1996 TOYOTA COROLLA Owners Manual

60
For high beam, push the lever away
from you. Pull it toward you for low
beam. For the headlight flasher, pull it
further back.
A blue light in the instrument panel indi-
cates high beam is on.
The headlight flasher works even when
the headlight switch is off.For signaling turns, move the lever up
or down in the conventional manner.
The key must be in the ºONº position.
The turn signal is self-cancelling after a
turn, but after a lane change, you may
have to cancel it by hand. You can also
signal a lane change by moving the turn
signal lever partway and holding it there.
If the green light in the instrument panel
flashes faster than normal, it indicates
that the front or rear turn signal bulb has
burned out.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being
discharged, do not leave the switch
on longer than necessary when the
engine is not running.
Emergency flashers
ProCarManuals.com

61
To adjust the brightness of the instru-
ment panel lights, turn the dial.To turn on the interior light, slide the
switch.
With the switch in the DOORº position,
the light comes on when any of the side
doors and back door are opened.To turn on the personal light, push the
switch. To turn it off, push the switch
once again.
Instrument panel light control Interior light Personal light
ProCarManuals.com

62
To turn the luggage compartment light
on, open the back door and push the
switch. Closing the back door will turn
the light off.To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ºONº position.
The wipers will operate at intervals when
the lever is in the ºINTº position.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
Luggage compartment light
(wagon)Windshield wipers and washer
(intermittent type without
interval adjuster)
ProCarManuals.com

63
To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ONº position.
The wipers will operate at intervals when
the lever is in the INTº position. With the
lever in this position, the wipers can be ad-
justed to operate at intervals of 3 to 10 se-
conds depending on the interval adjuster
setting between Sº and Fº.
Also, the wipers will automatically operate
a couple of times after the washer squirts
even with the lever in the OFFº position.If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ONº position.
If a single wipe is desired in mist, push the
lever to the MISTº position and release it.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
Windshield wipers and washer
(intermittent type with interval
adjuster)Windshield wipers and washer
(mist type)
ProCarManuals.com

64
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
To turn the rear wiper and washer on,
twist the knob at the end of the lever.
The key must be in the ONº position.
The wipers will operate at intervals when
the lever is in the INTº position.
The washer squirts at the two marked knob
positions. The knob will automatically re-
turn from these positions when it is re-
leased.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
NOTICE
Do not operate the rear wiper if the
rear window is dry. It may scratch
the glass.
To defog or defrost the rear window,
push the switch.
The key must be in the ONº position.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
Push the switch once again to turn the de-
fogger off.
With timer: The system will automatically
shut off after the defogger has operated
about 15 minutes.
Rear window defogger Rear window wiper and washer
ProCarManuals.com

65
Make sure you turn the defogger off when
the window is clear. Leaving the defogger
on for a long time could cause the battery
to discharge, especially during stop-and-
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE
Without timer: To prevent the bat-
tery from being discharged, turn
the switch on when the engine is
running.
When cleaning the inside of the
rear window, be careful not to
scratch or damage the heater
wires.
ProCarManuals.com

66ProCarManuals.com

Part 1Fuel gauge
67
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-5
Gauges, Meters
and Service reminder
indicators

Fuel gauge

Engine coolant temperature
gauge

Tachometer

Odometer and trip meter

Service reminder indicators
and warning buzzers
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the
tank.
It is a good idea to keep the tank over 1/4
full.
This fuel gauge has a non-return type
needle which remains at the last indicated
position when the ignition switch is turned
off.
If the fuel level approaches Eº or the low
fuel level warning light comes on, fill the
fuel tank as soon as possible.
If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
