1996 TOYOTA LAND CRUISER sensor

DI−148
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
No down−
shift (O/D → 3rd)
1. Shift solenoid valve No. 1 and No. 2 circuit
2. Throttle position sensor circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. On−vehicle repair matrix chart
6. ECMDI−157 DI−35
DI−87
DI−166 −
DI−145
No down −shift (3rd → 2nd)
1. Shift solenoid valve No. 1 and No. 2 circuit
2. Throttle position sensor circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. On−vehicle repair matrix chart
6. ECMDI−157 DI−35
DI−87
DI−166 −
DI−145
No down −shift (2nd → 1st)
1. Shift solenoid valve No. 1 and No. 2 circuit
2. Throttle position sensor circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. On−vehicle repair matrix chart
6. Off −vehicle repair matrix chart
7. ECMDI−157 DI−35
DI−87
DI−166 −
−
DI−145
Lock− up does not engage
1. Shift solenoid valve SL circuit
2. Throttle position sensor circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. Stop light switch circuit
6. Park/neutral position switch circuit
7. Engine coolant temp. sensor circuit
8. On −vehicle repair matrix chart
9. Off −vehicle repair matrix chart
10.ECMDI−163
DI−35
DI−87
DI−166
DI−185
DI−169 DI−30 −
−
DI−145
Lock− up does not disengage
1. Shift solenoid valve SL circuit
2. Throttle position sensor circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. Stop light switch circuit
6. On −vehicle repair matrix chart
7. Off −vehicle repair matrix chart
8. ECMDI−163 DI−35
DI−87
DI−166
DI−185 −
−
DI−145
Shift point too high or too low
1. Throttle position sensor circuit
2. Pattern select switch circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. ECMDI−35
DI−179 DI−87
DI−166
DI−145
Up− shifts to 2nd while in L position
Up− shifts to 3rd while in L position1. Park/neutral position switch circuit
2. ECMDI−169
DI−145
Up− shifts to O/D from 3rd while O/D main switch is OFF1. O/D main switck& O/D OFF indicator light circuit
2. ECMDI−174
DI−145
Up−shift to O/D from 3rd while engine is cold
1. Engine coolant temp. sensor circuit
2. On −vehicle repair matrix chart
3. Off −vehicle repair matrix chart
4. ECMDI−30 −
−
DI−145
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−149
1996 LAND CRUISER (RM451U)
Harsh engagement (N
→ D)
1. Shift solenoid valve SL circuit
2. ATF temp. sensor circuit
3. Throttle position sensor circuit
4. Park/neutral position switch circuit
5. On −vehicle repair matrix chart
6. Off −vehicle repair matrix chart
7. ECMDI−163
DI−154 DI−35
DI−169 −
−
DI−145
Harsh engagement (Lock −up)
1. Shift solenoid valve SL circuit
2. Throttle position sensor circuit
3. No. 1 vehicle speed sensor circuit
4. No. 2 vehicle speed sensor circuit
5. On −vehicle repair matrix chart
6. Off −vehicle repair matrix chart
7. ECMDI−163 DI−35
DI−87
DI−166 −
−
DI−145
Harsh engagement (Any driving position)
1. Shift solenoid valve SL circuit
2. ATF temp. sensor circuit
3. Throttle position sensor circuit
4. No. 1 vehicle speed sensor circuit
5. No. 2 vehicle speed sensor circuit
6. On −vehicle repair matrix chart
7. Off −vehicle repair matrix chart
8. ECMDI−163
DI−154 DI−35
DI−87
DI−166
−
−
DI−145
Slip or shudder (Forward and reverse)1. On −vehicle repair matrix chart
2. Off −vehicle repair matrix chart−
−
Slip or shudder (A particular position)1. On −vehicle repair matrix chart
2. Off −vehicle repair matrix chart−
−
No engine braking1. On −vehicle repair matrix chart
2. Off −vehicle repair matrix chart−
−
Poor acceleration
