WITH THE IGNITION SW TURNED ON, THE CURRENT FLOWS TO TERMINAL (A)14 OF THE WIPER AND WASHER SW, TERMINAL 2 OF
THE WASHER MOTOR AND TERMINAL 6 OF THE WIPER MOTOR THROUGH THE WIPER FUSE.
1. LOW SPEED POSITION
WITH WIPER SW TURNED TO LOW POSITION, THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW "
TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND CAUSES TO THE WIPER MOTOR TO RUN
AT LOW SPEED.
2. HIGH SPEED POSITION
WITH WIPER SW TURNED TO HIGH POSITION, THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW "
TERMINAL (A)7 " TERMINAL 2 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND CAUSES TO THE WIPER MOTOR TO RUN
AT HIGH SPEED.
3. INT POSITION
WITH WIPER SW TURNED TO INT POSITION, THE RELAY OPERATES AND THE CURRENT WHICH IS CONNECTED BY RELAY
FUNCTION FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW " TERMINAL (A)6 " TO GROUND . THIS FLOW OF
CURRENT OPERATES THE INTERMITTENT CIRCUIT AND THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND
WASHER SW " TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND FUNCTIONS.
THE INTERMITTENT OPERATION IS CONTROLLED BY A CONDENSER'S CHARGED AND DISCHARGED FUNCTION INST\
ALLED IN
RELAY AND THE INTERMITTENT TIME IS CONTROLLED BY A TIME CONTROL SW TO CHARGE THE CHARGING TIME OF THE
CONDENSER.
4. MIST POSITION
WITH WIPER SW TURNED TO MIST POSITION, THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW "
TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND CAUSES TO THE WIPER MOTOR TO RUN
AT LOW SPEED.
5. WASHER CONTINUOUS OPERATION
WITH WASHER SW TURNED TO ON, THE CURRENT FLOWS FROM TERMINAL 2 OF THE WASHER MOTOR " TERMINAL 1 "
TERMINAL (A)13 OF THE WIPER AND WASHER SW " TERMINAL (A)6 " TO GROUND AND CAUSES TO THE WASHER MOTOR TO
RUN. AND WINDOW WASHER IS JET. THIS CAUSES THE CURRENT TO FLOW WASHER CONTINUOUS OPERATION CIRCUIT IN
TERMINAL (A)14 OF THE WIPER AND WASHER SW " TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 TO
GROUND AND FUNCTION.
C15(B), C16(A) WIPER AND WASHER SW [COMB. SW]
(A) 6±GROUND : ALWAYS CONTINUITY
(A) 14±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
(B) 8±GROUND : APPROX. 12 VOLTS WITH WIPER AND WASHER SW AT LOW OR MIST POSITION
APPROX. 12 VOLTS EVERY APPROX. 1 TO 10 SECONDS INTERMITTENTLY WITH WIPER SW AT INT POSITION
