1996 FORD MUSTANG ignition

170
*
[AS44230(MBC )08/95]
q
Using the ªSCANº function with your
cassette tape player
*
[AS44240(MBC )08/95]
Press the ªSCAN/TUNEº button to enter the
scan mode (display indicates ªSCNº).
Pushing the right (
a) side of the ªSEEKº
button will begin the forward scan mode on
the tape currently playing, stopping on each
tape selection for approximately an
eight-second sampling.
*
[AS44250(MBC )08/95]
Pushing the left (
b) side of the ªSEEKº
button will begin the reverse scan mode,
stopping on each previous tape selection for
approximately an eight-second sampling.
While scanning, the display indicates whirling
sprockets plus an ªSº (m).
*
[AS44260(MBC )08/95]
To stop the scan mode on the presently
sampled tape selection press the
ªSCAN/TUNEº button again.
*
[AS44270(MBC )08/95]
q
How to change the side of the tape being
played
[AS44280(MBC )02/95]
The alternate side of the tape can be selected
at any time by pressing the ªPLAY/PROGº
button.
*
[AS44300(MBC )08/95]
How to eject the tape
*
[AS44310(MBC )08/95]
To stop the tape and eject the cassette, press the
ªEJCTº button. The radio will resume playing if
the radio power is on. The tape cartridge can be
ejected with radio power (and/or ignition) on or
off.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

171
*
[AS44320(MBC )08/95]
How to store the tape
*
[AS44330(MBC )08/95]
Press the ªAM/FMº button to stop the tape
player and resume radio play. The cassette will
be stored in the tape player and the
Xsymbol
in the display will be lit until you push the
ªPLAY PROGº button to resume tape play. Fast
forward and fast rewind can be used while the
tape is in storage mode without interrupting
radio play.
*
[AS44340(MBC )08/95]
Using the DolbyHB noise reduction feature
*
[AS44350(MBC )08/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS44360(MBC )04/95]
Push thekbutton to activate Dolby B Noise
Reduction. Push again to deactivate.
*
[AS44490(MBC )08/95]
Tape error messages
*
[AS44500(MBC )08/95]
Your cassette tape player is equipped to
diagnose certain problems you may experience.
Error codes are as follows:
*
[AS44510(MBC )08/95]
Error 0Ð Communication error between the
radio controller and the tape controller. The
cassette player will eject the tape. Insert the tape
again. If the same error code appears, turn the
ignition off, then back on again and insert the
tape.
*
[AS44520(MBC )08/95]
Error 1Ð Possible problem cartridge. The
cassette tape player will eject the tape. Insert the
tape again. If the same error code appears in the
display, try a different cartridge.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

177
Driving Your Mustang
*
[DR00200(M )06/95]
Procedures for driving your vehicle will vary
depending on which type of transmission your
vehicle has.
[DR00300(M )03/95]
q
an automatic overdrive transmission with
transmission control switch
*
[DR00400(M )06/95]
q
a manual transmission
%
*
[DR00500( ALL)03/93]
Driving with an Automatic
Overdrive Transmission
[DR00510(MBC )05/94]
The gearshift lever is floor mounted.
%*
[DR00800( ALL)01/95]
Putting Your Vehicle in Gear
*
[DR00950( ALL)05/95]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
[DR00965(MBC )03/95]
To move the shifter out of P (Park), the ignition
key must be turned to either the OFF or the ON
position and the thumb button must be pushed
in. This vehicle is also equipped with the brake
shift interlock safety feature which prevents
shifting the transmission out of the P (Park)
position without the brake pedal being
depressed if the key is in the ON position.
*
[DR00975( ALL)03/95]
To operate:
*
[DR00980( ALL)01/95]
1. Start the engine.
*
[DR00985( ALL)01/95]
2. Depress and hold the brake pedal.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