1. Throttle position sensor circuit
2. No. 1 vehicle speed sensor circuit
3. No. 2 vehicle speed sensor circuit
4. Shift solenoid valve No. 1 and No. 2 circuit
5. Shift solenoid valve SL circuit
6. On −vehicle repair matrix chart
7. Off −vehicle repair matrix chartDI−35
DI−87
DI−166
DI−157
DI−163 −
−
No kick− down
1. Throttle position sensor circuit
2. Shift solenoid valve No. 1 and No. 2 circuit
3. No. 1 vehicle speed sensor circuit
4. On−vehicle repair matrix chart
5. ECMDI−35
DI−157 DI−87 −
DI−145
No pattern select1. Pattern select switch circuit
2. ECMDI−179
DI−145
No 2nd start
1. Pattern select switch circuit
2. Shift solenoid valve No. 1 and No. 2 circuit
3. ECMDI−179
DI−157
DI−145
Large shift shock or engine stalls when starting off or stopping
1. Shift solenoid valve SL circuit
2. Stop light switch circuit
3. Off −vehicle repair matrix chart
4. ECMDI−163
DI−185 −
DI−145
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5KI−01
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−153
1996 LAND CRUISER (RM451U)
CIRCUIT INSPECTION
DTC P0500 Vehicle Speed Sensor Malfunction (No. 1 Vehicle Speed Sensor)
See page DI−87.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q04346
ATF Temperature SensorOIL
E5
R−W
BR−B
1 2
E2
E5 ECM
12 9 4 −
6 V
DI−154
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
DTC P0710 Transmission Fluid Temperature Sensor Cir-
cuit Malfunction (ATF Temperature Sensor)
CIRCUIT DESCRIPTION
The ATF temperature sensor converts fluid temperature into resistance value w\
hich is input into the ECM.
DTC No.DTC Detecting ConditionTrouble Area
P0710
Either (a) or (b) is detected for 0.5 sec. or more
(a) Temp. sensor resistance is less than 79 Ω
(b) After the engine has been operating for 15 min. or more, the resistance at the temp. sensor is more than 156 k ΩOpen or short in ATF temp. sensor circuit
 ATF temp. sensor
 ECM
WIRING DIAGRAM
DI5KK−02
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q07002
20°C and 110 °C
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−155
1996 LAND CRUISER (RM451U)
INSPECTION PROCEDURE
1 Check ATF temperature Sensor.
PREPARATION:
Remove the ATF temperature sensor.
CHECK:
Measure the resistance between terminals of the ATF tempera-
ture sensor at 20° C (68°F) and 110 °C (230° F).
OK:
Resistance :
20 °C (68° F): Approx. 12.2 kΩ
11 0 °C (230°F): Approx. 770 Ω
NG Replace ATF temperature sensor.
OK
2 Check harness and connector between ATF temperature sensor and ECM (See page IN−28 ).
NG Repair or replace harness or connector.
OK
Check and replace ECM.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q08221 Q08220D00081
(+) (−)
(+) (−)Air
DI−156
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
DTC P0750, P0755 Shift Solenoid A/B Malfunction (Shift Solenoid Valve No. 1/No. 2)
SYSTEM DESCRIPTION
The ECM uses signals from the vehicle speed sensor to detect the actual gea\
r position (1st, 2nd, 3rd or O/D
gear).
Then the ECM compares the actual gear with the shift schedule in the ECM mem\
ory to detect mechanical
trouble of the shift solenoid valves and valve body.
DTC No.DTC Detecting ConditionTrouble Area
P0750
P0755During normal driving, the gear required by the ECM does not
match the actual gear (2 trip detection logic)Shift solenoid valve No. 1/No. 2 is stuck open or closed
 Valve body is blocked up or stuck
HINT:
Check the shift solenoid valve No. 1 when DTC P0750 is output and check shift\
solenoid valve No. 2 when
DTC P0755 is output.