(B) 17±GROUND : APPROX. 12 VOLTS WITH IGNITION SW ON UNLESS WIPER MOTOR AT STOP POSITION
(A) 7±GROUND : APPROX. 12 VOLTS WITH IGNITION SW ON AND AFTER WIPER SW OFF UNTIL WIPER MOTOR STOPS
W 5 WIPER MOTOR
6±5 : CLOSED UNLESS WIPER MOTOR AT STOP POSITION
SYSTEM OUTLINE
SERVICE HINTS
WhereEverybodyKnowsYourName

144
ABS (ANTI±LOCK BRAKE SYSTEM)
M
A
11
MR A
4
R± A
5
SR
A
6 SFL
A
12 SRR
A
8 AST
A
9 MT
B
1 SFR
B
16 PKB
B
2 GND
B
13 GND
B
1B 4 B
3B 2B5
A 4
A 3
A 1 2 1
IG1
19
IO1
5IO1 7
EB EA 16 22 23 11
EB1
6IK1 10
IJ
EA 1
34
3 2
16
1
4
2
IK2
25 IK2 2
IE1
1
IE2
12
2 1
E10
I23I25
E9
2
6 6
666
66
66
6
B
10
WA
B
6
TS
5
6
E12 L
P±B
V±Y
L±W
L±W L
W
V±YL
W± B L±W V±YY±L
R
R
R
B±R
B±R
B±R
P±B
V
L
L
L V
L V±Y
V
R±Y
Y
B±Y P
L±W Y±G
R±W R±W
W±B
W±B
R±W
R±W
B
B
W±B
W±B W±B
W±B W±B
L±WL
W± B
SFR SFL SRR AST MT
BS
BM
GND WA
TS TC
WB
BATTERY ABS ECU
(
W/O TRACTION CONTROL )
R
120A ALT
60A ABS NO. 1
ABS MOTOR
RELAY
ABS ACTUATOR
RELAY
CHECK
CONNECTOR
FUSE BLOCK
R±W
DIODE
(FOR PARKING BRAKE )
BRAKE FLUID
LEVEL SW
PARKING
BRAKE
SW
ABS ACTUATOR
(
CANA DA )
( USA )
B1
D2
A4 , A33
P3
A2 2
,A23
B
BA A
C3
F9 SHORT PIN
WhereEverybodyKnowsYourName

134
ABS AND TRACTION CONTROL
34
3 2
16
1
4
26
666
66
66
6 56
ABS MOTOR
RELAY
ABS ACTUATOR
RELAY4 1
3
26
6
66TRACTION MOTOR
RE LA Y
M
A
13 SFL C
12 SRL
A
8 AST
A
7 MT
B
1 SFR
B
4B 51B 2B3
A 2
A 1
C 1
L±W
L
Y
B±Y
P±B
L±W Y±G
SFR SFL SRL AST MT
BS
BM
GND
ABS ACTUATOR A4,A5 ,A6 B
B C
A
EA
EB B
16
MR A
9
TMR
A
22
SR
A
25
R± E10
E12
6
11 2
L±Y
W±B V±Y
W±B B±R
R
Y R
W±B V±Y
W±B W±B
W±B
Y
V±Y
R±B G Y
R R
W±B L±W
V±Y
V±Y
G V±Y
L
L±W
L
W±B W±B W±B W
R Y
30A ABS NO. 2
60A ABS NO. 1 120A ALT
BATTERY
FUSE BLOCK
ABS AND TRACTION ECUA
26 SRR
6
P
SRR B
A24
,A25 ,
A26
F9
B
A
B
A
5 FL+
A
18 FL ±
21 (
SHIELDED )
W
B
B
W
A7
FRONT LH
E2
V±Y
W±B
V±Y
R±B
V±Y
WhereEverybodyKnowsYourName

226
AUTOMATIC AIR CONDITIONER
1. HEATER BLOWER MOTOR OPERATION
CURRENT IS APPLIED AT ALL TIMES THROUGH HEATER FUSE (60A) TO TERMINAL 5 OF HEATER RELAY. WHEN THE IGNITION SW IS
TURNED ON, CURRENT FLOWS THROUGH HEATER FUSE (10A) TO TERMINAL 1 OF HEATER RELAY " TERMINAL 3 " TERMINAL HR
OF A/C CONTROL ASSEMBLY. AT THE SAME TIME, CURRENT ALSO FLOWS FROM HEATER FUSE (10A) TO TERMINAL IG+ OF A/C
CONTROL ASSEMBLY AND TERMINAL 2 OF WATER VALVE VSV " TERMINAL 1 " TERMINAL WV OF A/C CONTROL ASSEMBLY.
