The Cluster
[LG02715(M )06/93]
The following warning lights and gauges are on
the cluster. All of the warning lights and gauges
alert you to possible problems with your vehicle.
Some of the lights listed are optional. The
following sections detail what each of these
indicators means.
%*
[LG02900( ALL)06/95]
Brake System Warning Light
*
[LG03000( ALL)03/95]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by a
qualified service technician.
[LG03050(M )05/95]
one inch art:0011354-A[LG03100( ALL)01/95]
This light comes on when the parking brake is
set, or if it is not set, it comes on briefly when
you turn the ignition key to START. It normally
goes off shortly after the engine starts and you
release the parking brake. If the light stays on
after you have fully released the parking brake,
have the hydraulic brake system serviced.
*
[LG03200( ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

66 [LG04025(M )06/93]1. Park your car on level ground, and turn off
the engine and allow a few minutes for the
engine oil to drain back into the oil pan.
[LG04075(M )06/93]
2. Use the dipstick to check the oil. If the level
is low, add oil, but do not overfill. See
Engine Oil Recommendationsin the Index.
[LG04100(M )12/91]
If you are parked on a steep incline, the LOW
OIL LEVEL warning may come on when you
start your car, even though the oil is at the
correct level.
[LG04125(M )11/90]
NOTE: The LOW OIL LEVEL warning will
stay on until you turn the ignition
OFF. After your car is on level ground,
wait five minutes to allow the oil to
drain back before turning the ignition
ON again.
[LG04200(M )06/93]
one inch art:0010115-B%*
[LG04300( ALL)07/95]
Safety Belt Warning Light and Chime
*
[LG04305( ALL)09/95]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
*
[LG04315(M )03/95]
q
If the safety belt is not buckled when the key
is turned to the ON position, the light comes
on for 1 to 2 minutes and the chime sounds
for 4 to 8 seconds.
*
[LG04320(MBC )03/95]
q
If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime will turn off.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

67
*
[LG04325(M )03/95]
q
If the safety belt is buckled before the key is
turned to the ON position, the light will
come on for 4 to 8 seconds with no chime.
[LG04600( ALL)05/92]
one inch art:0010118-A%*
[LG04610( ALL)01/95]
Air Bag Readiness Light
[LG04620( ALL)05/94]
The air bag system uses a readiness light to
indicate the condition of the system. If the
system is functioning properly, the light will
stay on for 6 seconds when the ignition switch is
turned to the ON position.
[LG04630( ALL)05/94]
If there is a problem with the system, two things
may happen: the readiness light will either flash
or stay lit up, or you will hear a beeping sound.
If either of these things happen, have the air bag
system serviced at your Ford or Lincoln-Mercury
dealer immediately.
[LG04640(M GV)05/95]
one inch art:0010578-AFile:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

68 % [LG04650(M )05/95]Low Coolant Warning Light (4.6L Engine
Only)
[LG04660(M )03/92]
This light tells you that the coolant is low inside
the coolant recovery bottle and that you should
add more coolant.
[LG04665(M )03/92]
This light comes on for a few seconds when
your ignition key is turned to start, but should
turn off when the engine starts. If this light stays
on, check the level of coolant inside the recovery
bottle. SeeEngine Coolantin the Index.
[LG04670(M )05/95]
one inch art:0010579-B%*
[LG04700( ALL)01/95]
Charging System Light
*
[LG04800( ALL)03/95]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[LG04900( ALL)05/92]
one inch art:0010119-A*
[LG05100( ALL)07/95]
This light comes on every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