INSPECTION PROCEDURE
1 Check shift solenoid valve No. 1 or No. 2 operation.
PREPARATION:
(a) Remove the oil pan.
(b) Remove the shift solenoid valve No. 1 or No. 2.
CHECK:
(a) Applying 490 kPa (5 kgf/cm2, 71 psi) of compressed air,
check that the shift solenoid valve does not leak air.
(b) When battery positive voltage is supplied to the shift sole-
noid valves, check they opens.
NG Replace shift solenoid valve No. 1 or No. 2.
OK
2 Check valve body (See page DI−147 ).
NG Repair or replace valve body.
OK
Repair transmission (See page AT −18).
DI5KM−02
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

D00076
Line
PressureDrain
Q08219
Q08226
D00087
(+)
(−)
(+)(−)
Air
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−161
1996 LAND CRUISER (RM451U)
DTC P0770 Shift Solenoid E Malfunction
(Shift Solenoid Valve SL)
SYSTEM DESCRIPTION
The ECM uses the signals from the throttle position sensor, air −
flow meter and crankshaft position sensor to monitor the en-
gagement condition of the lock −up clutch.
Then the ECM compares the engagement condition of the
lock−up clutch with the lock −up schedule in the ECM memory
to detect mechanical trouble of the shift solenoid valve SL,
valve body and torque converter clutch.
DTC No.DTC Detecting ConditionTrouble Area
P0770
Lock− up does not occur when driving in the lock− up range
(normal driving at 80 km/h [50 mph] ), or lock− up remains ON
in the lock− up OFF range (2 trip detection logic)Shift solenoid valve SL is stuck open or closed
 Valve body blocked up or stuck
 Lock− up clutch
INSPECTION PROCEDURE
1 Check shift solenoid valve SL operation.
PREPARATION:
Remove the shift solenoid valve SL from the valve body.
CHECK:
(a) Applying 490 kPa (5 kgf/cm2, 71 psi) of compressed air,
check that the solenoid valve opens.
(b) When battery voltage is supplied to the shift solenoid
valve, check it does not leak air.
NG Replace shift solenoid valve SL.
OK
DI5KQ−02
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q07352 AT5605D00084
Rotor
No. 2 Vehicle Speed Sensor Rotor
No. 2 Vehicle Speed Sensor
AT8761
5 V/div.
0 V
2 msec./div.
DI−166
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
DTC P1700 Speed Sensor No. 2 Circuit Malfunction
(No. 2 Vehicle Speed Sensor)
CIRCUIT DESCRIPTION
The No. 2 vehicle speed sensor detects the rotation speed of the transmissi\
on output shaft and sends sig-
nals to the ECM. The ECM determines the vehicle speed based on these signals\
.
An AC voltage is generated in the No. 2 vehicle speed sensor coil as the r\
otor mounted on the output shaft
rotates, and this voltage is sent to the ECM.
The gear shift point and lock −up timing are controlled by the ECM based on the signals from this vehic\
le
speed sensor and the throttle position sensor signal.
If the No. 2 vehicle speed sensor malfunctions, the ECM uses input signa\
ls from the No. 1 vehicle speed
sensor as a back −up signal.
DTC No.DTC Detecting ConditionTrouble Area
P1700
All conditions below are detected 500 times or more continu-
ously (2 trip detection logic)
(a) No signal from No. 2 vehicle speed sensor is input to ECM while 4 pulses of No. 1 vehicle speed sensor signal is sent
(b) Vehicle speed: 9 km/h (5.6 mph) or more for as least 4 sec.
(c) Park/neutral position switch: OFF (Other than P or N posi-
tion)
(d) Transfer position: Other than N position
 Open or short in No. 2 vehicle speed sensor circuit
 No. 2 vehicle speed sensor
 ECM
Reference:
Waveform between terminals SP2
+ and SP2− when the vehicle
speed is approx. 60 km/h (37 mph).