* LOW SPEED OPERATION
WHEN THE BLOWER SW (A/C CONTROL ASSEMBLY) IS PUSHED TO LOW SPEED POSITION, THE CURRENT TO TERMINAL HR OF A/C
CONTROL ASSEMBLY FLOWS TO TERMINAL E OF A/C CONTROL ASSEMBLY " GROUND AND TURNS THE HEATER RELAY. AS A
RESULT, THE CURRENT TO TERMINAL 5 OF HEATER RELAY FLOWS TO TERMINAL 4 OF RELAY " TERMINAL 2 OF BLOWER
RESISTOR " TERMINAL 1 " GROUND AND CAUSES THE BLOWER MOTOR TO ROTATE AT LOW SPEED.
* MEDIUM (M1, M2, M3) AND HIGH SPEED OPERATION
WHEN THE BLOWER SW (A/C CONTROL ASSEMBLY) IS SELECTED TO MEDIUM (M1, M2, M3) OR HIGH POSITION, THE CURRENT TO
TERMINAL HR OF A/C CONTROL ASSEMBLY FLOWS TO TERMINAL E " GROUND AND TURNS THE HEATER RELAY ON. THEN, THE
CURRENT TO TERMINAL IG+ OF A/C CONTROL ASSEMBLY FLOWS TO TERMINAL BLR " TERMINAL (B)2 OF POWER TRANSISTOR
" TERMINAL (A)1 " GROUND. AS A RESULT, THE CURRENT TO TERMINAL 5 OF HEATER RELAY FLOWS TO TERMINAL 4 "
TERMINAL 2 OF BLOWER MOTOR " TERMINAL 1 " TERMINAL (A)2 OF POWER TRANSISTOR " TERMINAL (A)1 " GROUND AND
BLOWER MOTOR IS ROTATED AT SELECTED SPEED BY THE A/C CONTROL ASSEMBLY CONTROLLING THE CURRENT FLOW FROM
TERMINAL (B)2 OF POWER TRANSISTOR TO TERMINAL (B)1.
* AUTO FUNCTION
WHEN THE AUTO SW IN HEATER CONTROL SW (A/C CONTROL ASSEMBLY) IS SELECTED, THE CURRENT FLOW IS THE SAME AS
ABOVE MENTIONS, BUT THE A/C CONTROL ASSEMBLY DECIDES THE APPROPRIATE AIR FLOW VOLUME ACCORDING TO SET
TEMPERATURE AND THE INPUT SIGNALS FROM EACH SENSOR. BY CONTROLLING THE CURRENT FLOW\
FROM TERMINAL BLR OF
THE A/C CONTROL ASSEMBLY TO TERMINAL (B)2 OF POWER TRANSISTOR " TERMINAL (A)1 " GROUND , THE A/C CONTROL
ASSEMBLY CONTROLS THE BLOWER MOTOR STEPLESSLY.
2. OPERATION OF AIR INLET CONTROL SERVO MOTOR
(SWITCHING FROM FRESH TO RECIRC)
WITH IGNITION SW TURNED ON, THE CURRENT FLOWS FROM HEATER FUSE (10A) TO TERMINAL IG+ OF A/C CONTROL ASSEMBLY
" TERMINAL MREC " TERMINAL 6 OF AIR INLET CONTROL SERVO MOTOR " TERMINAL 2 " TERMINAL MFRS OF A/C CONTROL
ASSEMBLY " TERMINAL E " GROUND , THE MOTOR ROTATES AND THE DAMPER MOVES TO THE RECIRC SIDE. WHEN THE
DAMPER OPERATES WITH THE A/C SW AT RECIRC POSITION, THE DAMPER POSITION SIGNAL IS INPUT FROM TERMINAL 5 OF THE
SERVO MOTOR TO TERMINAL TPI OF THE ECU (BUILT INTO THE A/C CONTROL ASSEMBLY). AS A RESULT, CURRENT TO THE SERVO
MOTOR CIRCUIT IS CUT OFF BY THE ECU, SO THE DAMPER STOPS AT THAT POSITION.
