1996 TOYOTA COROLLA Owners Manual

100
If following another vehicle on a dusty
road, or driving in windy and dusty con-
ditions, it is recommended that the air
intake control lever be temporarily set
to the RECIRCULATED AIR position,
which will close off the outside pas-
sage and prevent outside air and dust
from entering the vehicle interior.
The side vents may be opened or
closed as shown.
Side Vents
ProCarManuals.com

Part 1Clock
Cigarette lighter and ashtray
101
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-8
Other equipment

Clock

Cigarette lighter and ashtray

Glovebox

Cup holder

Luggage cover

Floor mat
The digital clock indicates the time
with the ignition key at the ACCº or
ONº position. To reset the hour, de-
press the Hº button. To reset the min-
utes, depress the Mº button. To ad-
just the time to full hour, depress the
:00º button.
For example, if the :00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the time
will change to 2:00.
When the instrument panel lights are
turned on, the brightness of the time indi-
cation will be reduced.
Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (one
o'clock).To operate the cigarette lighter, press
it in. When it becomes heated, it auto-
matically pops out ready for use.
If the engine is not running, the key must
be in the ºACCº position.
Do not hold the cigarette lighter pressed
in.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, press it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull it out.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.
ProCarManuals.com

102
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.CAUTION
!
To open the glovebox door, compress
the lock release buttons.
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the glovebox
door closed while driving.CAUTION
!
To use the cup holder, push it and pull
it out completely.
The cup holder is designed for holding
cups or drinkÐcans fit snugly in its holes.

Do not place anything else on the
cup holder, as such items may be
thrown about and possibly injure
people in the vehicle during sud-
den braking or an accident.

Keep the cup holder shut when not
in use.CAUTION
! Glovebox Cup holder
ProCarManuals.com

103
To use the luggage cover, pull it out of
the retractor and hook it to the anchors.To remove the luggage cover, lift up
the luggage cover.Vehicles with rear speakersÐ
For more luggage space, remove the lug-
gage cover board.
Unlock the rear seatback and fold it down
slightly. Pull up the front of the luggage
cover board first, then pull the luggage
cover board toward you.
Luggage cover (wagon)
ProCarManuals.com

104
Use a floor mat of the correct size.
If the floor mat has a hole, then it is de-
signed for use with a locking clip. Fix the
floor mat and locking clip into the hole in
the floor carpet.
Make sure the floor mat is properly
placed on the floor carpet. If the
floor mat slips and interferes with
the movement of the pedals during
driving, it may cause an accident.CAUTION
! Floor mat
ProCarManuals.com

Part 2Break-in period
Fuel
105
INFORMATION
BEFORE DRIVING
YOUR TOYOTA

Break-in period

Fuel

Operation in foreign countries

Three-way catalytic converter

Engine exhaust cautions

Facts about engine oil
consumption

Brake system

Brake pad wear limit indicators

Luggage stowage precautions

Your Toyota's idenitification

Theft prevention labels

Suspension and chassis

Types of tires
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break-in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of your
vehicle:

Do not drive over 88 km/h (55 mph).

Avoid overrevving. Maintain engine
speed between 2000 and 4000 rpm.

Avoid full-throttle starts.

Try to avoid hard stops during the first
300 km (200 miles).

Do not drive slowly with the manual
transmission in a high gear.

Do not drive for a long time at any
single speed, either fast or slow.

Do not tow a trailer during the first 800
km (500 miles).FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mixups, your
Toyota has a new smaller fuel tank open-
ing. The special nozzle on pumps with un-
leaded fuel will fit it, but the larger standard
nozzle on pumps with leaded gas will not.
Do not use leaded gasoline. Use of
leaded gasoline will cause the three-
way catalytic converter to lose its ef-
fectiveness and the emission con-
trol system to function improperly.
Also, this can increase maintenance
costs.
NOTICE
OCTANE NUMBER
Select Research Octane Number 91
(Octane Rating 87) or higher.
Use of unleaded fuel with an octane num-
ber or rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage.
ProCarManuals.com

106If your engine knocks...
If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady speed on level roads, consult your
Toyota dealer.
However, now and then, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is no cause
for concern.
GASOLINES CONTAINING DETER-
GENT ADDITIVES
Toyota recommends use of gasolines
that contain detergent additives to
avoid build-up of engine deposits.
For further details, ask your Toyota dealer
or a local gasoline retailer.
GASOLINES CONTAINING MTBE
Gasolines that contain MTBE (Methyl
Tertiary-Butyl Ether) are available in
the market. If you use a gasoline mixed
with MTBE, make certain that it does
not contain more than 15% of MTBE.
If the use of gasolines containing MTBE
causes poor driveability and/or poor fuel
economy, you should discontinue the use
of fuels containing MTBE.GASOLINES CONTAINING ALCOHOL
If you use gasohol in your Toyota, be
sure that it is unleaded, has an octane
rating no lower than 87 and does not
contain more than 10% ethanol.
Gasohol is a mixture of gasoline and etha-
nol.
Toyota does not recommend the use of
gasolines containing methanol. If you use
gasoline containing methanol, use only
gasoline meeting the requirements above
and also containing less than 5% metha-
nol with cosolvents and corrosion inhibi-
tors for methanol.

Do not use gasohol other than
stated above. It will cause fuel
system damage or vehicle perfor-
mance problems.
If driveability problems are en-
countered (poor hot starting, va-
porizing, engine knock, etc), dis-
continue the use.
Take care not to spill gasohol dur-
ing refueling. Gasohol may cause
paint damage.
NOTICE
FUEL TANK CAPACITY
50 L (13.2 gal., 11.0 imp. gal.)If you plan to drive your Toyota in anoth-
er country...
First, comply with the vehicle registration
laws.
Second, confirm the availability of the
correct fuel (unleaded and minimum oc-
tane number).
Operation in foreign countries
ProCarManuals.com

107
The three-way catalytic converter is
an emission control device installed in
the exhaust system.
The purpose is to reduce pollutants in the
exhaust gas.
CAUTION!

Keep people and combustible ma-
terials away from the exhaust pipe
while the engine is running. The
exhaust gas is very hot.

Do not drive, idle or park your ve-
hicle over anything that might burn
easily such as grass, leaves, paper
or rags.
A large amount of unburned gases
flowing into the three-way catalytic
converter may cause it to overheat
and create a fire hazard. To prevent
this and other damage, observe the
following precautions:
Use only unleaded gasoline.
Do not drive with an extremely low
fuel level; running out of fuel
could cause the engine to misfire,
creating an excessive load on the
three-way catalytic converter.
Do not allow the engine to run at
idle speed for more than 20 min-
utes.
Avoid racing the engine.
Do not push-start or pull-start
your vehicle.
Do not turn off the ignition while
the vehicle is moving.
Keep your engine in good running
order. Malfunctions in the engine
electrical system, electronic igni-
tion system/distributor ignition
system or fuel system could cause
an extremely high three-way cata-
lytic converter temperature.
NOTICEIf the engine becomes difficult to
start or stalls frequently, take your
vehicle in for a check-up as soon
as possible. Remember, your Toyo-
ta dealer knows your vehicle and its
three-way catalytic converter sys-
tem best.
To ensure that the three-way cata-
lytic converter and the engine
emission control system operate
properly, your vehicle must re-
ceive the periodic inspections re-
quired by the Toyota Maintenance
Schedule. For scheduled mainte-
nance information, refer to the
separate Owner's Manual Sup-
plement/Maintenance Scheduleº.
Three-way catalytic converter
