1996 TOYOTA COROLLA Owners Manual

6
Anti-lock brake system warning light *1
Brake system warning light *1
Seat belt reminder light*1
Discharge warning light*1
Low oil pressure warning light*1
Malfunction indicator lamp*1
Open door warning light*1
SRS airbag warning light*1
Turn signal indicator lights
Headlight high beam indicator light
Overdrive-of f indicator light
Cruise control indicator light*
2
Rear window defogger indicator light
*
1: For details, see Service reminder indicators and warning
buzzersº in Chapter 1-5.
*
2: If this light flashes, see Cruise controlº in Chapter 1-6.
Indicator symbols on the instrument panel
ProCarManuals.com

Part 1Keys (sedan)
7
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-2
Keys and Doors

Keys

Side doors

Power windows

Trunk lid

Back door

Hood

Theft deterrent system

Fuel tank cap

Electric sun roof
The master key works in every lock.
The subkey will not work in the trunk.
To protect things locked in the trunk when
you have your vehicle parked, leave the
subkey with the attendant.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare master key in case you acci-
dentally lock your keys inside the vehicle.Keep the key number plate in a safe
place such as your wallet, not in the
vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.
ProCarManuals.com

8
The key works in every lock.
Since the side doors and back door can be
locked without a key, you should always
carry a spare master key in case you acci-
dentally lock your key inside the vehicle.Keep the key number plate in a safe
place such as your wallet, not in the
vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.LOCKING WITH KEY
Turn the key towards the front of the
vehicle to lock and towards the back to
unlock.
Vehicles with power door lock sys-
temÐAll the side doors and back door
lock and unlock simultaneously with either
front door. In the driver's door lock, turning
the key once will unlock the driver's door
and twice in succession will unlock all the
side doors and back door simultaneously.
Keys (wagon)Side doors
ProCarManuals.com

9
LOCKING WITH INSIDE LOCK BUTTON
Push in the lock button to lock and pull
it out to unlock.
Closing the door with the lock button
pushed in will also lock the door. Be care-
ful not to lock your keys in the vehicle.LOCKING WITH POWER DOOR LOCK
SWITCH
To lock all the side doors simulta-
neously, push the switch on the LOCK
side. Pushing on the UNLOCK side
will unlock them.
ProCarManuals.com

10
LOCKING WITH REAR DOOR CHILD-
PROTECTOR
Turn the lock knob to the LOCKº
position as shown on the label.
This feature allows you to lock a rear door
so it can be opened from the outside only,
not from inside. We recommend using this
feature whenever small children are in the
vehicle.
CAUTION!
Before driving, be sure that the
doors are closed and locked, espe-
cially when small children are in the
vehicle. Along with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also
helps prevent the doors from being
opened unintentionally.
The windows can be operated with the
switch on each door.
The ignition key must be in the ONº posi-
tion.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves
as long as you hold the switch.
To open: Lightly push down the switch.
To close: Pull up the switch.
Power windows
ProCarManuals.com

11
Automatic operation (to open only):
Push the switch completely down and
then release it. The window will fully open.
To stop the window partway, lightly pull the
switch up and then release it.
OPERATING THE PASSENGERS' WIN-
DOWS
Use the switch on each passenger's
door or the switch on the driver's door
that control each passenger's window.
The window moves as long as you hold
the switch.
For driver and front passenger's useÐ
To open: Push down the switch.
To close: Pull up the switch.
For rear passengers' use-
To open: Push on the lower side of the
switch.
To close: Push on the upper side of the
switch.
If you push in the window lock button on
the driver's door, the passenger's win-
dows cannot be operated.
ProCarManuals.com

12
CAUTION!
To avoid serious personal injury,
you must do the following.

Always make sure the head, hands
and other parts of the body of all oc-
cupants are kept completely inside
the vehicle before you close the
power windows. If someone's neck,
head or hands gets caught in a clos-
ing window, it could result in a seri-
ous injury. When anyone closes the
power windows, be sure that they
operate the windows safely.

When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock button
to prevent them from making unex-
pected use of the switches.

Never leave small children alone in
the vehicle, especially with the
ignition key still inserted. They
could use the power window
switches and get trapped in a win-
dow. Unattended children can be-
come involved in serious acci-
dents.
To open the trunk lid from the outside,
insert the master key and turn it clock-
wise.
See ºLuggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
To close the trunk lid, lower it and press
down on it. After closing the trunk lid, try
pulling it up to make sure it is securely
closed.
CAUTION!
Keep the trunk lid closed while driv-
ing. This not only keeps the luggage
from being thrown out but also pre-
vents exhaust gases from entering
the vehicle.
To open the trunk lid from the driver's
seat, pull up on the lock release lever.
Trunk lid (sedan)Ð ÐLock release lever
ProCarManuals.com

13
This system deactivates the lock re-
lease lever so that things locked in the
trunk can be protected.
1. Push down the security lock levers
to lock the rear seatbacks.
On vehicles with built-in child restraint,
only the left seatback has a lock lever and
can be lowered. The right seatback can-
not be folded down.
After locking the rear seatbacks, try fold-
ing them down to make sure they are se-
curely locked, otherwise, someone could
get into the trunk by folding down a rear
seat.2. After closing the trunk lid, insert the
master key and turn it counterclockwise
to deactivate the lock release lever.
After closing the trunk lid, try pulling it up
to make sure it is securely locked.This system deactivates the lock re-
lease lever so that things locked in the
trunk can be protected.
After closing the trunk lid, insert the
master key and turn it counterclockwise
to deactviate the lock release lever.
After closing the trunk lid, try pulling it up
to make sure it is securely closed.
ÐLuggage security system
(with fold-down rear seat)ÐLuggage security system
(without fold-down rear seat)
