1997 NISSAN MAXIMA Owners Manual

SAA0060CSAA0061C
3-8
Z01.2.1/A32-DX

IThe air conditioner cooling function
operates only when the engine is run-
ning.
IDo not leave children, unreliable
adults, or pets alone in your vehicle.
On hot, sunny days, temperatures in
a closed vehicle could quickly be-
come high enough to cause severe or
possibly fatal injuries to people or
animals.
IDo not use the recirculation mode for
long periods as it may cause the
interior air to become stale and the
windows to fog up.
IPositioning of the heating or air con-
ditioning controls should not be
done while driving, in order that full
attention may be given to the driving
operation.
Start the engine and operate the controls to
activate the air conditioner.
Cooling and/or dehumidified heating
(Auto mode)
This mode may be normally used all year
round as the system automatically works to
keep a constant temperature. Air flow distribu-
tion and fan speed are also controlled auto-
matically.
1. Push the AUTO button on. (ªAUTOº will be
displayed.)
2. Push the temperature set button
ª
ºªº to set the desired tempera-
ture.
IAdjust the temperature set button to about
75ÉF (24ÉC) for normal operation.
IThe temperature of the passenger compart-
ment will be maintained automatically. Air
flow distribution and fan speed are also
controlled automatically.
Heating (ECON mode)
The air conditioner does not activate. When
you need to heat only, use this mode.
1. Push the ECON (ECONOMY) button on.
(ªECONº will be displayed.)
SAA0043B
AUTOMATIC AIR CONDITIONER
(if so equipped)
3-9
Z01.2.1/A32-DX

2. Push the temperature set button
ªºªº to set the desired tempera-
ture.
IThe temperature of the passenger compart-
ment will be maintained automatically. Air
flow distribution and fan speed are also
controlled automatically.
IDo not set the temperature lower than the
outside air temperature. Otherwise the sys-
tem may not work properly.
INot recommended if windows fog up.
Dehumidified defogging
1. Push the DEF ªº button on. (The
indicator light on the button will come on.)
2. Push the temperature set button
ª
ºªº to set the desired tempera-
ture.
ITo quickly remove ice or fog from the
outside of the windows, push the manual
fan control button ª
º and set to the
maximum position ªº.
IAs soon as possible after the windshield is
clean, push the AUTO button to return to
the auto mode.
IWhen the DEF ª
º button is pushed,
the air conditioner will automatically beturned on at outside temperatures above
35ÉF (2ÉC) to defog the windshield, and the
air recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
Manual fan speed control
Push the fan control button ªº to manu-
ally control the fan speed.
IPush the AUTO button to return to auto-
matic control of the fan speed.
Air recirculation button
Push the air recirculation button ªºto
recirculate interior air inside the vehicle. The
indicator light on the switch will come on.
Push it again to draw outside air into the
passenger compartment. The indicator will go
out.
IThe air recirculation button will not be acti-
vated when the air conditioner is in DEF
mode.
Manual air flow control button
ªMODEº
Pushing the manual air flow control buttonselects the air outlet to:
: Air flows from center and side ventila-
tors.
: Air flows from center and side ventila-
tors and foot outlets.
: Air flows mainly from foot outlets.
To turn system off
Push the OFF button.
Operating tips
IWhen the engine coolant temperature and
outside air temperature are low, the air flow
from the foot outlets may not operate for a
maximum of 150 seconds. However, this is
not a malfunction. After the coolant tem-
perature warms up, the air flow from the
foot outlets will operate normally.
3-10
Z01.2.1/A32-DX

The sensor on the instrument panel helps
maintain a constant temperature; do not put
anything on or around this sensor.
Servicing air conditioner
The air conditioning system in your NISSAN
vehicle is charged with a refrigerant designed
with the environment in mind.This refrigerant
will not harm the earth's ozone layer.How-
ever, special charging equipment and lubricant
are required when servicing your NISSAN air
conditioner. Using improper refrigerants or lu-
bricants will cause severe damage to your air
conditioning system. See AIR CONDITION-
ING SYSTEM REFRIGERANT AND LUBRI-
CANT RECOMMENDATIONS in the TECHNI-
CAL AND CONSUMER INFORMATION
section of this manual.
Your NISSAN dealer will be able to service
your environmentally ªfriendlyº air conditioning
system.To turn the radio on, turn the ignition key to
ªACCº or ªONº. If you listen to the radio with
the engine not running, turn the key to the
ªACCº position.
Radio reception is affected by station signal
strength, distance from radio transmitter, build-
ings, bridges, mountains and other external
influences. Intermittent changes in reception
quality normally are caused by these external
influences.
HA1011
RADIO
3-11
Z01.2.1/A32-DX

