1996 FORD MUSTANG ignition

92
*
[SC02301( ALL)03/95]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[SC02401( ALL)08/95]
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
%*
[SC02700( ALL)05/95]
High Beams
*
[SC02800( ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[SC02900( ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
[SC02955(M )06/93]
NOTE: The fog lamps will turn off if you put
high beams on while fog lamps are on.
%*
[SC03200( ALL)08/95]
Flashing the Lights
*
[SC03300( ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
%
*
[SC03500( ALL)08/95]
Windshield Wipers and Washer
*
[SC03600( ALL)03/95]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[SC03750( ALL)01/95]
Rotate the end of the lever away from you to
activate the wipers. The first seven detents are
interval wipe positions, the eighth detent is the
LO position and the ninth detent is the HI
position.
*
[SC03800( ALL)01/95]
To turn the wipers off, turn the knob toward
you to the OFF position.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

101
*
[SC11800( ALL)08/95]
q
Depress the accelerator pedal. When the
vehicle attains the desired speed, press the
SET ACCEL switch and release it
immediately.
% [SC11850(M GV)05/95]
q
TAP-UPÐ Press and then quickly release the
SET ACCEL switch. Each time you ªtapº the
switch, the set speed will increase by one (1)
mph (1.6 km/h). Multiple taps will cause the
set speed to increase in increments of one (1)
mph (1.6 km/h). For example, if the current
set speed is 55 mph (88 km/h) five (5) taps
of the SET ACCEL switch will increase the
vehicle speed and SET it at 60 mph
(96 km/h).
%*
[SC12800( ALL)08/95]
Resuming a Set Speed
[SC12900(M )03/95]
If you press the brake or clutch pedal, speed
control is suspended. You can return to the set
speed you set by pressing the RESUME switch,
as long as you did not press the OFF switch.
You must be driving at least 30 mph (48 km/h).
*
[SC13400( ALL)05/95]
Your vehicle will gradually return to the
previously set speed and then maintain it.
%*
[SC13501( ALL)01/95]
To Turn Speed Control Off
*
[SC13601( ALL)08/95]
Press the OFF switch.
*
[SC13701( ALL)01/95]
Speed control is also turned OFF each time the
vehicle ignition is shut off.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

105
*
[FV03270(M )05/95]
NOTE: The factory installed Remote Entry
System has a PANIC feature that also
chirps the vehicle horn and flashes the
interior/exterior lamps when the
PANIC button on the remote entry
transmitter is pushed. The PANIC
alarm and the Anti-Theft alarm are two
separate features. Both the anti-theft
alarm and the PANIC feature can be
active at the same time.
[FV03280(MBC )05/95]
To tell the difference between a PANIC alarm
and a triggered Anti-theft alarm:
[FV03290(MBC )10/95]
q
only the Anti-Theft alarm will cause the
alarm indicator lamp (located in the
instrument cluster) to flash on and off.
[FV03301(MBC )05/95]
q
only the Anti-Theft alarm will disable the
start circuit so that the vehicle can not be
started.
[FV03310(MBC )05/95]
q
the Anti-Theft alarm will not stop by pushing
the PANIC button on the Remote Entry
transmitter.
*
[FV03320(MBC )05/95]
For more information on the PANIC alarm, see
Remote Entry Systemin the Index.
%*
[FV03330(MBC )05/95]
Arming the system
[FV03340(MBC )05/95]
To arm the system, do the following steps in
sequence:
*
[FV03350(MBC )07/95]
1. Remove the key from the ignition. The hood
must be closed to arm the system.
*
[FV03360(MBC )05/95]
2. Open any door. The alarm indicator light
will start flashing to remind you to arm the
system.
[FV03370(MBC )05/95]
3. Lock the doors by using the power door
lock switch or by pressing the remote entry
transmitter LOCK button.
[FV03380(MBC )05/95]
The alarm indicator will now glow steadily.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

106 [FV03390(MBC )05/95]4. Close all doors. The alarm indicator light
will then remain on steadily for
approximately 30 seconds and then go out.
When the light goes out, the system is
armed.
*
[FV03400(MBC )06/95]
NOTE: Be sure to close all doors completely. If
not, the alarm indicator light will
remain on. Remember, your anti-theft
system is armed only after the alarm
indicator light remains on steadily for
approximately 30 seconds after the last
door is closed, and then goes out.
[FV03410(MBC )05/95]
You can also arm the anti-theft system by
following this sequence:
[FV03420(MBC )08/95]
1. Remove key from ignition.
*
[FV03430(MBC )05/95]
2. Close all of the doors.
[FV03440(M )05/94]
3. Press the remote entry transmitter LOCK
button. The alarm indicator will come on for
30 seconds to show the alarm is arming and
then turn off to show that the alarm has
armed.
*
[FV03450(MBC )05/95]
The anti-theft system is designed to work with
the factory installed remote entry system. It may
not work with other remote entry systems.
%*
[FV03460(MBC )05/95]
Disarming an untriggered anti-theft system
*
[FV03470(MBC )05/95]
You can disarm the system by:
[FV03480(MBC )05/95]
q
unlocking a door with the key (turn the key
all the way to the end of travel or the system
may not disarm.
*
[FV03490(MBC )05/95]
q
using the UNLOCK button of the remote
entry transmitter
[FV03500(MBC )05/95]
q
if remaining in the vehicle, turn the ignition
switch to ON or ACC
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

