1996 TOYOTA 4RUNNER Owners Manual

54
To turn on the personal light, push the
switch. To turn the lights off, push the
switch once again.To turn on the luggage compartment
light, slide the switch.
The luggage compartment light switch has the following positions: ONºÐ Keeps the light on all the time.
OFFºÐ Turns the light off.
DOORºÐ Turns the light on when the
back door is opened. The light goes off
when the back door is closed.For easy access to the ignition switch,
the ignition switch light comes on
when the driver's door is opened.
The light remains on for some time after
the driver's door is closed.
Ignition switch light
Personal lights Luggage compartment light

55
To turn on the windshield wipers, move the lever to the desired setting. The key must be in the ONº position.Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The INT TIMEº band lets you adjust the wiping time interval when the wiper lever is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it. To squirt washer fluid, pull the lever to-
ward you.
If the windshield wipers are off, they will
operate a
couple of times after the washer
squirts.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
In freezing weather, warm the windshield with the defroster before using the wash-
er. This will help prevent the washer fluid
from freezing on your windshield, which can block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the
glass.To turn on the windshield wipers, move the lever to the desired setting. The key must be in the ONº position.
Lever position
Speed setting
Position 1Slow
Position 2Fast
For a single sweep of the windshield, push the lever up and release it.
To squirt washer fluid, pull the lever to-
ward you.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
Windshield wipers and washer (intermittent type)
Windshield wipers andwasher (mist type)

56In freezing weather, warm the windshield with the defroster before using the wash-
er. This will help prevent the washer fluid
from freezing on your windshield, which can block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the
glass.
To turn on the back window wiper,
twist the lever knob upward. The key must be in the ONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Normal
To squirt washer fluid on the back window,
twist the knob upward or downward as far
as it will go (position 3 or 4). The knob au-
tomatically returns from these positions
after you release it.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
NOTICE
Do not operate the back window wipers if the back window is dry. It
may scratch the glass.
Back window wiper and washer

57
To defog or defrost the back window,
push the switch. The key must be in the ONº position.
The thin heater wires on the inside of the back window will quickly clear the surface.
An indicator light will illuminate to indicatethe defogger is operating. Push the switch once again to turn the de-
fogger off.
Make sure you turn the defogger off when
the window is clear. Leaving the defogger on for a long time could cause the battery
to discharge, especially during stop-and-
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE
To prevent the battery from being
discharged, turn the switch on
when the engine is running.
When cleaning the inside of theback window, be careful not to
scratch or damage the heaterwires.
Back window defogger

58

Part 1Fuel gauge
59
OPERATION OF INSTRUMENTS AND CONTROLSÐ
Chapter 1-5 Gauges, Meters and Service reminderindicators
Fuel gauge
Engine coolant temperature gauge
Tachometer
Odometer and trip meter
Service reminder indicators and warning buzzers
The gauge works when the ignition
switch is on
and indicates the approxi-
mate quantity of fuel remaining in the tank. Nearly fullÐNeedle at Fº Nearly emptyÐNeedle at Eº
It is a good idea to keep the tank over 1/4 full.
This fuel gauge has a non-return type
needle wh ich remains at the last indicated
position when the ignition switch is turned
off.
If the fuel level approaches Eº or the low fuel level warning light comes on, fill the fuel tank as soon as possible. If the fuel tank is completely empty, themalfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving several times. If the indicator lamp does
not go off, contact your Toyota dealer assoon as possible.

60
The gauge indicates the engine cool-
ant temperature when the ignition
switch is on. The engine operating
temperature will vary with changes inweather and engine load.
If the needle moves into the red zone, your engine is too hot. If your vehicle over-
heats, stop your vehicle and allow the en-
gine to cool.
Your vehicle may overheat during severe operating conditions, such as: Driving up a long hill on a hot day.
Reducing speed or stopping after high
speed driving.
Idling for a long period with the air con-
ditioning on in stop-and-go traffic.
Towing a trailer.
NOTICE
Do not remove the thermostat in
the engine cooling system as this
may cause the engine to overheat.
The thermostat is designed to con-trol the flow of coolant to keep the
temperature of the engine within the specified operating range.
Do not continue driving with anoverheated engine. See If yourvehicle overheatsº in Part 4.
The tachometer indicates engine
speed in thousands of rpm (revolu-
tions per minute). Use it while driving
to select correct shift points and to
prevent engine lugging and overrev-ving.
Driving with the engine running too fast
causes excessive engine wear and poor
fuel economy. Remember, in most cases
the slower the engine speed, the greater
the fuel economy.
NOTICE
Do not let the indicator needle get into the red zone. This may cause
severe engine damage.
Tachometer
Engine coolant temperature gauge

61
These meters show the running dis- tance.
1. OdometerÐIt shows the total distance
the vehicle has been driven.
2. Trip meterÐIt shows the distance
driven since the last time it was set to
zero. The black digits on white indicate
tenths of kilometers or miles.
3. Trip meter reset knobÐIt resets the trip meter to zero.
To reset the trip meter, push the knob.
Odometer and trip meter Service reminder indicators and warning buzzers