(SWITCHING FROM RECIRC TO FRESH)
WITH IGNITION SW TURNED ON, WHEN THE RECIRC/FRESH SW IS SWITCHED TO THE FRESH SIDE, THE CURRENT FLOWS FROM
TERMINAL IG+ OF A/C CONTROL ASSEMBLY " TERMINAL MFRS " TERMINAL 2 OF AIR INLET CONTROL SERVO MOTOR "
TERMINAL 6 " TERMINAL MREC OF A/C CONTROL ASSEMBLY " TERMINAL E " GROUND , THE MOTOR ROTATES AND THE
DAMPER STOPS AT THAT POSITION.
3. OPERATION OF AIR VENT MODE CONTROL SERVO MOTOR
WITH IGNITION SW TURNED ON, THE CURRENT FLOWS FROM HEATER FUSE (10A) TO TERMINAL IG+ OF A/C CONTROL ASSEMBLY.
(SWITCHING FROM DEF TO FACE)
THE CURRENT FLOWS FROM TERMINAL MFACE OF A/C CONTROL ASSEMBLY " TERMINAL 4 OF AIR VENT CONTROL SERVO
MOTOR " TERMINAL 5 " TERMINAL MDEF OF A/C CONTROL ASSEMBLY " TERMINAL E " GROUND . THE MOTOR ROTATES AND
THE DAMPER MOVES TO THE FACE SIDE. WHEN THE DAMPER OPERATES WITH THE A/C SW AT FACE POSITION, THE DAMPER
POSITION SIGNAL IS INPUT FROM TERMINAL 1 OF THE SERVO MOTOR TO THE TERMINAL TPM OF THE ECU (BUILT INTO THE A/C
CONTROL ASSEMBLY). AS A RESULT, CURRENT TO THE SERVO MOTOR CIRCUIT IS CUT OFF BY THE ECU, SO THE DAMPER STOPS
AT THAT POSITION.
(SWITCHING FROM FACE TO DEF)
THE CURRENT FLOWS FROM TERMINAL DEF OF A/C CONTROL ASSEMBLY " TERMINAL 5 OF AIR VENT CONTROL SERVO MOTOR
" TERMINAL 4 " TERMINAL MFACE OF A/C CONTROL ASSEMBLY " TERMINAL E " GROUND , THE MOTOR ROTATES AND THE
DAMPER STOPS AT THAT POSITION.
SYSTEM OUTLINE
WhereEverybodyKnowsYourName

227
4. OPERATION OF AIR MIX CONTROL SERVO MOTOR
WHEN THE TEMPERATURE SW IS TURNED TO THE ªCOOLº SIDE, THE CURRENT FLOWS FROM TERMINAL MC OF A/C CONTROL
ASSEMBLY " TERMINAL 4 OF AIR MIX CONTROL SERVO MOTOR " MOTOR " TERMINAL 5 " TERMINAL MH OF A/C CONTROL
ASSEMBLY " GROUND AND THE MOTOR ROTATES. THE DAMPER OPENING ANGLE AT THIS TIME IS INPUT FROM TERMINAL 1 OF
SERVO MOTOR TO TERMINAL TP OF A/C CONTROL ASSEMBLY, THIS IS USED TO DETERMINE THE DAMPER STOP POSITION AND
MAINTAIN THE SET TEMPERATURE.
WHEN THE TEMPERATURE CONTROL SW IS TURNED TO THE ªHOTº SIDE, THE CURRENT FLOWS FROM SERVO MOTOR "
TERMINAL MH OF A/C CONTROL ASSEMBLY " TERMINAL 5 OF AIR MIX CONTROL SERVO MOTOR " MOTOR " TERMINAL 1 "
TERMINAL MC OF A/C CONTROL ASSEMBLY, ROTATING THE MOTOR IN REVERSE AND SWITCHING THE DAMPER FROM ªCOOLº TO
ªHOTº SIDE.
