Page 331 of 1354

S01830
Fuel Inlet Hose
P25066
− DIAGNOSTICSENGINE
DI−11
1996 RAV4 (RM447U)
7 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Turn ignition switch ON.
(c) Connect the TOYOTA hand−held tester to DLC3 on the
vehicle.
(d) Use ACTIVE TEST mode to operate the fuel pump.
(e) If you have no TOYOTA hand−held tester, connect the
positive (+) and negative (−) leads from the battery to the
fuel pump connector (See page SF−5).
CHECK:
Check for fuel pressure in the inlet hose when it is pinched off.
HINT:
At this time, you will hear a fuel flowing noise.
NG Proceed to page SF−5 and continue to trouble-
shoot.
OK
8 Check for spark.
PREPARATION:
(a) Disconnect the high−tension cord from spark plug.
(b) Remove spark plug.
(c) Install spark plug to high−tension cord.
(d) Disconnect injector connector.
(e) Ground the spark plug.
CHECK:
Check if spark occurs while engine is being cranked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, do not crank the engine for more than 5 −
10 seconds at a time.
NG Proceed to page IG−1 and continue to trouble-
shoot.
OK
Proceed to matrix chart of problem systems
on page DI−20.
Page 333 of 1354

− DIAGNOSTICSENGINE
DI−13
1996 RAV4 (RM447U)
(b) TOYOTA Enhanced Signals
TOYOTA hand−held tester displayMeasurement ItemNormal Condition *
MISFIRE RPMEngine RPM for first misfire rangeMisfire 0: 0 RPM
MISFIRE LOADEngine load for first misfire rangeMisfire 0: 9 g/r
INJECTORFuel injection time for cylinder No.1Idling: 1.9 − 3.3 ms
IAC DUTY RATIOIntake Air Control Valve Duty Ratio Opening
ratio rotary solenoid type IAC valveIdling: 25 − 60 %
STARTER SIGStarter SignalCranking: ON
A/C SIGA/C Switch SignalA/C ON: ON
PNP SWPark / Neutral Position Switch SignalP or N position: ON
ELCTRCL LOAD SIGElectrical Load SignalDefogger S/W ON: ON
STOP LIGHT SWStop Light Switch SignalStop light switch ON: ON
FC IDLFuel Cut Idle: Fuel cut when throttle valve fully
closed, during decelerationFuel cut operating: ON
FC TAUFuel Cut TAU: Fuel cut during very light loadFuel cut operating: ON
CYL#1
CYL#2
CYL#3
CYL#4
Abnormal revolution variation for each cylinder0 %
IGNITIONTotal number of ignitions for every 1,000
revolutions0 − 2,000
EGR SYSTEMEGR system operating conditionIdling: OFF
FUEL PUMPFuel Pump SignalIdling: ON
EVAP (PURGE) VSVEVAP VSV SignalVSV operating: ON
VAPOR PRESS VSVVapor Pressure VSV SignalVSV operating: ON
A/C CUT SIGA/C Cut SignalA/C S/W OFF: ON
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 1Idling: 0.8 − 1.2
O2 LR B1, S1
Oxygen Sensor Lean Rich Bank 1, Sensor 1
Response time for oxygen sensor output to
switch from lean to rich.
Idling after warned up: 0 − 1,000 msec.
O2 RL B1, S1
Oxygen Sensor Rich Lean Bank 1, Sensor 1
Response time for oxygen sensor output to
switch from rich to lean.
Idling after warned up: 0 − 1,000 msec.
*: If conditions are specifically stated for ”Idling” , it means the shift lever is at N or P Position, the A/C switch
is OFF and all accessory switches are OFF.
Page 340 of 1354

