1996 TOYOTA RAV4 Engine

FI2553
SST
S01837
Fuel
Pump
Connector
S01832
Plug SF−2
− SFISFI SYSTEM
1996 RAV4 (RM447U)
(b) When installing the battery, be especially careful not to in-
correctly connect the positive (+) and negative (−) cables.
(c) Do not permit parts to receive a severe impact during re-
moval or installation. Handle all SFI parts carefully, espe-
cially the ECM.
(d) Do not be careless during troubleshooting as there are
numerous transistor circuits and even slight terminal con-
tact can cause further troubles.
(e) Do not open the ECM cover.
(f) When inspecting during rainy weather, take care to pre-
vent entry of water. Also, when washing the engine
compartment, prevent water from getting on the SFI parts
and wiring connectors.
(g) Parts should be replaced as an assembly.
(h) Care is required when pulling out and inserting wiring con-
nectors.
(i) Release the lock and pull out the connector, pulling on the
connectors.
(j) Fully insert the connector and check that it is locked.
(k) Use SST for inspection or test of the injector or its wiring
connector.
SST 09842−30070
8. FUEL SYSTEM
(a) When disconnecting the high fuel pressure line, a large
amount of gasoline will spill out, so observe the following
procedures:
(1) Disconnect the fuel pump connector.
(2) Start the engine. After the engine has stopped on
its own, turn the ignition switch to LOCK.
(3) Put a container under the connection.
(4) Slowly loosen the connection.
(5) Disconnect the connection.
(6) Plug the connection with a rubber plug.

S01831
New Gasket
FI1654
Fulcrum Length
30 mm
SST
FI0420
O−Ring
Injector
GrommetDelivery PipeCORRECT
WRONG
P15485
O−Ring
Injector Grommet
O−Ring Insulator
− SFISFI SYSTEM
SF−3
1996 RAV4 (RM447U)
(b) When connecting the flare nut or union bolt on the high
pressure pipe union, observe the following procedures:
(1) Union Bolt Type:
Always use 2 new gaskets.
(2) Union Bolt Type:
Tighten the union bolt by hand.
(3) Union Bolt Type:
Tighten the union bolt to the specified torque.
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(4) Flare Nut Type:
Apply a light coat of engine oil to the flare nut, and
tighten the flare nut by hand.
(5) Flare Nut Type:
Using SST, tighten the flare nut to specified torque.
SST 09631−22020
NOTICE:
Do not rotate the fuel pipe, when tightening the flare nut.
Torque: 34 N·m (350 kgf·cm, 25 ft·lbf)
28 N·m (285 kgf·cm, 21 ft·lbf) for SST
HINT:
Use a torque wrench with a fulcrum length of 30 cm (11.81 in.).
(c) Observe the following precautions when removing and
installing the injectors.
(1) Never reuse the O−ring.
(2) When placing a new O−ring on the injector, take
care not to damage it in any way.
(3) Coat a new O−ring with spindle oil or gasoline be-
fore installing−never use engine, gear or brake oil.
(4) Install the injector to the delivery pipe and intake
manifold as shown in the illustration.

S01354
TOYOTA
Hand−Held Tester
S01830
Fuel Inlet Hose SF−4
− SFISFI SYSTEM
1996 RAV4 (RM447U)
(d) Check that there are no fuel leaks after performing main-
tenance anywhere on the fuel system.
(1) Connect the TOYOTA hand−held tester to the
DLC3.
(2) Turn the ignition switch ON and TOYOTA hand−
held tester main switch ON.
NOTICE:
Do not start the engine.
(3) Select the active test mode on the TOYOTA hand−
held tester.
(4) Please refer to the TOYOTA hand−held tester oper-
ator ’s manual for further details.
(5) If you have no TOYOTA hand−held tester, connect
the positive (+) and negative (−) leads from the bat-
tery to the fuel pump connector (See page
SF−5).
(6) Pinch the fuel inlet hose.
The pressure in the high pressure line will rise to
approx. 400 kPa (4 kgf/cm
2, 57 psi). In this state,
check that there are no leaks from any part of the
fuel system.
NOTICE:
Always pinch the hose. Avoid bending as it may cause the
hose to crack.
(7) Turn the ignition switch to LOCK.
(8) Disconnect the TOYOTA hand−held tester from the
DLC3.
(9) Start the engine.
NOTICE:
Keep cranking the engine until the air is removed from the
fuel line.
(10) After the engine starts, check again that there are
no fuel leaks.

