1996 TOYOTA T100 engine

Downloaded from www.Manualslib.com manuals search engine BO0EC−02
N15352
Back Panel Upper Garnish
Back Panel Lower GarnishRear Seat CushionQuarter Window Glass
Back Panel TrimRear Seat
Outer Belt
Front Seat Quarter Trim
Outer Belt
43 (440, 32)
9.8 (100, 7)
43 (440, 32)
43 (440, 32)
43 (440, 32)
N·m (kgf·cm, ft·lbf) : Specifeid torque
9.8 (100, 7)
− BODYQUARTER WINDOW GLASS
BO−25
1909 Author: Date:
1996 TOYOTA T100 (RM449U)
QUARTER WINDOW GLASS
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine BO0ED−03
N13374
10 clips
N13376
N1337711 clips 6 clips BO−26
− BODYQUARTER WINDOW GLASS
1996 TOYOTA T100 (RM449U)
REMOVAL
1. REMOVE FRONT PILLAR GARNISH
2. REMOVE DOOR SCUFF PLATE
3. REMOVE ASSIST GRIP
4. REMOVE BACK PANEL UPPER GARNISH AND BACK
PANEL TRIM
(a) Insert a screwdriver between the back panel upper gar-
nish and body to remove the back panel upper garnish.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 3 bolts and back panel trim.
Torque: 9.8 N·m (100 kgf·cm, 7 in.·lbf)
5. REMOVE REAR SEAT CUSHION
(a) Remove the 3 clips and back panel lower garnishes.
(b) Remove the 2 bolts and rear seat cushion.
Torque: 9.8 N·m (100 kgf·cm, 7 in.·lbf)
6. REMOVE SEAT BELT
Remove the 4 bolts, seat belt anchor and belt guide.
Torque: 43 N·m (440 kgf·cm, 32 ft·lbf)
7. REMOVE LOCK HANDLE
HINT:
Tape a screwdriver tip before use.
(a) Using a screwdriver, remove the cover.
(b) Remove the 2 screws.
8. REMOVE QUARTER TRIM
Remove the 17 clips and quarter trim.

Downloaded from www.Manualslib.com manuals search engine N13378
N13379
− BODYQUARTER WINDOW GLASS
BO−27
1996 TOYOTA T100 (RM449U)
9. REMOVE QUARTER WINDOW GLASS
(a) Remove the 4 nuts and quarter window glass.
(b) Remove the screw and lock handle from the quarter win-
dow glass.
(c) Remove the 2 screws and hinges from the quarter win-
dow glass.

Downloaded from www.Manualslib.com manuals search engine BO0EE−01
BO−28
− BODYQUARTER WINDOW GLASS
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page BO−26).

Downloaded from www.Manualslib.com manuals search engine BO0EF−03
Z14390
Weatherstrip
Back WindowBack Window Assembly (Slide Type)
Glass Channel Slide GlassStopperFix Frame
Weatherstrip
− BODYBACK WINDOW GLASS
BO−29
1913 Author: Date:
1996 TOYOTA T100 (RM449U)
BACK WINDOW GLASS
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine BO0EG−03
BO3301
Weatherstrip
Body
Z04539
Weatherstrip BO−30
− BODYBACK WINDOW GLASS
1996 TOYOTA T100 (RM449U)
REMOVAL
REMOVE BACK WINDOW GLASS WITH WINDOW FRAME
HINT:
Tape a screwdriver tip before use.
(a) Using a screwdriver, loosen the weatherstrip from the
body.
NOTICE:
Be careful not to damage the body paint.
(b) Pry the lip of the weatherstrip outward from the interior
part of the body flange.
(c) Pull the glass outwards, and remove it with the weather-
strip.

Downloaded from www.Manualslib.com manuals search engine BO0EH−02
Z04533
BO0050
BO0051
BO0052
− BODYBACK WINDOW GLASS
BO−31
1996 TOYOTA T100 (RM449U)
DISASSEMBLY
1. REMOVE STOPPER
2. REMOVE FIX FRAMES
3. REMOVE SLIDE GLASS
Pull apart the channels and remove the 2 slide glass panes at
the center area of the glass channel.
4. REMOVE NON−SLIDE GLASS
(a) Pull apart the channels and remove the 2 fix frames, as
shown.
(b) Pull apart the channels and remove the 2 non−slide glass
panes, as shown.
HINT:
At the time of reassembly, please refer to the following item.
Apply soapy water to the contact surface of the weatherstrip
and glass channel flange.

Downloaded from www.Manualslib.com manuals search engine BO0EI−01
BO−32
− BODYBACK WINDOW GLASS
1996 TOYOTA T100 (RM449U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO−31).
