CLEARING OF DIAGNOSTIC CODE
1. CLEARING OF MALFUNCTION CODE(EXCEPT CODE 41)
Remove the battery negative (±) terminal or ECU±B fuse for
10 seconds or more with the ignition switch OFF.
NOTICE: When connecting the battery after cancelling
the malfunction code, always do it with the ignition
switch in LOCK position. If the battery is connected with
the ignition switch in ACC or ON position, there are cases
when the diagnosis system does not operate normally.
HINT:
wCode 41 cannot be cleared by this method.
wThe lower the temperature, the longer the battery
negative (±) terminal must be left off.
wOther memory systems (clock, audio system) will also
be cancelled out (See page AB±2).
2. CLEARING OF MALFUNCTION CODE 41 STORED IN MEMORY
(a) Connect service wires to terminals Tc and AB of theTDCL.
(b) Turn the ignition switch ACC or ON and wait approx. 6 seconds.
(c) S ta rtin g with th e Tc te rmin a l, ap p ly bo d y gr ound
alternately to terminal Tc and terminal AB twice each in
cycles of 1.0 ± 0.5 seconds. Finally, keep applying body
ground to terminal Tc.
HINT: When alternating between body ground of terminals Tc
and AB release one from body ground while applying it to the
other terminal. The time interval in between must be within
the following conditions. If it is out of the conditions, code 41
will not be cleared.
(d) After several seconds, when the airbag warning light
starts to blink in a 64 msec. cycle, cancellation is
completed.
HINT: This method clears not only code No. 41, but also other
malfunction codes all at once.
Except when instructed by the troubleshooting procedure,
use this method only when the repair procedure is completed
(See page AB±25).
AB±32
SRS AIRBAG
± Troubleshooting
WhereEverybodyKnowsYourName

MAINTENANCE
GENERAL NOTES:
wThere are 2 separate maintenance schedules,
namely A and B, which apply to different driving
conditions. Find out how the vehicle is driven,
select the appropriate schedule and service the
vehicle accordingly.
w Every service item in the periodic maintenance list
must be performed.
w Next to the columns of periods in the schedule,
reference pages have been added for easy access
to service data and procedures necessary for each
operation.
w The service interval for scheduled maintenance is
determined by the odometer reading or time
interval, whichever comes first, shown in the
schedule.
w Maintenance services after the last period should
be performed at the same interval as before unless
otherwise noted.
w Skipping even 1 item in the list can cause the
engine to run poorly and increase exhaust
emissions.
MA±1
WhereEverybodyKnowsYourName

DIAGNOSTIC TROUBLE CODE
CLEARANCE
Using diagnostic check wire:(a) Connect the 2 service wires to terminals Tc and AB of DLC1.
(b) Turn the ignition switch ACC or ON And wait approx. 6 seconds.
(c) Starting with the Tc terminal, apply body ground alternately to terminal Tc and terminal AB twice each in cycles of 1.0
seconds Confirm that body ground is absolute. Finally, keep
applying body ground to terminal Tc.
HINT: When alternately grounding terminals Tc and AB, re-
lease ground from one terminal and immediately apply it to
the other terminal within an interval of 0.2 second. If diagnos-
tic trouble codes do not clear, repeat the above procedure un-
til the codes are cleared.
(d) Several seconds after performing the clearing procedure, theSRS warning light will blink in a 50 m sec cycle to indicate the
codes have been cleared.
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±63
