1997 NISSAN MAXIMA Owners Manual

FM-AM RADIO WITH CASSETTE
PLAYER
Radio operation
Push the POWER/VOLUME control knob to
listen to the radio and tune in the desired
station.
Push the FM-AM band select button while the
cassette tape is playing will turn off the cas-
sette player and turn on the radio.
Turn the POWER/VOLUME control knob to
adjust the volume.
Inserting a cassette tape into the cassette
player while the radio is on will turn off the
radio and turn on the cassette player.
The radio has a diversity reception system.
The FM signal can reflect off of buildings or
mountains. This causes offensive noise. The
diversity system employs two antennas; one is
a rod type antenna and the other is a printed
antenna on the rear window. This system
automatically switches to the antenna which
receives less noise. Thus the radio provides
high quality reception.
Selecting the desired band
Push the band select button FM-AM bandSAA0233
3-16
Z01.2.1/A32-DX

select to change the reception as follows:
FM1,FM2,AM
The stereo indicator will glow during FM stereo
reception. When the stereo broadcast signal is
weak, the radio will automatically change from
stereo to monaural reception.
Tuning
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.
Manual tuning
Push down either manual tuning button
ª
ºorªº.
SCAN tuning
Push the SEEK/SCAN tuning button ª
ºor
ªº for more than 1.5 seconds. SCAN
tuning begins and stops at each broadcasting
station for five seconds. Pushing the button
again during this five second period will stop
SCAN tuning and the radio will remain tuned to
that station.SEEK tuning
Push the SEEK/SCAN tuning button ª
ºor
ªº for less than 1.5 seconds. SEEK tun-
ing begins and stops at the next broadcasting
station.
Twelve stations can be set for the FM band
(FM1 and FM2).
Six stations can be set for the AM band.
1. Tune to the desired station using the
SEEK/SCAN or TUNE button.
SAA0234
3-17
Z01.2.1/A32-DX

2. Push the desired station select button for
more than 1.5 seconds. (For example, in
the diagram ch2 is to be memorized. The
radio mutes when the select button is
pushed.)
3. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if the
fuse blows, the radio memory will be can-
celled. In that case, reset the desired stations.
Adjusting tone quality and speaker
sound balance
Push the AUDIO switch to change the display
as follows:
BAS,TRE,FAD,BAL
BAS (bass) and TRE (treble) adjust the tone
quality by pushing the control button
ª
ºorªº to the most pleasing level.
The indicator light will show the level of the
tone quality.
FAD (fader) adjusts the speaker sound bal-
ance between the front ª
º and rear
ªº speakers, and BAL (balance) adjusts
the speaker sound balance between the rightª
º and left ªº speakers by pushing
the control button. The indicator light will show
the level of the speaker sound balance.
Cassette tape operation
Turn the ignition key to ACC or ON, then
carefully insert the cassette tape into the tape
door.
The cassette tape will automatically pull into
the player.
SAA0235
3-18
Z01.2.1/A32-DX