5. AIR CONDITIONER OPERATION
THE A/C CONTROL ASSEMBLY RECEIVES VARIOUS SIGNALS, I.E., THE ENGINE RPM FROM THE IGNITER, OUTLET TEMPERATURE
SIGNAL FROM THE A/C THERMISTOR, COOLANT TEMPERATURE FROM THE WATER TEMP. SENSOR AND THE LOCK SIGNAL FROM
THE A/C COMPRESSOR, ETC.
WHEN THE ENGINE IS STARTED AND THE A/C SW (A/C CONTROL ASSEMBLY) IS ON, A SIGNAL IS INPUT TO THE ECU. (BUILT IN THE
A/C CONTROL ASSEMBLY).
AS A RESULT, THE GROUND CIRCUIT IN A/C CONTROL ASSEMBLY IS CLOSED AND CURRENT FLOWS FROM HEATER FUSE (10A) TO
TERMINAL 2 OF MAGNETIC CLUTCH RELAY " TERMINAL 3 " TERMINAL ACMG OF ENGINE AND ECT ECU " TERMINAL E OF A/C
CONTROL ASSEMBLY " GROUND , TURNING THE MAGNETIC CLUTCH RELAY ON, SO THAT THE MAGNETIC CLUTCH IS ON AND THE
A/C COMPRESSOR OPERATES.
AT THE SAME TIME, THE ENGINE AND ECT ECU DETECTS THE MAGNETIC CLUTCH IS O\
N AND THE A/C COMPRESSOR OPERATES.
OPEN DIRECTION TO AVOID LOWERING THE ENGINE RPM DURING A/C OPERATING.
WHEN ANY OF THE FOLLOWING SIGNALS ARE INPUT TO THE A/C CONTROL ASSEMBLY, THE CONTROL ASSEMBLY OPERATES TO
TURN OFF THE AIR CONDITIONING.
* ENGINE HIGH TEMP. SIGNAL IS HIGH.
* COOLANT HIGH TEMP. SIGNAL IS HIGH.
* A SIGNAL THAT THE TEMPERATURE AT THE AIR OUTLET IS LOW.
* A SIGNAL THAT THERE IS A LARGE DIFFERENCE BETWEEN ENGINE RPM AND COMPRESSOR RPM.
* A SIGNAL THAT THE REFRIGERANT PRESSURE IS ABNORMALLY HIGH OR LOW.
WhereEverybodyKnowsYourName

60
CHARGING
1E
81H 52
3D
2 2
3D
1
IG3
1 IJ2
13 EB2 2
IJ1
5
A
A
A
231
LIG S B 1B
IC REGULATOR
6
11
57 1412
15
WB W B
W
B±O
Y±G
Y±G
Y±G
Y±G
Y±G B±Y W
B B±Y
W B±Y
W
B
FUSE B LOCK
BATTERY 7. 5A
IGN
7. 5A
ENGINE 7. 5A
ALT
SENCING
CHARGE W ARNING
LIG HT
[COMB . METER]
120A ALT
60A MAIN
A1 0 ,A11
A
B
ALTERNATOR
F9
C12
FROM POWER SOURCE SYSTEM
(
SEE PAGE 56 )
Y±G
TO INTE GRATION
RELAY
( CANADA )
I14
Y±G
WhereEverybodyKnowsYourName

26
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
A 1 A/C Ambient Temp. Sensor E 1 ECT Solenoid
A 2 A/C Lock Sensor and A/C Magnetic Clutch E 2 EFI Water Temp. Sensor
A 3 A/C High Pressure SW E 3 EGR Gas Temp. Sensor (for USA Spec.)
