2. Remove the access cover from
the rubber strip behind the left
door.
3. Insert the tapered end of the lug
wrench or tip of jack handle
through the access hole and into
the tube.
4. Turn wrench or handle
counterclockwise until cable is
slack and tire can be slid rearward
from under vehicle.
5. Remove retainer from spare tire.
To stow the cable retainer with the
spare removed, turn the jack
handle wrench clockwise until all
slack is removed.
To stow the spare tire:
1. Lay tire on the ground under
the rear of the vehicle with valve
stem facing up.Stow aluminum
wheels with valve stem facing
down.
2. Install the retainer through
wheel center.
3. Raise the tire by turning the
wrench or handle clockwise.
Roadside emergencies
113

Continue until the lift mechanism
ªclicks.º
4. Check that the tire is tightly
seated under the vehicle by
pushing against tire. Retighten as
necessary.
5. Replace the access cover,
anti-theft bracket and thumb
screw. Use finger pressure only to
secure the thumb screw.
Make sure the spare tire
and jacking equipment are
stowed and secured in the
proper storage location.
Never run the engine with
one wheel off the ground.
Preparing to change the tire
1. Make sure your vehicle will not
move or roll.
²Put the gearshift in P (Park)
DPRN 21
eco_preparing_tire_change
Roadside emergencies
114

²Apply the parking brake
²Block the wheel that is
diagonally opposite the tire you
are changing
On E-Super Duty vehicles, the
parking brake is on the
transmission. Therefore, the
vehicle will not be prevented from
moving when a rear wheel is lifted,
even if the parking brake is
applied. Be sure to block both
directions of the wheel that is
diagonally opposite to the wheel
that is being lifted.
Roadside emergencies
115

If the vehicle slips off the
jack, you or someone else
could be seriously injured.
2. Get out spare tire and jack.
3. Use the tapered end of the lug
nut wrench to unscrew wheel
ornaments attached by retaining
screws. Remove any wheel trim.
Insert the tapered end of the lug
nut wrench behind wheel covers or
hubcaps and twist off.
Loosen the wheel nuts by pulling
up on the handle of the lug nut
wrench about one-half turn
(counterclockwise). Do not remove
the wheel lug nuts until you raise
the tire off the ground.
Replacing the tire
1. Unfold the jack handle and lock
into jack. Use the jack handle to
eco_changing-tire
Roadside emergencies
116

slide the jack under the vehicle.
To lessen the risk of
personal injury, do not put
any part of your body under the
vehicle while changing a tire. Do
not start the engine when your
vehicle is on the jack. The jack is
only meant for changing the tire.
2. Position the jack to raise the
front or rear wheel.
Never use the differential housing
as a lift point.
Rear axle jacking points:
²All models except E-Super Duty
²E-Super Duty
Roadside emergencies
117

Front axle jacking points:
²All models
3. Turn the jack handle clockwise
until the wheel is completely off
the ground.
4. Remove the lug nuts with the
lug nut wrench.
5. Replace the flat tire with the
spare tire.
If your vehicle has dual rear
wheels, there are locating pins on
the hubs and wheels with
corresponding holes. When you
install the wheel make sure that
the pins are aligned with the
proper holes.
If your vehicle has single rear
wheels, thread the lug nuts on the
studs with the beveled face toward
the wheel.
If your vehicle has dual rear
wheels, thread the two element
swiveling lug nut on the studs with
the flange facing toward the wheel.
6. Use the lug nut wrench to screw
the lug nut snugly against the
wheel.
Roadside emergencies
118

7. Lower the vehicle by turning the
jack handle counterclockwise.
8. Remove the jack and fully
tighten the lug nuts in the
following pattern:
5 lug wheel
8 lug wheel
Never use wheels or lug
nuts different than the
original equipment as this could
damage the wheel or mounting
system. This damage could allow
the wheels to come off while the
vehicle is being driven.
9. Replace any wheel covers,
ornaments or hub caps. make sure
they are screwed or snapped in
place.
10. Stow the jack, handle and lug
wrench.
11. Unblock the wheels.
Roadside emergencies
119

On vehicles equipped with dual
rear wheels retighten the wheel
lug nuts to the specified torque at
160 km (100 miles), and again at
800 km (500 miles) of new vehicle
operation and at intervals specified
in the ªService Guide.º
On vehicles equipped with single
rear wheels retighten the lug nuts
to the specified torque at 800 km
(500 miles) of operation after any
wheel change or any time the lug
nuts are loosened.
Model Bolt Size Wheel Lug nut Torque*
N²M Ft-Lb
E-150 1/2-20 135 100
E-250, E-350
and E-Super
Duty9/16-18 190 140
* Torque specifications are for nut and bolt threads free of dirt and
rust. Do not use oil or grease on threads. Use only Ford recommened
replacement fasteners.
