1997 FORD E SERIES Owners Manual

Deactivating overdrive
Press the transmission control
switch (TCS) on the end of the
gearshift lever. The Transmission
Control Indicator Light (TCIL)
(the word ªOFFº on the gearshift
lever) will illuminate. The
transmission will only operate in
gears one through three.
Deactivate overdrive when:
²driving with a heavy load
²driving in hilly terrain
²additional engine braking is
desired
Activating overdrive
To return to normal overdrive
operation, press the TCS again.
The light illuminating the word
ªOFFº will turn off.
When restarting your vehicle, the
transmission will automatically
return to the normal overdrive
operation mode.
eco_overdrive_activating
eco_trans_control_light
Controls and features
25

Transmission control indicator
light (TCIL)
The TCIL (the word ªOFFº)
located on the gearshift lever
indicates the status of the
transmission.
The TCIL may flash steady if a
malfunction is detected. If this
occurs have your transmission
serviced by your Ford dealer as
soon as possible or damage may
occur.
Tilt steering
Pull the control to adjust the
steering column angle. Push the
control back up to lock the
steering wheel into position.
Never adjust the steering
wheel when the vehicle is
moving.
OVERDRIVE OFF
eco_tilt-steering
eco_hazard_flasher
Controls and features
26

Hazard flasher control
For more information on the
hazard flasher control, refer to the
Roadside emergencieschapter.
Windshield wipers and washer
²Push the end to activate the
washer.
²Push end once for a single wipe.
²Push and hold for a constant
cycle.
²Turn the dial to adjust
intermittent wiper speed.
FlashÐ toÐ pass
Pull toward you and release for
ªflash-to-passº operation.
O
O
O
eco_washer-wiper
eco_flash-to-pass_high-beams eco_speed_control
Controls and features
27

Speed control (if equipped)
To turn speed control on
²Press ON
To turn speed control off
²Press OFF or
²Turn off the vehicle ignition.
Once speed control is switched off,
the previously programmed set
speed will be erased.
To set a speed
Press SET ACCEL. For speed
control to operate, the speed
control must be ON and the
vehicle speed must be greater than
48 km/h (30 mph).
If you drive up or down a steep
hill, your vehicle speed may vary
momentarily slower or faster than
the set speed. This is normal.
Speed control cannot reduce the
vehicle speed if it increases above
the set speed on a downhill. If
your vehicle speed is faster than
the set speed while driving on a
downhill in Overdrive, you may
want to shift to the next lower
gear to reduce your vehicle speed.
ON
OFFRES
SET
ACCEL
COAST
ON
OFFRES
SET
ACCEL
COAST
com_speed_on.01 com_speed_off.01
com_set_speed.01
Controls and features
28

If your vehicle slows downs more
than 16 km/h (10 mph) below your
set speed on an uphill, your speed
control will disengage. This is
normal. Pressing RES will
re-engage it.
Do not use the speed
control in heavy traffic or
on roads that are winding,
slippery, or unpaved.
To set a higher speed
²Press and hold SET ACCEL.
Release the switch when the
desired vehicle speed is
reached, or
²Press and release SET ACCEL.
Each press will increase the set
speed by 1.6 km/h (1 mph) or
²Accelerate with your accelerator
pedal, then press SET ACCEL.
You may accelerate with the
accelerator pedal at any time
during speed control usage.
Releasing the accelerator pedal will
return your vehicle speed to the
previously programmed set speed.
To set a lower set speed
²Press and hold COAST. Release
the switch when the desired
vehicle speed is reached, or
²Press and release COAST. Each
press will decrease the set
speed by 1.6 km/h (1 mph) or
²Depress the brake pedal. When
the desired vehicle speed is
reached press SET ACCEL.
ON
OFFRES
SET
ACCEL
COAST
ON
OFFRES
SET
ACCEL
COAST
com_speed_up.01
com_slow_down.01
com_disengage_speed_control.01
Controls and features
29

To disengage speed control
²Depress the brake pedal.
Disengaging the speed control will
not erase the previously
programmed set speed.
To return to a set speed
²Press RES. For RES to operate,
the vehicle speed must be faster
than 48 km/h (30 mph).
OVERHEAD CONTROLS
Cargo and dome lamps
Rear cargo lamps equipped with an
ON/OFF/DOOR control will light
when:
²the doors are closed and the
switch is in the ON position
²either front door is open and
the switch is in the DOOR
position
²the headlamp control is rotated
fully counterclockwise
When the cargo lamp switch is in
the OFF position, it will not
illuminate when you open the
doors or turn the headlamp
control.
ON
OFFRES
SET
ACCEL
COAST
ONDOOROFF
com_resume_feature.01
eco_overhead_control
eco_cargo-dome_lamps
eco_courtesy-reading_lamps
Controls and features
30

Courtesy/reading lamps
The courtesy/reading lamps will
illuminate when:
²the lens is in the flat position
and any door is open
²the lens is in the flat position
and the headlamp control is
rotated fully counterclockwise
²the lens is in the rotated
position.
DOOR MOUNTED CONTROLS
Power outside mirrors (if
equipped)
To adjust the outside mirrors:
1. Select the mirror you want to
adjust:
Driver side mirror
Passenger side mirror
2. Move the mirror control in the
desired direction.
3. Lock the mirror by moving the
control to the center
position.
eco_door_controls
eco_power_mirror
eco_power_door_locks
Controls and features
31

Power door locks (if equipped)
Push to lock or unlock the doors.
LAll doors locked
UAll doors unlocked
²Driver side
²Passenger side
UL
U L
eco_power_windows
Controls and features
32