S01354
TOYOTA
Hand−Held Tester
SF0Q5−03
S01830
Fuel Inlet Hose
S01827
− SFIFUEL PUMP
SF−5
1996 RAV4 (RM447U)
FUEL PUMP
ON−VEHICLE INSPECTION
1. CHECK FUEL PUMP OPERATION
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Turn the ignition switch ON and TOYOTA hand−held tes-
ter main switch ON.
NOTICE:
Do not start the engine.
(c) Select the active test mode on the TOYOTA hand−held
tester.
(d) Please refer to the TOYOTA hand−held tester operator’s
manual for further details.
(e) If you have no TOYOTA hand−held tester, connect the
positive (+) and negative (−) leads from the battery to the
fuel pump connector (See page SF−5).
(f) Check that there is pressure in the fuel inlet hose from the
fuel filter.
HINT:
If there is fuel pressure, you will hear the sound of fuel flowing.
If there is no pressure, check the H−fuse, fuses, EFI main relay,
circuit opening relay, fuel pump, ECM and wiring connections.
(g) Turn the ignition switch to LOCK.
(h) Disconnect the TOYOTA hand−held tester from the
DLC3.
2. CHECK FUEL PRESSURE
(a) Check the battery positive voltage is above 12 V.
(b) Disconnect the negative (−) terminal cable from the bat-
tery.
(c) Remove the air cleaner assembly (See page ST−4).
(d) Remove the 2 bolts, and disconnect the engine comport-
ment R/B No.2 from the bracket on the body.
(e) Remove the union bolt and 2 gaskets, and disconnect the
fuel inlet hose from the fuel filter outlet.
CAUTION:
Put a shop towel under the fuel filter. Slowly loosen the
union bolt.

S01834
Gasket
SST (Union)
SST
Fuel Inlet Hose Gasket
SST (Union)
S01835
301 − 347 kPa
S01836
For 5 Minutes After Engine has Stopped
147 kPa
or More SF−6
− SFIFUEL PUMP
1996 RAV4 (RM447U)
(f) Install the fuel inlet hose and SST (pressure gauge) to the
fuel filter outlet with the 3 gaskets and SST (union bolt).
SST 09268−45012
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(g) Wipe off any splattered gasoline.
(h) Connect the TOYOTA hand−held tester to the DLC3.
(i) Reconnect the negative (−) terminal cable to the battery.
(j) Turn the ignition switch ON.
(k) Measure the fuel pressure.
Fuel pressure:
301 − 347 kPa (3.1 − 3.5 kgf/cm
2, 44 − 50 psi)
If pressure is high, replace the fuel pressure regulator.
If pressure is low, check these parts:
Fuel hoses and connections
Fuel pump
Fuel filter
Fuel pressure regulator
(l) Remove the TOYOTA hand−held tester from the DLC3.
(m) Start the engine.
(n) Measure the fuel pressure at idle.
Fuel pressure:
301 − 347 kPa (3.1 − 3.5 kgf/cm
2, 44 − 50 psi)
(o) Stop the engine.
(p) Check that the fuel pressure remains as specified for 5
minutes after the engine has stopped.
Fuel pressure:
147 kPa (1.5 kgf/cm
2, 21 psi) or more
If pressure is not as specified, check the fuel pump, pressure
regulator and/or injectors.
(q) After checking fuel pressure, disconnect the negative (−)
terminal cable from the battery and carefully remove the
SST to prevent gasoline from splashing.
SST 09268−45012
(r) Reconnect the fuel inlet hose with 2 new gaskets and the
union bolt.
Torque: 29 N·m (300 kgf·cm, 21 ft·lbf)
(s) Reconnect the negative (−) terminal cable to the battery.
(t) Check for fuel leakage (See page SF−1).
(u) Reinstall the engine comportment R/B No.2 and air clean-
er assembly.
3. CHECK FUEL PUMP
(a) Remove the LH rear seat assembly.
(b) Remove the floor service hole cover.