178
*
[DR00990( ALL)01/95]
3. Move the gearshift lever out of P (Park).
%*
[DR00995( ALL)04/95]
Your vehicle is equipped with a Brake Shift
Interlock safety feature. This feature prevents the
gearshift from being moved from the P (Park)
position until the brake pedal is depressed. This
feature is active when the ignition is in the ON
position. If the gearshift lever CANNOT be
moved from P (Park) with the brake pedal
depressed:
*
[DR01000( ALL)01/95]
1. Turn the engine off and remove the ignition
key.
*
[DR01005( ALL)01/95]
2. Apply parking brake.
*
[DR01010( ALL)01/95]
3. Reinsert the ignition key and turn clockwise
to the first position (OFF).
*
[DR01020( ALL)01/95]
4. Depress the brake pedal, move the gearshift
lever to N (Neutral) and start the engine.
*
[DR01025( ALL)09/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
*
[DR01027( ALL)07/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Mustang
in this Owner Guide for instructions on checking
and replacing fuses.
[DR01030(MBC )05/94]
The console-mounted gearshift will lock in P
(Park) when you turn the key to the LOCK
position. When the gearshift is in any position
except P (Park), the ignition key cannot be
turned to LOCK or removed from the steering
column. TO REMOVE THE KEY, the gearshift
lever must be in P (Park).
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

179 % [DR01200(M )03/93]
half page art:0010306-D
The positions of the console-mounted gearshift
*
[DR01500( ALL)11/94]
Once the gearshift is secure in the desired
position, release the brake pedal and use the
accelerator as necessary.
%*
[DR01700( ALL)01/95]
R (Reverse)
*
[DR01800( ALL)08/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[DR01830( ALL)01/95]
N (Neutral)
[DR01860( ALL)10/95]
As in P (Park), there is no power transferred
through the transmission. However, the final
drive is not locked so the wheels are free to
rotate. The vehicle may be started in the N
position, but the ignition key cannot be
removed.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

185 %
*
[DR09000(M )05/95]
Downshifting
*
[DR09100(M )03/95]
When you slow down or climb a steep hill,
always downshift before the engine starts to lose
power. Downshifting reduces the chance of
stalling and gives your vehicle better acceleration
to increase speed again.
*
[DR09200(M )03/95]
When you drive down steep hills, downshifting
helps you keep a safe speed and helps prevent
unnecessary wear on the brakes.
*
[DR09300(M )03/95]
When you come to a stop, do not downshift
through each gear. Disengage the clutch and use
the brake as necessary. Downshifting through
the gears decreases your vehicle's fuel economy.
[DR09400(M )03/95]
NOTE: Do not downshift into 1 (First) when
your vehicle is moving faster than
15 mph (24 km/h). This will damage
the clutch.
*
[DR09500(M )03/95]
Parking
*
[DR09600(M )03/95]
To park your vehicle, shift into 1 (First), set the
parking brake fully, and turn off the ignition.
*
[DR09700(M )05/95]
RWARNING
Do not park your vehicle in Neutral, it
may move unexpectedly and injure
someone. Use 1 (First) gear and set the
parking brake fully.
% [DR09720( ALL)03/95]
Traction-Lok Axle (If equipped)
[DR09730( ALL)12/91]
This axle provides added traction on slippery
surfaces, particularly when one wheel is on a
poor traction surface. Under normal conditions
the Traction-Lok axle functions as a standard
rear axle.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

200acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE01000( ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01100( ALL)03/95]
Preparing Your Vehicle
[RE01150( ALL)11/90]
NOTE: also see label on battery.
*
[RE01200( ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300( ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
File:12rcrem.ex
Update:Wed Mar 27 09:34:49 1996

205 [RE03810(M )09/95]
NOTE: If your vehicle is equipped with a 3.8L
engine you will need to perform
additional steps after your vehicle has
been jump started. SeeReadiness for
Inspection/Maintenance Testingin
Servicing Your Vehicle Chapter.
%
*
[RE03900( ALL)03/95]
Changing a Tire
*
[RE04000( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[RE04100( ALL)03/95]
The Temporary Spare Tire
[RE04225(MBC )03/94]
You have a high pressure temporary spare tire.
This spare tire is smaller than a regular tire and
is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon
as you can. This spare tire is marked with the
words ªTEMPORARY USE ONLYº so that you
can easily identify it.
*
[RE04250( ALL)01/95]
NOTE: Extended use of other than
conventional spare tires on a
Traction-Lok rear axle could result in a
permanent reduction in effectiveness.
This loss of effectiveness does not
affect normal driving and should not
be noticeable to the driver.
*
[RE04300( ALL)01/93]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
File:12rcrem.ex
Update:Wed Mar 27 09:34:49 1996
