Fig. 255: Identifying Retrofitting Illuminated Door Sill Molding Components
It is also possible to order the illuminated door sill molding with the lettering "AMG" - see parts ordering
notes.
Removal
Contact with components
under high voltage can
pose lethal hazardDo not touch parts which
conduct high voltages.
Persons who wear
electronic implants (e.g.
heart pacemakers) must
not carry out any work on
such components.AS00.00-Z-0020-01A
1Connect quiescent current
retention unit *WH58.30-Z-1012-09A
2Disconnect ground cable
of battery
AR54.10-P-0003A
3Open fuse and relay
module (F1)2 covers. Rear cover is
attached with 5 screws.
4Remove screws for fuse
block 2 screws at front.
5Remove door sill
moldings on right and left Up to VIN A145272,
X708318: Begin in the

2001 Mercedes-Benz ML320
1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis
me
Saturday, October 02, 2010 3:30:11 PMPage 346 © 2006 Mitchell Repair Information Company, LLC.

Fig. 302: Identifying Voltage Supply And Instrument Panel Support
3. Insert plug into interface module.
Input on interface module marked.
4. Secure all wiring harnesses (3) of the video system to the interior wiring harness (4) with tie straps.
Fastening points are marked with white adhesive tape on the wiring harnesses.
5. Disconnect connector in the voltage supply cable (11) from the relay module.
6. Insert noise filter (12) into the voltage supply cable (11).
7. Secure noise filter (12) under the right-hand instrument panel support with tie straps.
Fig. 303: Identifying Noise Filter And Voltage Supply Cable

8. Install fuse holder (6) of the voltage supply cable in position f9 of the fuse unit (7).
9. Insert 7.5 A fuse supplied into fuse holder.
Only on vehicles on which running boards are not installed

2001 Mercedes-Benz ML320
1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis
me
Saturday, October 02, 2010 3:30:12 PMPage 387 © 2006 Mitchell Repair Information Company, LLC.

10.
1. Insert red relay module (8) for power supply cable in position 7 in fuse unit (7).
Only on vehicles on which running boards are installed
2. Remove cable and fuse from red relay module (8) and install in free locations of present redreplay
module in position 7 of fuse unit (7).
11. Insert attached 10 A fuse into fuse holder with voltage supply cable.
12. Unscrew nut (9) at terminal 31.
Fig. 304: Identifying Fuse Holder, Red Relay Module And Black Relay Module

13. Connect ground cable (10) of the interface module wiring harness to terminal 31.
14. Install nut (9) on terminal 31.
15.
1. Insertblack relay module (11) into location 9 of fuse unit (7).
Only if relay is not yet present.
16. Install fuse unit cover in right-side footwell.
RETROFIT VEHICLE VIDEO SYSTEM - AZ82.60-P-0004A
MODELS 163.136 /154 /172 1A as of 145273, 163.136 /154 /172 1X as of 708319,

2001 Mercedes-Benz ML320
1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis
me
Saturday, October 02, 2010 3:30:12 PMPage 388 © 2006 Mitchell Repair Information Company, LLC.

GF82.15-P-0002-03GH
Headlamp cleaning system (HCS), location of

components

n

P82.15-2083-06

F2k5
Relay 5

M5/2
HCS pump

N10/1
Extended activity module (EAM)

S4/1
HCS [SRA] switch

Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

GF80.20-P-0005-01GH
Central locking (CL), location of components

P80.20-0522-06

Location of components
1
Antenna

F1
Fuse and relay module

F1k15
CL rear door unlocking relay

F1k20
CL all door locking relay

F1k23
CL front right front door and rear

door unlocking relay

F1k24
CL front left front door and tank

flap unlocking relay

M14/5
Right front door CL actuating

motor

M14/6
Left front door CL actuating motor

M14/7
Tailgate CL actuating motor

M14/8
Left rear door CL actuating motor

M14/9
Right rear door CL actuating motor

M14/10
Filler flap CL actuating motor

N10
All-activity module (AAM)

Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

AD80.20-P-6001-43GH
CL test of electrical system motor actuation

relay

t
A

Scope of test

Measuring instrument/

Test connection
Operation/Requirement

Specified value
D

Possible cause/Remedy

1.0
Central locking locks

everything

HHT actuation

A

All doors closed and

unlocked.
All doors and

fuel tank flap

are locked
D
Individual doors are not

locked:

t
1.1

D
No door is locked:

t
1.2
1.1
Central locking unlocks

everything

HHT actuation

A

All doors closed and locked.
All doors and

fuel tank flap

are unlocked
D
Left front door and fuel

tank flap are not unlocked:

t
1.3

D
Right front door and rear

doors are not unlocked:

t
1.4

D
Tailgate is not unlocked:

t
1.5

D
No door is unlocked:

Cables, N10

1.2
Central locking relay,

lock all doors (F1k20)

Function

Replace relay (F1k20) by

relay (F1k15),

Repeat test
t
1.0

All doors and

fuel tank flap

are locked
If test 1.0 in order:
D
Relay (F1k20)

otherwise:

D
Cables

1.3
Central locking relay,

unlock left door and fuel

tank flap (F1k24)

Function

Replace relay (F1k24) by

relay (F1k15), close and

lock left front door

A
Actuation of unlocking

left front door.