A 4 ABS Actuator E 5 Engine Hood Courtesy SW
A 5 ABS Actuator (w/ Traction Control) E 6 Engine Oil Level Warning SW
A 6 ABS Actuator (w/ Traction Control)
A 7 ABS Speed Sensor Front LH F 1 Front Airbag Sensor LH
A 8 ABS Speed Sensor Front RH F 2 Front Airbag Sensor RH
A 9 Air Flow Meter F 3 Front Clearance Light LH
A 10 Alternator F 4 Front Clearance Light RH
A 11 Alternator F 5Front Side Marker Light LH
A 33 ABS Actuator (w/o Traction Control) F 6 Front Side Marker Light RH F 7 Front Turn Signal Light LH
B 1 Brake Fluid Level SW F 8 Front Turn Signal Light RH
B 6 Back±Up Light SW (for M/T) F 9 Fuse Block
C 3 Check Connector H 1 Headlight Hi LH
C 6 Cornering Light LH H 2 Headlight Hi RH
C 7 Cornering Light RH H 3 Headlight Lo LH
C 8 Cruise Control Actuator H 4 Headlight Lo RH H 5 Horn LH
D 13 Distributor H 6 Horn RH
WhereEverybodyKnowsYourName

150
CRUISE CONTROL
CURRENT IS APPLIED AT ALL TIMES THROUGH STOP FUSE TO TERMINAL 1 OF THE CONTROL ECU TERMINAL 2 OF STOP LIGHT
SWITCH, AND ALSO THROUGH THE DOME FUSE TO TERMINAL 15 OF CRUISE CONTROL ECU.
WITH THE IGNITION SWITCH TURNED TO ON, THE CURRENT FLOWS THROUGH GAUGE FUSE TO TERMINAL (A)1 OF COMBINATION
METER AND THE CURRENT THROUGH ECU±IG FUSE FLOWS TO TERMINAL 14 OF CRUISE CONTROL ECU.
WHEN THE IGNITION SWITCH IS ON AND THE CRUISE CONTROL MAIN SWITCH IS TUR\
NED ON, A SIGNAL IS INPUT FROM TERMINAL
15 OF CRUISE CONTROL MAIN SWITCH TO TERMINAL 4 OF CRUISE CONTROL ECU. AS A RESULT, THE CRUISE CONTROL ECU
FUNCTIONS AND THE CURRENT TO TERMINAL 14 OF CRUISE CONTROL ECU TO TERMINAL 13 OF CRUISE CONTROL ECU "
GROUND, AND THE CRUISE CONTROL SYSTEM IS IN A CONDITION READY FOR OPERATION.
AT THE SAME TIME, THE CURRENT THROUGH THE GAUGE FUSE FLOWS FROM TERMINAL (A)1 OF CRUISE CONTROL INDICATOR
LIGHT " TERMINAL (B)20 "TERMINAL 5 OF CRUISE CONTROL ECU "TERMINAL 13 " TO GROUND, CAUSING THE CRUISE
CONTROL INDICATOR LIGHT TO LIGHT UP, INDICATING THAT THE CRUISE CONTROL IS READY FOR OPERATION.
1. SET OPERATION
WHEN THE CRUISE CONTROL MAIN SWITCH IS TURNED ON AND THE SET SWITCH IS PUSHE\
D WITH THE VEHICLE SPEED WITHIN
THE SET LIMIT (APPROX. 40 KM/H, 2.5 MPH TO 200 KM/H, 124 MPH), A SIGNAL IS INPUT TO TERMINAL 18 OF THE CRUISE CONTROL
ECU AND THE VEHICLE SPEED AT THE TIME THE SET SWITCH IS RELEASED IS MEMORIZED IN THE ECU AS THE SET\
SPEED.
2. SET SPEED CONTROL
DURING CRUISE CONTROL DRIVING, THE ECU COMPARES THE SET SPEED MEMORIZED IN THE ECU WITH THE ACTUAL VEHICLE
SPEED INPUT INTO TERMINAL 20 OF THE CRUISE CONTROL ECU FROM THE SPEED SENSOR, AND CONTROLS THE CRUIS\
E
CONTROL ACTUATOR TO MAINTAIN THE SET SPEED.