DI3ZB−02
DI−20
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
PROBLEM SYMPTOMS TABLE
When the malfunction code is not confirmed the DTC check and the problem still can not be confirmed in
the basic inspection, then proceed to this step and perform troubleshooting according to the numbered order
given in the table below.
SymptomSuspect AreaSee page
Does not start (Engine does not crank1. Starter and starter relayST Section
Does not start (No combustion)
1. ECM power source circuit
2. Fuel pump control circuit
3. Engine control module (ECM)DI−11 3
DI−11 6
IN−30
Does not start (No complete combustion)1. Fuel pump control circuitDI−11 6
Difficult to start (Engine cranks normally)1. Fuel pump control circuit
2. CompressionDI−11 6
EM−3
Difficult to start (Cold engine)1. Starter signal circuit
2. Fuel pump control circuitDI−105
DI−11 6
Difficult to start (Hot engine)1. Starter signal circuit
2. Fuel pump control circuitDI−105
DI−11 6
Poor idling (High engine idle speed)1. A/C signal circuit
2. ECM power source circuitAC−64
DI−11 3
Poor idling (Low engine idle speed)1. A/C signal circuit
2. Fuel pump control circuitAC−64
DI−11 6
Poor idling (Rough idling)1. Compression
2. Fuel pump control circuitEM−3
DI−11 6
Poor idling (Hunting)1. ECM power source circuit
2. Fuel pump control circuitDI−11 3
DI−11 6
Poor Driveability (Hesitation / Poor acceleration)
1. Fuel pump control circuit
2. A/T faulty
3. A/C cut control circuitDI−11 6
DI−141
DI−122
Poor Driveability (Surging)1. Fuel pump control circuitDI−11 6
Engine stall (Soon after starting)1. Fuel pump control circuitDI−11 6
Engine stall (During A/C operation)1. A/C signal circuit
2. Engine control module (ECM)AC−64
IN−30
Page 369 of 1354
− DIAGNOSTICSENGINE
DI−49
1996 RAV4 (RM447U)
2 Check for oxygen sensor data.
PREPARATION:
(a) Connect the OBDII scan tool or TOYOTA hand−held tester to the DLC3.
(b) Warm up engine to normal operating temperature.
CHECK:
Read the oxygen sensor output voltage and short−term fuel trim.
RESULT:
PatternOxygen sensor output voltageShort−term fuel trim
1Lean condition (Changes at 0.55 V or less)Changes at about +20 %
2Rich condition (Changes at 0.35 V or more)Changes at about −20 %
3Except 1 and 2
3 Check for oxygen sensor
(See page DI−42).
1, 2
3 Check fuel pressure (See page SF−5).
NG Check and repair fuel pump, pressure regulator,
fuel pipe line and filter (See page SF−1).
OK
4 Check injector injection (See page SF−21).
NG Replace injector.
OK
5 Check manifold absolute pressure sensor and engine coolant temp. sensor
(See page DI−21, DI−29).
NG Repair or replace.
OK
Page 436 of 1354
S02410
EFI
MAIN No.1
IG Switch AM2
MAIN
FL
BatteryPark/Neutral
Position Switch
(Clutch Start
Switch)EFI Main
RelayCircuit Opening
Relay
Fuel Pump
ECM
FC
Tr
STA
NE (STA Signal)
(NE Signal) Starter IGN
ST Relay DI−11 6
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
Fuel Pump Control Circuit
CIRCUIT DESCRIPTION
In the diagram below, when the engine is cranked, current flows from terminal ST of the ignition switch to
the starter relay coil and also current flows to terminal STA of ECM (STA signal).
When the STA signal and NE signal are input to the ECM, Tr is turned ON, current flows to coil of the circuit
opening relay, the relay switches on, power is supplied to the fuel pump and the fuel pump operates.
While the NE signal is generated (engine running), the ECM keeps Tr ON (circuit opening relay ON) and the
fuel pump also keeps operating.
DI407−02
Page 437 of 1354
S07291
ECM
E1 FC 14
E6 G−R
ID1 4 R/B No.5
5
5 5
53
12 5
Circuit Opening
Relay
Fuse Block
10 11
L−B
B−O 11 17 2
1J
1E1
9 8
3
131E
1D
1D
1H
Fuel
Pump
L−B
W−BBH
IB111
B−R
6 5
1 3
2
EFI Main RelayR/B No.6
B−R
B−R
B−W
B−W
B−W (M/T) B−R
B
B R
IG1
IG12
1
Clutch Start
Switch10 IG111
EA
12 2 17
16
20
21
6 6 6
10 B−R A
W−BW−B
J1
Junction
Connector
W−BA A
EA1 B
BB
WEA1
810
652 3 B (A/T)
Starter S31
Battery
Fusible
Link
Block 252
2
2
2 2 21
3ST Relay MAIN
No.1AM2EFI
56
MAINR−W
B−R
*
1
*1*2
*2
EA1
*1: 2WD
*2: 4WDJ/B
No.1B−O
IGN B−O
IG Switch
8 76 R/B No.2
54 B−O
Park/Neutral
Position Switch
− DIAGNOSTICSENGINE
DI−11 7
1996 RAV4 (RM447U)
WIRING DIAGRAM
Page 438 of 1354
DI−11 8
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
INSPECTION PROCEDURE
TOYOTA hand−held tester
1 Connect the TOYOTA hand−held tester and check operation of fuel pump (See
page SF−5).
OK Check for starter signal circuit (See page
DI−105).
NG
2 Check for ECM power source circuit (See page DI−11 3).
NG Repair or replace.
OK
3 Check circuit opening relay (See page SF−41).
NG Replace circuit opening relay.
OK
Page 439 of 1354
A00424
FC
(+)
ON
− DIAGNOSTICSENGINE
DI−11 9
1996 RAV4 (RM447U)
4 Check voltage between terminal FC of ECM and body ground.
PREPARATION:
(a) Remove side trim cover (See page SF−61).
(b) Turn ignition switch ON.
CHECK:
Measure voltage between terminal FC of ECM and body
ground.
OK:
Voltage: 9 − 14 V
NG Check for open in harness and connector be-
tween EFI main relay (Marking: EFI) and circuit
opening relay, circuit opening relay and ECM.
OK
5 Check fuel pump (See page SF−5).
NG Repair or replace fuel pump.
OK
6 Check for open in harness and connector between circuit opening relay and fuel
pump, fuel pump and body ground (See page IN−30).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN−30).