Left front door

is unlocked
Value in order:

D
Relay (F1k24)

Value not in order:

D
Cables

1.4
Central locking relay,

unlock right door and

rear doors (F1k23)

Function

Replace relay (F1k23) by

(F1k15), repeat test

t
1.1

All doors and

fuel tank flap

are unlocked
If the same fault pattern

emerges when test 1.1 is

repeated:

D
Cables

D
All-Activity Module (AAM)

(N10)

Tailgate is not unlocked:

D
Relay (F1k23)

1.5
Central locking relay,

unlock tailgate (F1k15)

Function

Replace relay (F1k15) by

(F1k23), close and lock

tailgate

A
Actuation of unlocking

tailgate

Tailgate is

unlocked
Value in order:

D
Relay (F1k15)

Value not in order:

D
Cables

Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Fig. 1: Drive Belt Routing
Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
TROUBLE SHOOTING
PRELIMINARY INSPECTION
Verify customer complaint by operating system. Visually inspect for obvious signs of mechanical and electrical
damage. Check generator belt tension and condition. Ensure that battery voltage is within specifications. Inspect
for blown fuses and damaged relays.
Verify ground connection integrity between engine, body, battery and generator. Check for damaged wiring
harnesses and/or switches. Check for a broken or partially broken wire inside insulation, which could cause
system malfunction but prove good in a continuity/voltage check with system disconnected. Ensure any
aftermarket electronic equipment is properly installed. If fault is found, repair as necessary. If no fault is found,
check for conditions that might cause an intermittent situation.
SERVICE PRECAUTIONS
BATTERY DISCONNECT/CONNECT
Disconnect Procedures
1. On vehicles not equipped with TELE AID, go to step 5 . Vehicles equipped with TELE AID, switch
TELE AID into service mode by turning ignition ON.
2. Turn ON telephone and enter code "*#4610#" on handset.
3. Confirm that "No Telematics Service" appears on handset with okay.
4. Turn OFF handset.
5. Turn OFF ignition.
6. Open hood and open snap fasteners (1) on dust filter housing. See Fig. 2
.
7. Remove dust filter housing (2) exposing battery.
8. If not using quiescent current retention unit, go to step 14 . If using quiescent current retention unit, go to
next step.
9. Connect quiescent current retention unit by switching on quiescent current retention unit (7) and then first
connecting positive terminal (8) and negative terminal (9) of retention unit to positive cable and battery
ground (W10). See Fig. 3
.
10. On vehicles equipped with TELE AID, remove luggage compartment cargo anchoring lugs and remove
floor paneling.
11. Remove screws (1). See Fig. 4
.
12. Dismantle cover from TELE AID control module (A35/8).
13. Disconnect connection coupling for back up battery and remove back up battery.
14. Disconnect ne
gative battery cable (1) and insulate terminal. See Fig. 5. NOTE: Numbers and letters in text refer to numbers and letters in figures.

2001 Mercedes-Benz ML320
2001-04 STARTING & CHARGING SYSTEMS Generators & Regulators - 163 Chassis
me
Saturday, October 02, 2010 3:20:31 PMPage 3 © 2006 Mitchell Repair Information Company, LLC.

GF77.20-P-2002GH
Closing sliding /pop-up roof, function
19.2.97

MODEL
163 with CODE (414a) Electric glass sliding/pop-up roof

Function prerequisites

D
Voltage not too low or too high

D
Switch-on conditions for convenience control fulfilled

Function

The sliding roof and pop-up roof can be closed by pressing the

switch (SR, S13/2)
. The sliding/pop-up roof can only be closed by

continuously pressing the
switch (SR, S13/2)
.

The express close function is not available for safety reasons.


If the sliding/pop-up roof has not been synchronized, it opens only in

the pop-up roof direction each time the
switch (SR, S13/2) is

actuated. Upon reaching its end position, i.e. before the pop-up roof

is completely open,
synchronization
is accomplished.
After successful synchronization, the sliding/pop-up roof can then be

controlled without limitations.

Vehicles
up to 11.99:

The power for the
sliding/pop-up roof (M12)
is supplied via a

fuse directly to c. 30.

The power for the
switch (SR, S13/2)
is supplied via the

convenience relay (F1k14)
, which is actuated by the
all-activity

module (AAM, N10)
.

Vehicles
as of 12.99:

The power for the
sliding/pop-up roof (M12)
is supplied via a

fuse directly to c. 30. The power for the
switch (SHD, S13/2) is

supplied via a lead to the
extended-activity module (EAM,

N10/1) , this power is switched through only when the switch-on

conditions for the convenience control are fulfilled and the EAM is

coded accordingly.

Opening pop-up roof, function

GF77.20-P-2003GH

Opening sliding roof, function

GF77.20-P-2004GH

Synchronizing sliding /pop-up roof, function

GF77.20-P-3002GH

Sliding/pop-up roof, location/purpose/
design/function

GF77.20-P-4100GH

Convenience control

GF72.29-P-2002GH

All-activity module (AAM)
up to 11.99

GF54.21-P-4100GH

Extended-activity module, location/

purpose/design
as of 12.99

GF54.21-P-4107GK

Copyright DaimlerChrysler AG 04.08.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