S01952
Sound
ScopeSF0QG−02
S01950
Ohmmeter SF−16
− SFIINJECTOR
1996 RAV4 (RM447U)
INJECTOR
ON−VEHICLE INSPECTION
1. INSPECT INJECTOR OPERATION
Check operation sound from each injector.
(1) With the engine running or cranking, use a sound
scope to check that there is normal operating noise
in proportion to engine speed.
(2) If you have no sound scope, you can check the in-
jector transmission operation with your finger.
If no sound or unusual sound is heard, check the wiring connec-
tor, injector or injection signal from the ECM.
2. INSPECT INJECTOR RESISTANCE
(a) Remove the cylinder head cover (See page EM−33).
(b) Disconnect the injector connectors.
(c) Using an ohmmeter, measure the resistance between the
terminals.
Resistance: Approx. 13.8 Ω
If the resistance is not as specified, replace the injector.
(d) Reconnect the injector connectors.
(e) Reinstall the cylinder head cover (See page EM−55).

SF0QI−03
S01903
S01939
(1)
(2)
S01827
S01949
Disconnect
Spacer
− SFIINJECTOR
SF−19
1996 RAV4 (RM447U)
REMOVAL
1. REMOVE AIR CLEANER ASSEMBLY (See page
ST−4)
2. REMOVE CYLINDER HEAD COVER (See page
EM−33)
3. DISCONNECT THROTTLE BODY FROM INTAKE MAN-
IFOLD (See page SF−30)
4. REMOVE DISTORIBUTOR (See page IG−9)
5. DISCONNECT ENGINE WIRE FROM INTAKE MAN-
IFOLD
(a) Disconnect the 4 injector connectors.
(b) Disconnect the 2 clamps of the engine wire from the wire
brackets on intake manifold.
(c) Remove the bolt, and disconnect the engine wire protec-
tor from the RH side of the intake manifold.
(d) Disconnect the clamp of the engine wire from the wire
clamp.
6. REMOVE EGR VALVE AND PIPE
(a) Disconnect these hoses from the EGR valve:
(1) Vacuum hose from port E of VSV
(2) EGR hose from vacuum modulator
(b) Loosen the cylinder head side of the EGR pipe union nut.
(c) Remove the 2 nuts, the EGR valve, pipe assembly and
gasket.
7. DISCONNECT ENGINE COMPORTMENT R/B NO.2
8. REMOVE FUEL INLET HOSE AND DELIVERY PIPE
(a) Remove the union bolt and 2 gaskets, and disconnect the
fuel inlet hose from the fuel filter outlet.
CAUTION:
Put a shop towel under the fuel filter. Slowly loosen the
union bolt.
(b) Disconnect the air hose for the air assist system from the
intake manifold port, and remove the air hose.
(c) Loosen the 2 bolts holding the delivery pipe to the cylinder
head.
(d) Disconnect the delivery pipe from the 4 injectors, and re-
move the delivery pipe and fuel inlet hose assembly.
9. REMOVE INJECTORS AND SPACERS
(a) Remove the 4 injectors and 2 spacers from the cylinder
head.
NOTICE:
Be careful not to drop the injectors and spacers.

SF0QJ−04
S01900
Union Bolt
SST (Union)SST
(Hose)SST
(Clamp)
Injector Fuel Filter
(On−Vehicle)SST
(Union)
S01833
Union Bolt
SST
(Hose)
Fuel FilterSST
(Union)
Gasket
P25498
SST
(Hose)
SST
(Clamp) SST
(Union)
O−Ring
Vinyl
Tube
S01354
TOYOTA
Hand−Held Tester
− SFIINJECTOR
SF−21
1996 RAV4 (RM447U)
INSPECTION
1. INSPECT INJECTOR INJECTION
CAUTION:
Keep injector clear of sparks during the test.
(a) Connect SST (union and hose) to the fuel filter outlet with
the 2 gaskets and union bolt.
SST 09268−41046 (90405−09015)
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
HINT:
Use the vehicle’s fuel filter.
(b) Install the grommet and O−ring to the injector.
(c) Connect SST (union and hose) to the injector, and hold
the injector and union with SST (clamp).
SST 09268−41046
(d) Put the injector into a graduated cylinder.
HINT:
Install a suitable vinyl hose onto the injector to prevent gasoline
from splashing out.
(e) Connect the TOYOTA hand−held tester to the DLC3.
(f) Turn the ignition switch ON and TOYOTA hand−held tes-
ter main switch ON.
NOTICE:
Do not start the engine.
(g) Select the active test mode on the TOYOTA hand−held
tester.
(h) Please refer to the TOYOTA hand−held tester operator’s
manual for further details.
(i) If you have no TOYOTA hand−held tester, connect the
positive (+) and negative (−) leads from the battery to the
fuel pump connector (See page SF−5).
