1997 FORD E SERIES Owners Manual

in the ON position and the engine
is off.
Transmission control indicator
light (TCIL)
The Transmission Control Indicator
Light (TCIL), which is located on
the gearshift lever, may flash
steadily if a malfunction is
detected. If the TCIL is flashing,
contact your Ford dealer as soon
as possible. If this condition
persists, damage to the
transmission could occur.
The word ªOFFº located on the
end of the gearshift lever is the
transmission control indicator light
(TCIL).
Safety belt
Illuminates when the ignition is
switched on to remind you to
fasten your safety belts. For more
information, refer toUsing the
safety restraints properlyin the
Seating and safety restraints
chapter.
Charging system
Briefly illuminates when the
ignition is turned on and the
engine is off. The light also
illuminates when the battery is not
charging properly, requiring
electrical system service.
Air bag readiness
Briefly illuminates when the
ignition is turned on. If the light
fails to illuminate, continues to
OVERDRIVE OFF
eco_trans_control_light
com_safety_belt.01
com_charging_system.01
com_air_bag.01
Instrumentation
9

flash or remains on, have the
system serviced immediately.
Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on.
High beams
Illuminates when the headlamp
high beams are on.
Door ajar (if equipped)
Illuminates when the ignition
switch is in the ON or START
position and any door is open.
Oil pressure/Engine coolant
This light will come on when the
key is in the ON position and the:
²engine coolant temperature is
very high
²engine oil pressure is low
The light serves as a notice that a
system needs your attention and to
check the engine coolant
temperature gauge and the engine
oil pressure gauge.
Refer to engine coolant
temperature gauge and engine oil
pressure gauge in this section for
more information.
DOOR
AJAR
com_turn_signal.01
com_high_beams.01
eco_door_ajar
eco_oil-press_eng-temp_light
eco_warning_chimes
Instrumentation
10

WARNING CHIMES
Safety belt warning chime
For information on the safety belt
warning chime, refer to the
Seating and safety restraints
chapter.
Supplemental restraint system
(SRS) warning chime
For information on the SRS
warning chime, refer to the
Seating and safety restraints
chapter.
Key-in-ignition warning
chime/buzzer
Sounds when the key is left in the
ignition and the driver's door is
opened.
Headlamps on warning chime (if
equipped)
Sounds when the headlamps are
on, the ignition is off and the
driver's door is opened.
GAUGES
0 1020304050
60
70
80
90
10 0
20 km/h
406080
10 0
12 0
14 0
H
L
16 0
MPH
000000
0000
NORMAL
18
8NORMALFH
C
E
NORMAL
com_safety_chime.01
com_srs_chime.01
eco_key_chime
eco_headlamps_chime
eco_gauges
com_speedometer.01
Instrumentation
11

Speedometer
Indicates the current vehicle
speed.
Fuel gauge
The fuel gauge displays
approximately how much fuel is in
the fuel tank, when the ignition
switch is ON.
The fuel gauge indicator may vary
slightly when the vehicle is in
motion.
The vehicle should be refueled
with the ignition key in the OFF
position. If the vehicle is refueled
with the key in the ON position,
the key must be turned to the OFF
position and then the vehicle
started to get an accurate fuel
gauge reading. If the vehicle is
fueled with the key in the ON
position and the above mentioned
is not performed, it will take
approximately 25 minutes for the
gauge to go from ªEº to ªF.º
Engine coolant temperature
gauge
Indicates the temperature of the
engine coolant. At normal
operating temperature, the needle
remains within the normal area. If
it enters the red section, the
0 1020304050
60
70
80
90
10 0
20 km/h
406080
10 0
12 0
14 0
16 0
MPH
000000
0000
F
E
H
C
eco_fuel_gauage
com_coolant_temperature.03
Instrumentation
12

engine is overheating. Switch off
the ignition and let it cool. Refer to
Checking and adding engine
coolantin theMaintenance and
carechapter.
Engine oil pressure gauge
This shows the engine oil pressure
in the system. Sufficient pressure
exists as long as the needle
remains in the normal range.
If the gauge indicates constantly
low pressure at normal engine
speed, refer toChecking and
adding engine oilin the
Maintenance and carechapter. If
the gauge indicates a low pressure
and the engine oil level is correct,
switch off the engine immediately
and have your vehicle checked at
your dealership or by a qualified
technician.
Charging system gauge
If the pointer moves and stays
outside of the normal range, have
the vehicle's electrical system
checked as soon as safely possible.
Odometer
Registers the total kilometers
(mileage) of the vehicle.
H
L
18
8
20 km/h
406080
10 0
12 0
14 0
16 0
com_oil_pressure.03
com_voltage.01
com_odometer.01 com_trip_odometer.01
Instrumentation
13

Trip odometer
Can register the kilometers
(mileage) of individual journeys.
To reset, depress the control.
0 1020304050
60
70
80
90
10 0
20 km/h
406080
10 0
12 0
14 0
16 0
MPH
000000
0000
Instrumentation
14

INSTRUMENT PANEL
CONTROLS
Headlamp control
1. Pull the headlamp control
toward you to the first position.
Parking lamps, tail lamps, license
plate lamps and marker lamps are
now on.eco_panel_controls
eco_headlight_switch_operation
Controls and features
15

2. Pull the headlamp control
toward you to the outer position.
Headlamps are now on in addition
to above.
3. Rotate the control when it is in
the on position to brighten or dim
the instrument panel lamps. Rotate
fully counterclockwise to operate
courtesy and cargo lamps.
Daytime running light (DRL)
system (if equipped)
The DRL system turns on the high
beam headlamps, with a reduced
light output, when:
²the vehicle is running (ignition
switch is in the ON position)
²the vehicle has a fully released
parking brake
eco_headlight_daytime_running
Controls and features