71
*
[LG11050( ALL)05/95]
The light comes on briefly when you turn the
ignition key toON, but it should turn off when
the engine starts. If the light does not come on
when you turn the ignition toONor if it comes
on and stays on when you are driving, have
your vehicle serviced as soon as possible. This
indicates a possible problem with one of the
vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG11055( ALL)05/95]
If the light turns on and off at one (1) second
intervals while you are driving the vehicle, it
means that the engine is misfiring. If this
condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle
serviced at the first opportunity. You do not
need to have your vehicle towed in.
*
[LG11060( ALL)05/95]
If the light turns on and off on rare occasions
while you are driving, it means that a
malfunction occurred and the condition corrected
itself.
*
[LG11065( ALL)05/95]
An example of a condition which corrects itself
occurs when an engine running out of fuel
begins to misfire. In this case, the Check Engine
Warning Light may turn on and will then set a
Diagnostic Trouble Code indicating that the
engine was misfiring while the last of the fuel
was being consumed. After refueling, the Check
Engine Warning Light will turn off after the
vehicle has completed three consecutive warm
up cycles without a misfire condition occurring.
A warm up cycle consists of engine start from a
cold condition (engine at ambient temperature)
and running until the engine reaches normal
operating temperature.
*
[LG11075( ALL)05/95]
On the fourth engine start up, the Check Engine
Warning Light will turn off as soon as the
engine begins to crank. It is not necessary to
have the engine serviced.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

73 %
*
[LG13000( ALL)01/95]
Fuel Gauge
[LG13075(M )05/95]
one third page art:0011344-A
The fuel gauge
[LG13100( ALL)08/93]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON. For proper fuel gauge
indication after adding fuel, turn the ignition
switch OFF while refueling the vehicle.
[LG13150( ALL)08/93]
The fuel gauge indicator may vary slightly when
the vehicle is in motion. The most accurate
reading is obtained with the vehicle on level
ground.
*
[LG13200( ALL)08/93]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
%*
[LG13400( ALL)01/95]
Engine Coolant Temperature Gauge
*
[LG13550( ALL)03/95]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[LG13600( ALL)03/94]
The pointer moves from the C (cold) mark into
the NORMAL band as your engine coolant
warms up. Under normal driving conditions, the
pointer should stay in the NORMAL band. It is
acceptable for the pointer to fluctuate within the
NORMAL band under normal driving
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

76 %
*
[LG15450(MBC )02/95]
Tachometer
[LG15500(M )05/95]
one third page art:0011346-A
The tachometer
*
[LG15600(MBC )01/95]
The tachometer displays the approximate engine
revolutions per minute (rpm), or how fast the
engine is running.
[LG15700(M )06/93]
The white zone shows the highest number of
engine revolutions per minute (rpm) at which
you should drive your car. Driving with the
pointer in the red zone may cause engine
damage.
% [LG16220( ALL)05/94]
Battery Voltage Gauge (If Equipped)
*
[LG16225( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG16230( ALL)05/95]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[LG16260( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

84 [IP33000( ALL)12/94]Clear away any snow that is on the rear
window before using the defroster. With the
engine running, push the defrost button.
[IP33100( ALL)12/94]
After approximately 10 minutes, the defroster
will turn off. If the window is still not clear,
turn the defroster on again.
[IP33200( ALL)12/94]
The defroster will turn off when the ignition key
is turned to the OFF position.
*
[IP33300( ALL)02/95]
The heating elements are bonded to the inside of
the rear window. Do not use sharp objects to
scrape the inside of the rear window or use
abrasive cleaners to clean it. Doing so could
damage the heating elements.
%
*
[IP34200( ALL)01/95]
The Interior and Exterior Lights
%*
[IP34310( ALL)01/95]
Daytime Running Light System
*
[IP34312( ALL)03/95]
(Canadian vehicles only)
*
[IP34320( ALL)03/95]
The Daytime Running Light (DRL) system turns
the high beam headlamps on, with a reduced
light output, when:
*
[IP34325( ALL)03/95]
q
The headlamp system is in the OFF position,
and
*
[IP34330( ALL)03/95]
q
The vehicle is running, and
*
[IP34340( ALL)01/95]
q
The vehicle has a fully released parking
brake.
*
[IP34363( ALL)09/95]
NOTE: The high beam indicator will not turn
on in the flash-to-pass mode during
nighttime driving.
*
[IP34365( ALL)01/95]
NOTE: You may notice that the lights flicker
when the vehicle is turned on or off.
This is a normal condition.
