1997 FORD E SERIES Owners Manual

Number Fuse amperage
ratingCircuits protected
1 20 amp 4WABS or RABS
module
2 15 amp 4WABS relay (coil),
RABS (diode/resistor),
instrument cluster,
warning chime
3 15 amp Headlamp switch,
radio sense, rear
radio control, Remote
keyless entry module
4 15 amp Power mirrors,
modified vehicle,
power locks w/RKE,
Headlamp switch
(dome), illuminated
entry, Courtesy lamp
switches, Radio
(KAP), Cluster (KAP),
warning chime
5 20 amp Remote keyless entry
module, power door
lock switches,
memory lock
6 10 amp Brake shift interlock,
speed control,
daytime running light
module
7 10 amp Multi-function switch
Roadside emergencies
105

Number Fuse amperage
ratingCircuits protected
8 30 amp Noise supression
capacitor, ignition coil
positive feed, PCM
relay diode/PCM
power relay, fuel
heater (diesel), glow
plug relay (diesel)
9 30 amp Wiper control module,
wiper motor
10 20 amp Headlamp switch
(exterior lamps),
Multi-function switch
(flash-to-pass)
11 15 amp Stoplight switch, brake
pressure switch,
multi-function switch
12 15 amp Digital transmission
range sensor (backup
lamps), auxiliary
battery relay
13 15 amp A/C mode switch,
blend door actuator
14 5 amp Instrument cluster (air
bag and charge
indicator lamps)
15 5 amp Trailer tow battery
charge relay (coil)
16 30 amp Power seats
17 - Not used
18 - Not used
19 10 amp Air bag module
20 5 amp Overdrive cancel
switch
Roadside emergencies
106

Number Fuse amperage
ratingCircuits protected
21 30 amp Power windows
22 - Not used
23 20 amp Cigar lighter, data link
connector
24 5 amp Illuminated entry
25 10 amp Left headlamp (low
beam)
26 - Not used
27 - Not used
28 25 amp Instrument panel
power point
29 - Not used
30 15 amp Headlamps (high
beam), Daytime
running lamps (DRL),
high beam indicator
31 10 amp Right headlamp (low
beam), Daytime
running lamps (DRL)
32 - Not used
33 - Not used
34 10 amp Digital transmission
range sensor (start
control)
35 - Not used
36 5 amp Panel illumination
37 - Not used
38 10 amp Air bag module
39 - Not used
40 30 amp Modified vehicle
41 30 amp Modified vehicle
42 - Not used
Roadside emergencies
107

Number Fuse amperage
ratingCircuits protected
43 - Not used
44 - Not used
Power distribution box
Always disconnect the
battery before servicing
high current fuses.
Always replace the cover
to the Power Distribution
Box before reconnecting the
battery or refilling fluid
reservoirs.
Number Fuse amperage
ratingCircuits protected
1 - Generator to battery
2 - Not used
3 - Not used
1A
B
23
4
65
78
9
10
11
12
13
14
1516
17
18
19
20
21
22
23
E
H
J F
G
K24
25
26
27
28
29
C
D
eco_power_dist_box
Roadside emergencies
108

Number Fuse amperage
ratingCircuits protected
4 5 amp PCM keep alive
memory
5 10 amp Right trailer turn
signal
6 10 amp Left trailer turn signal
7 - Not used
8 60 amp Instrument panel
fuses
9 30 amp PCM power relay
10 60 amp Auxiliary battery
11 - Not used
12 60 amp Misc.
13 50 amp Blower motor relay
14 30 amp Trailer running lamps,
trailer backup lamps
15 40 amp Headlamp switch
16 50 amp Auxiliary A/C, remote
keyless entry module
17 30 amp Fuel pump relay
(gasoline), injector
driver module relay
(diesel)
18 60 amp Modified vehicle
power
19 60 amp Anti-lock brake
system (4WABS)
20 20 amp Electric brake
controller (trailer tow)
21 50 amp Modified vehicle
power
22 40 amp Trailer battery charge
(relay)
Roadside emergencies
109

Number Fuse amperage
ratingCircuits protected
23 60 amp Ignition switch feed
24 - Not used
25 - Not used
26 10 amp Alternator (diesel)
27 15 amp Horn, daytime running
lamp module
28 - PCM diode
29 - Not used
Roadside emergencies
110

Relays
Relays are located in the power
distribution box
Ford recommends that relays be
replaced by a qualified technician.
Position Circuit
A Not used
B Not used
C Trailer backup lamps
D Trailer running lamps
E Trailer battery charge relay
F Not used
G PCM
H Blower motor
1A
B
23
4
65
78
9
10
11
12
13
14
1516
17
18
19
20
21
22
23
E
H
J F
G
K24
25
26
27
28
29
C
D
eco_relays
Roadside emergencies
111

Position Circuit
J Horn
K Fuel pump or IDM
CHANGING TIRES
Spare tire location
The spare tire is stowed under the
rear of your vehicle (except
cutaway and stripped chassis
models).
To remove the spare tire:
1. Open both rear doors and
remove thumb screw and anti-theft
bracket. If finger pressure will not
remove thumb screw, use the lug
wrench to loosen screw.
eco_tire_location