Do not force the cassette tape into the
tape door.
This could cause player damage.
The cassette tape will automatically change
directions to play the other side when the first
side is completed.
The indicator light will run when the tape is
playing.
Precautions on cassette player
operation
ITo maintain good quality sound,
NISSAN recommends that you use cas-
sette tapes of 60 minutes or shorter in
length.
ICassette tapes should be removed from
the player when not in use. Store cas-
settes in their protective cases and away
from direct sunlight, heat, moisture and
magnetic sources.
Direct sunlight can cause the cassette to
become deformed. The use of deformed
cassettes may cause the cassette to jam
in the player.IDo not use cassettes that have labels
which are peeling and loose. If used, the
label could jam in the player.
IIf a cassette has loose tape, insert a
pencil through one of the cassette hubs
and rewind the tape firmly around the
hubs. Loose tape may cause tape jam-
ming and wavering sound quality.
IOver a period of time, the playback
head, capstan and pinch roller may col-
lect a tape coating residue as the tape
passes over the head. This residue ac-
cumulation can cause weak or wavering
sound, and should be removed periodi-
cally with a head cleaning tape. If the
residue is not removed periodically, the
player may need to be disassembled for
cleaning.
Fast forwarding or rewinding the
tape
Push either the FF (forward) or REW (rewind)
button for the desired direction.
The indicator light will run with quick intervals
when the FF or REW function is started.
APS fast forwarding or APS
rewinding the tape
Push either the APS (automatic program
search) FF or APS REW button while the
cassette tape is playing. The tape will run
quickly, and stop and play at the next program.
The indicator light will run with quick intervals
when the APS FF or APS REW function is
started.
This system searches at the blank intervals
between selections. If there is a blank interval
within one program or there is no interval
between programs, the system may not stop in
the desired or expected location.
Changing the direction of tape play
Push the PROG (program) select button.
Playing and stopping the cassette
tape
Pushing the PLAY/STOP button while the cas-
sette tape is playing stops the tape. Pushing
the button again plays the tape.
Dolby NR (noise reduction)
Push the DOLBY NR ªº button for Dolby
NR encoded tapes to reduce high frequency
tape noise. The indicator will come on.
3-19
Z01.2.1/A32-DX

Dolby noise reduction manufactured under li-
cense from Dolby Laboratories Licensing Cor-
poration. ªDOLBYº and the double-D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
Metal or chrome tape usage
The cassette player will be automatically set to
high performance play when playing a metal or
chrome cassette tape.
Ejecting the cassette tape
Push the EJECT ªº button.
The cassette tape will automatically come out.
3-20
Z01.2.1/A32-DX

SAA0204
3-21
Z01.2.1/A32-DX

FM-AM RADIO WITH CASSETTE
PLAYER AND COMPACT DISC
PLAYER
AUDIO MAIN OPERATION
Head unit
The radio has an FM Diversity reception sys-
tem, which employs two antennas. One is a
rod type antenna; the other is an antenna
printed on the window. This system automati-
cally switches to the antenna which is receiv-
ing less noise.
The tape deck employs a permalloy head
which allows for improved reproduction of high
frequency ranges. Noise is also greatly re-
duced by the combined use of the Dolby NR
(noise reduction) system.
Power/Volume control
Turn the ignition key to ªACCº or ªONº, and
then push the POWER/VOLUME knob while
the system is off to call up the mode (radio,
tape or CD) which was playing immediately
before the system was turned off. When no CD
or tape is loaded, the radio will come on. While
the system is on, pushing the
POWER/VOLUME knob turns the system off.To turn the radio off, press the POWER/
VOLUME knob.
Turn the POWER/VOLUME control knob to
adjust the volume.
Adjusting tone quality
Push then turn the BASS and TREB
(TREBLE) control knobs to obtain the most
pleasant sound.
SAA0194
3-22
Z01.2.1/A32-DX

Adjusting speaker sound balance
Push then pull the BAL (BALANCE) control
knob to adjust the volume between the right
and left speakers.
Fader volume control
Push then pull the FADER control knob to
adjust the volume between the front and rear
speakers.
RADIO OPERATION
FM×AM band select button
Pushing the FM×AM band select button will
change the band.
When FM×AM band select button is pushed
while the ignition switch is at ªACCº or ªONº,
the radio will come on at the station last
played.
The last station played will also come on when
the power knob is turned to ON.
If a compact disc or tape is inserted when the
power knob is turned to ON, the compact disc
or tape will automatically be turned off and the
last radio station played will come on.
The FM stereo indicator ªSTº will glow during
FM stereo reception. When the stereo broad-
cast signal is weak, the radio will automatically
change from stereo to monaural reception.
TUNE button
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.
Use these buttons for manual tuning.
If the TUNE button is pushed for less than 0.5
seconds, the frequency moves by an incre-
ment of 1 step.
To move quickly through the channels, hold
either of the TUNE buttons down for more than
0.5 seconds.
SAA0190
3-23
Z01.2.1/A32-DX