WHEN THE ACTUAL SPEED IS LOWER THAN THE SET SPEED, THE ECU CAUSES THE CURREN\
T TO THE CRUISE CONTROL
ACTUATOR TO FLOW FROM TERMINAL 12 " TERMINAL 6 OF CRUISE CONTROL ACTUATOR "TERMINAL 7 " TERMINAL 11 OF
CRUISE CONTROL ECU. AS A RESULT, THE MOTOR IN THE CRUISE CONTROL ACTUATOR IS ROTATED TO OPEN THE THROTTLE
VALVE AND THE THROTTLE CABLE IS PULLED TO INCREASE THE VEHICLE SPEED. WHEN THE ACTUAL DRIVING SPEED IS HIGHER
THAN THE SET SPEED, THE CURRENT TO CRUISE CONTROL ACTUATOR FLOWS FROM TERMINAL 11 OF ECU "TERMINAL 7 OF
CRUISE CONTROL ACTUATOR "TERMINAL 6 "TERMINAL 12 OF CRUISE CONTROL ECU.
THIS CAUSES THE MOTOR IN THE CRUISE CONTROL ACTUATOR TO ROTATE TO CLOSE THE THROTTLE VALVE AND RETURN THE
THROTTLE CABLE TO DECREASE THE VEHICLE SPEED.
3. COAST CONTROL
DURING THE CRUISE CONTROL DRIVING, WHILE THE COAST SWITCH IS ON, THE CRUISE CONTROL ACTUATOR RETURNS THE
THROTTLE CABLE TO CLOSE THE THROTTLE VALVE AND DECREASE THE DRIVING SPEED. THE VEHICLE SPEED WHEN THE COAST
SWITCH IS TURNED OFF IS MEMORIZED AND THE VEHICLE CONTINUES AT THE NEW SET SPEED.
4. ACCEL CONTROL
DURING CRUISE CONTROL DRIVING, WHILE THE ACCEL SWITCH IS TURNED ON, THE CRUISE\
CONTROL ACTUATOR PULLS THE
THROTTLE CABLE TO OPEN THE THROTTLE VALVE AND INCREASE THE DRIVING SPEED.
THE VEHICLE SPEED WHEN THE ACCEL SWITCH IS TURNED OFF IS MEMORIZED AND THE \
VEHICLE CONTINUES AT THE NEW SET
SPEED.
5. RESUME CONTROL
UNLESS THE VEHICLE SPEED FALLS BELOW THE MINIMUM SPEED LIMIT (APPROX. 40 KM/H, 25 MPH) AFTER CANCELING THE SET
SPEED BY THE CANCEL SWITCH, PUSHING THE RESUME SWITCH WILL CAUSE THE VEHICLE \
TO RESUME THE SPEED SET BEFORE
CANCELLATION.
6. MANUAL CANCEL MECHANISM
IF ANY OF THE FOLLOWING OPERATIONS OCCURS DURING CRUISE CONTROL OPERATION, THE SAFETY MAGNETIC CLUTCH OF
THE ACTUATOR TURNS OFF AND THE MOTOR ROTATES TO CLOSE THE THROTTLE VALVE AND THE CRUISE CONTROL IS
RELEASED.
* PLACING THE SHIFT LEVER IN ªNº RANGE (NEUTRAL START SWITCH ON)). ªSIGNAL INPUT TO TERMINAL 2 OF ECUº
* DEPRESSING THE BRAKE LEVER (STOP LIGHT SWITCH ON). ªSIGNAL INPUT TO TERMINAL 16 OF ECUº
* PULLING THE PARKING BRAKE PEDAL (PARKING BRAKE SWITCH ON). ªSIGNAL INPUT TO TERMINAL 3 OF ECUº
* PUSHING THE CANCEL SWITCH (CANCEL SWITCH ON). ªSIGNAL INPUT TO TERMINAL 18ª
SYSTEM OUTLINE
WhereEverybodyKnowsYourName
