1996 TOYOTA T100 engine

Downloaded from www.Manualslib.com manuals search engine BO0DZ−03
Z07820
SST
Z07821
BO2556
− BODYFRONT DOOR
BO−9
1996 TOYOTA T100 (RM449U)
ADJUSTMENT
1. ADJUST DOOR IN FORWARD/REARWARD AND
VERTICAL DIRECTIONS
Using SST, adjust the door by loosening the body side hinge
bolts.
SST 09812−00010
Torque: 25 N·m (260 kgf·cm, 19 ft·lbf)
2. ADJUST DOOR IN LEFT/RIGHT AND VERTICAL
DIRECTIONS
Loosen the door side hinge bolts to adjust.
HINT:
Substitute the standard bolt for the centering bolt.
(See page BO−5)
Torque: 25 N·m (260 kgf·cm, 19 ft·lbf)
3. ADJUST DOOR LOCK STRIKER
(a) Check that the door fit and door lock linkages are adjusted
correctly.
(b) Loosen the striker mounting screws to adjust the striker.
(c) Using a plastic hammer, tap the striker to adjust it.

Downloaded from www.Manualslib.com manuals search engine BO0E0−01
BO−10
− BODYFRONT DOOR
1996 TOYOTA T100 (RM449U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO−7).

Downloaded from www.Manualslib.com manuals search engine BO0E1−02
N15354
Wiper Arm
Cowl Louver
Wiper Link
Wiper Motor
N·m (kgf·cm, ft·lbf) : Specified torque
20 (204, 15)
20 (204, 15)
− BODYFRONT WIPER AND WASHER
BO−11
1895 Author: Date:
1996 TOYOTA T100 (RM449U)
FRONT WIPER AND WASHER
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine BO0E2−02
N12590
BO−12
− BODYFRONT WIPER AND WASHER
1996 TOYOTA T100 (RM449U)
REMOVAL
1. REMOVE WIPER ARMS
Torque: 20 N·m (204 kgf·cm, 15 ft·lbf)
2. REMOVE COWL LOUVER
3. REMOVE WIPER MOTOR
(a) Disconnect the connector, then unfasten 4 bolts.
(b) Connect the claw of the wiper link to the panel.
(c) Disconnect the motor from the wiper link and remove it.
4. REMOVE WIPER LINK
5. REMOVE WINDOW WASHER NOZZLE

Downloaded from www.Manualslib.com manuals search engine BO0E3−02
N05675
BB A
C A
C
− BODYFRONT WIPER AND WASHER
BO−13
1996 TOYOTA T100 (RM449U)
INSPECTION
INSPECT WASHER NOZZLE
(a) While operating the washer, check whether the upper
point where the washer fluid hits the windshield and the
surge area are within the range indicated by the hatched
line.
A: Approx. 150 mm (5.91 in.)
B: Approx. 50 mm (1.97 in.)
C: Approx. 0 − 50 mm (0 − 1.97 in.)
(b) Check if the lower point where the washer fluid hits the
windshield is within the range of the wiping pattern the
area of the glass which is wiped by the wiper blades.

Downloaded from www.Manualslib.com manuals search engine BO0E4−02
BE3367
2 − 2.5 mm
(0.079 −0.098 in.)
0.7 − 0.75 mm
(0.028 −0.030 in.) BO−14
− BODYFRONT WIPER AND WASHER
1996 TOYOTA T100 (RM449U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like that shown in the figure, change the direction
of the nozzle hole to adjust the point where washer fluid strikes
the windshield.

Downloaded from www.Manualslib.com manuals search engine BO0E5−01
− BODYFRONT WIPER AND WASHER
BO−15
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page BO−12).

Downloaded from www.Manualslib.com manuals search engine BO0E6−02
N12569H01707
Front Wheel
Arch Moulding
Rear Wheel
Arch Moulding BO−16
− BODYWHEEL ARCH MOULDING
1900 Author: Date:
1996 TOYOTA T100 (RM449U)
WHEEL ARCH MOULDING
COMPONENTS
