-
faces. This will damage the paint. If fluid
is spilled, wash with water.
Type A
Add fluid when the low washer fluid warning
light comes on. Add a washer solvent to the
water for better cleaning. In the winter season,
add a windshield washer anti-freeze. Follow
the manufacturer's instructions for the mixture
ratio.
SDI0119SDI0189
BRAKE AND CLUTCH FLUID WINDOW WASHER FLUID
7-12
Z01.2.1/A32-DX

Type B
To check the fluid level, use your finger to plug
the center hole of the cap (as shown above),
then remove it from the tank. If there is no fluid
in the tube, add fluid. Add a washer solvent to
the water for better cleaning. In the winter
season, add a windshield washer anti-freeze.
Follow the manufacturer's instructions for the
mixture ratio.
Anti-freeze is poisonous and should be
stored carefully in marked containers
out of the reach of children.
Do not substitute engine anti-freeze
coolant for window washer solution.
This may result in damage to the paint.
IKeep the battery surface clean and dry. Any
corrosion should be washed off with a
solution of baking soda and water.
IMake certain the terminal connections are
clean and securely tightened.
IIf the vehicle is not to be used for 30 days or
longer, disconnect the ªÐº negative battery
terminal cable to prevent discharge.
IDo not expose the battery to flames
or electrical sparks. Hydrogen gas
generated by battery action is explo-
sive. Do not allow battery fluid to
contact your skin, eyes, fabrics, or
painted surfaces. After touching a
battery or battery cap, do not touch or
rub your eyes. Thoroughly wash your
hands. If the acid contacts your eyes,
skin or clothing, immediately flush
with water for at least 15 minutes and
seek medical attention.
IWhen working on or near a battery,
always wear suitable eye protection
and remove all jewelry.
IKeep the battery out of the reach of
SDI0497
BATTERY
7-13
Z01.2.1/A32-DX

children.
Check the fluid level in each cell. It should be
between the MAX. and MIN. lines.
If it is necessary to add fluid, add only distilled
water to bring the level to the indicator in each
filler opening.Do not overfill.
1. Remove the cell plugs.
2. Add distilled water up to the MAX. level.
3. Tighten cell plugs.
JUMP STARTING
If jump starting is necessary, see the ªIn case
of emergencyº section. If the engine does not
start by jump starting, the battery may have to
be replaced. Contact your NISSAN dealer.
DI0137M
7-14
Z01.2.1/A32-DX

Be sure the ignition key is ªOFFº. The
engine could rotate unexpectedly.
1. Visually inspect each belt for signs of un-
usual wear, cuts, fraying, oil adhesion or
looseness. If the belt is in poor condition or
loose, have it replaced or adjusted by your
NISSAN dealer.
2. Have the belts checked regularly for condi-
tion and tension in accordance with the
maintenance schedule in this manual.
Be sure the engine and ignition switch
are off and that the parking brake is
engaged securely.
Be sure to use the correct wrench to
remove the plugs. An incorrect wrench
can cause damage.
SDI0141
DRIVE BELTS SPARK PLUG REPLACEMENT
7-15
Z01.2.1/A32-DX

1. Remove the rocker cover ornament using a
suitable hexagon wrench. (Front side)
2. Disconnect the electrical connectors.
3. Loosen the ignition coil fixing bolts. And
remove the ignition coil to give access to
the spark plugs.
4. Remove the spark plugs with a spark plug
wrench.
The plug wrench has a rubber seal that
holds the spark plug so that it will not fall
when it is pulled out. Make sure that each
spark plug is snugly fitted into the plug
wrench.5. Fit the new plugs, one at a time, into the
spark plug wrench and install them. Turn
each plug in several full turns by hand, then
tighten with a spark plug wrench to the
correct torque. Do not overtighten.
Spark plug tightening torque:
14 to 22 ft-lb
(20 to 29 N×m)6. Holding the ignition coil, re-connect each
ignition coil to its proper spark plug by
pushing it on until you feel a snap.
7. Tighten all ignition coils.
SDI0122SDI0123
7-16
Z01.2.1/A32-DX

Platinum-tipped spark plug
It is not necessary to replace the platinum-
tipped spark plugs as frequently as the con-
ventional type spark plugs since they will last
much longer. Follow the maintenance sched-
ule but, do not reuse them by cleaning or
regapping.
Always replace with recommended
platinum-tipped spark plugs.The filter element should not be cleaned and
reused. Replace it according to the mainte-
nance intervals shown in the ªMaintenance
scheduleº section. When replacing the filter,
wipe the inside of the air cleaner housing and
the cover with a damp cloth.
Operating the engine with the air cleaner
off can cause you or others to be
burned. The air cleaner not only cleans
the air, it stops flame if the engine back-
fires. If it is not there, and the engine
SDI0498SDI0145SDI0121
AIR CLEANER FILTER
7-17
Z01.2.1/A32-DX