107
*
[FV03510(MBC )05/95]
Triggering the alarm system
*
[FV03520(MBC )05/95]
The armed system will be triggered if:
[FV03530(MBC )05/95]
q
any door is opened without disarming the
system first (see previous paragraphs)
*
[FV03540(MBC )10/95]
q
the trunk lock cylinder is removed
*
[FV03543(MBC )09/95]
NOTE: You can open the trunk with your key
without setting off the alarm.
[FV03544(M )10/95]
q
the hood is opened (except on GT/Cobra
vehicles)
[FV03546(M )10/95]
q
the ignition key lock cylinder is forcibly
removed from the steering column (except on
GT/Cobra vehicles where the coded key
anti-theft system provides this protection).
%*
[FV03550(MBC )05/95]
Disarming a triggered system
*
[FV03560(MBC )05/95]
The alarm can be disarmed by:
*
[FV03570(MBC )05/95]
q
unlocking a front door with the key
*
[FV03580(MBC )05/95]
q
using the UNLOCK button of the remote
entry transmitter
*
[FV03582(MBC )09/95]
NOTE: The flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs. However, the
starter circuit remains disabled until
the system is disarmed.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

108 [FV03583(M )05/95]Coded Key Anti-Theft System
(If equipped)
[FV03584(M )10/95]
If your vehicle is equipped with the coded key
anti-theft system, you can only use an
electronically coded key to start the vehicle.
During each vehicle start sequence, the coded
key is read by the anti-theft system. If the key's
ID code matches that in the anti-theft system,
the vehicle is enabled to start. If the key's ID
code does not match the anti-theft system, or if
no coded key is detected, then the vehicle is not
able to start. Your vehicle was equipped with
two electronically coded keys. The coded
ignition key is larger than normal due to the
electronics located in the head of the key.
Additional spare keys, maximum of 14, can be
purchased either through your dealership or
selected retailers. Be sure to purchase only coded
keys with a Ford or Mercury logo on it to
ensure proper functionality. If both supplied
keys are lost or stolen, the vehicle must be
brought to the dealership for re-initialization.
(All keys must be brought to the dealer, if any.)
[FV03585(M )05/95]
quarter page art:0011372-AFile:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

109 [FV03586(M )05/95]
Theft Indicator
*
[FV03587(M )10/95]
The indicator provides system proveout and
operating status. The system activates the
indicator when the ignition switch is placed in
the ON or START position. This indicator helps
to determine possible fault conditions and/or
normal operating proveout. The system will
illuminate the indicator for two (2) seconds then
go out to acknowledge normal operating
conditions. If the indicator does not illuminate at
key ON or flashes, have the system serviced.
*
[FV03588(M )10/95]
Spare Key Programming Procedure
*
[FV03589(M )10/95]
Two electronically coded keys were supplied
with your vehicle, use one of these with the
procedure below:
*
[FV03590(M )10/95]
q
Using a coded key that you can start your
engine with, turn the ignition from the ON to
the OFF position.
*
[FV03591(M )10/95]
q
Within 15 seconds, insert a new key into the
ignition and turn it to ON or START. The
vehicle does not have to be started.
*
[FV03592(M )10/95]
If the key has been coded, the theft indicator
will illuminate for two seconds. The key can
then be used to start the vehicle.
*
[FV03593(M )10/95]
Repeat until all chosen keys have been coded
(max=16).
*
[FV03594(M )10/95]
If the key coding failed, the theft indicator will
flash and the vehicle cannot be started. One of 3
causes are possible:
*
[FV03595(M )10/95]
q
The new key was not inserted within 15
seconds or
*
[FV03596(M )10/95]
q
All 16 key codes have been stored or
[FV03597(M )05/95]
q
The key does not have an electronic code
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

110
%*
[FV08030( ALL)05/95]
Remote Entry System
(If equipped)
*
[FV08036( ALL)03/94]
If your vehicle has the remote entry system, you
can lock and unlock the vehicle doors and open
the trunk without using a key. The remote also
has a personal alarm feature. The buttons for the
system are located on the hand held
transmitter(s) that came with your vehicle.
*
[FV08040( ALL)06/95]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
*
[FV08045(MBC )02/95]
The remote entry features only operate with the
ignition in the OFF position.
[FV08050(MBC )02/95]
one third page art:0001000-A
Remote entry transmitter
%*
[FV08055( ALL)02/95]
Unlocking the doors and opening the trunk
*
[FV08060( ALL)02/95]
To unlock the driver's door, press the UNLOCK
button.
*
[FV08065( ALL)02/95]
To unlock the other doors, press the UNLOCK
button a second time within five seconds of
unlocking the driver's door.
*
[FV08070(MBC )02/95]
To open the trunk, press the TRUNK button.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