FM/AM RADIO WITH CASSETTE
PLAYER
Radio operation
Push the ON/VOL knob to listen to the radio
and tune in the desired station.
Pushing the ª
º button while the cas-
sette tape is playing will turn off the cassette
player and turn on the radio.
Turn the ON/VOL knob to adjust the volume.
Inserting a cassette tape into the cassette
player while the radio is on will turn off the
radio and turn on the cassette player.
The electronic tuning radio has a DIVERSITY
reception system. The FM signal can reflect off
of buildings or mountains. This causes offen-
sive noise. The DIVERSITY system employs
two antennas; one is a rod type antenna and
the other is a printed antenna on the rear
window. This system automatically switches to
the antenna which receives less noise. Thus
the radio provides high quality reception.
Selecting the desired band
Push the band select button ªºto
change from AM to FM reception.
The stereo indicator will glow during FM stereo
SAA0044B
3-12
Z01.2.1/A32-DX

reception. When the stereo broadcast signal is
weak, the radio will automatically change from
stereo to monaural reception.
Tuning
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.
Manual tuning
Push down either manual tuning ª
º
ªº button.
SCAN tuning
Push the SEEK/SCAN tuning button ª
º
for more than 1.5 seconds. SCAN tuning be-
gins from low to high frequencies and stops at
each broadcasting station for five seconds.
Pushing the button again during this five sec-
ond period will stop SCAN tuning and the radio
will remain tuned to that station.SEEK tuning
Push the SEEK/SCAN tuning button ª
º
for less than 1.5 seconds. SEEK tuning begins
from low to high frequencies and stops at the
next broadcasting station.
Station memory operations
Six stations can be set for each band.
1. Tune to the desired station.
2. Push the desired select button for more
AHA0040
3-13
Z01.2.1/A32-DX

than 2 seconds. (For example, in the dia-
gram ch2 is to be memorized. The radio
mutes when the select button is pushed.)
3. The indicator ªch2º will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if the
fuse blows, the radio memory will be can-
celled. In that case, reset the desired stations.
Adjusting tone quality
Push then turn the BASS and TREB
(TREBLE) control knob to obtain the most
pleasant sound.
Adjusting speaker sound balance
Push then pull the BAL (BALANCE) control
knob to adjust the volume between the right
and left speakers.
FADER volume control
Push then pull the FADER control knob to
adjust the volume between the front and rear
speakers.
Cassette tape operation
Turn the ignition key to ªACCº or ªONº, then
carefully insert the cassette tape into the tape
door.
The cassette tape will automatically pull into
the player.
Do not force the cassette tape into the
tape door.
This could cause player damage.
The cassette tape will automatically change
directions to play the other side when the first
side is completed.
ITo maintain good quality sound, NIS-
SAN recommends that you use cassette
tapes of 60 minutes or shorter in length.
ICassette tapes should be removed from
the player when not in use. Store cas-
settes in their protective cases and away
from direct sunlight, heat, moisture and
magnetic sources.
Direct sunlight can cause the cassette to
become deformed. The use of deformed
HA1078
3-14
Z01.2.1/A32-DX

cassettes may cause the cassette to jam
in the player.
IDo not use cassettes that have labels
which are peeling and loose. If used, the
label could jam in the player.
IIf a cassette has loose tape, insert a
pencil through one of the cassette hubs
and rewind the tape firmly around the
hubs. Loose tape may cause tape jam-
ming and wavering sound quality.
IOver a period of time, the playback
head, capstan and pinch roller may col-
lect a tape coating residue as the tape
passes over the head. This residue ac-
cumulation can cause weak or wavering
sound, and should be removed periodi-
cally with a head cleaning tape. If the
residue is not removed periodically, the
player may need to be disassembled for
cleaning.Fast forwarding or rewinding the
tape
Push either the FF (forward) or REW (rewind)
button for the desired direction.
The indicator light on the switch will come on.
APS fast forwarding or APS
rewinding the tape
Push either the APS (automatic program
search) FF or APS REW button while the
cassette tape is playing. The tape will run
quickly, and stop and play at the next program.
The indicator light flashes on and off while
searching the program.
This system searches at the blank intervals
between selections. If there is a blank interval
within one program or there is no interval
between programs, the system may not stop in
the desired or expected location.
Changing the direction of tape play
Push the PROG (program) select button.
Playing and stopping the cassette
tape
Pushing the PLAY/STOP button while the cas-
sette tape is playing stops the tape. Pushing
the button again plays the tape.
Dolby NR (noise reduction)
Push theªDOLBY NRº button for Dolby
NR encoded tapes to reduce high frequency
tape noise. The indicator will come on.
Dolby noise reduction manufactured under li-
cense from Dolby Laboratories Licensing Cor-
poration. ªDOLBYº and the double-D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
Metal or chrome tape usage
The cassette player will be automatically set to
high performance play when playing a metal or
chrome cassette tape.
Ejecting the cassette tape
Push the eject button.
The cassette tape will automatically come out.
3-15
