(b) Remove four clips.
(c) Remove the clip and ambient temperature sensor.
(d) Remove four nuts.
(e) Remove ten clips.
(f) Remove two bolts.
(g) Disconnect the connectors.
(h) Remove the bumper cover assy.
6. REMOVE REINFORCEMENT Remove six bolts and the reinforcement.
7. REMOVE UPPER REINFORCEMENT Remove eight bolts and the reinforcement.
8. REMOVE HEADLIGHT (High Beam)
(a) Remove two screws, a clip and the headlight.
(b) Disconnect the connector.
±
BODY Bumper (Front Bumper)BO±13
WhereEverybodyKnowsYourName
Page 833 of 4087
Parts Replacement ± Headlight
(Headlight)
REPLACEMENT OF HEADLIGHT
1. REMOVE HEADLIGHT(a) Remove battery (LH) or disconnect negative termial (±)from the battery (RH).
CAUTION: Work must be started after approx. 20 se-
conds or longer from the time the ignition switch is
turned to the ºLOCKº position and negative (±) terminal
cable is disconnected from the battery.
(b) Remove fender liner. ( BO±92)
(c) Remove a screw and two nuts.
(d) Disconnect connector.
(e) Remove headlight (Low Beam).
(f) Disconnect connector.
(g) Remove front bumper. ( BO±12)
(h) Remove the bolt.
(i) Remove headlight (High±Beam).
2. INSTALL HEADLIGHT For installation, follow the removed procedure in reverse.
±
BODY ELECTRICAL SYSTEM Lighting SystemBE±37
WhereEverybodyKnowsYourName
Page 843 of 4087

5. USAINSPECT COMBINATION SWITCH CIRCUIT
(a) Pull the spool body to forward and separate spool bodyfrom steering column.
(b) C onnect the wire harness side connector to the
combination switch and inspect wire harness side
connector from the back side as shown.
(Light Control Switch Circuit)
Check forTester connectionConditionSpecified value
ContinuityB4±GroundConstantContinuity
(Dimmer Switch Circuit)
Check forTester connectionConditionSpecified value
*1B7 GroundLight Control Switch PositionOFF or TAILNo voltage*1B7±GroundLight Control Switch PositionHEADBattery voltage
VoltageLow beamNo voltage
*1B9±GroundDimmer Switch PositionFlash or High
beamBattery voltage
ContinuityB18±GroundConstantContinuity
*1: USA
(Turn Signal Switch Circuit)
Check forTester connectionConditionSpecified value
VoltageA3±GroundHazard Warning Switch ONBattery voltage
e 0 V
Ignition Switch ON and turn
signal switch positionRightBattery voltage
e 0 V
A4±GroundHazard Warning Switch ONBattery voltage
e 0 V
Ignition Switch ON and turn
signal switch positionLeftBattery voltage
e 0 V
ContinuityA12±GroundConstantContinuity
(Cornaring Light Control Switch Circuit)
Check forTester connectionConditionSpecified value
VoltageA8±GroundLight control switch HEAD andLOBattery voltagegg
dimmer switch positionHI or FLASHNo voltage
ContinuityA10±GroundConstant*2 Continuityy
A11±GroundConstant*2Continuity
*2 There is resistance because this circuit is grounded through the bulb.
If the circuit is not as specified, refer to BE±34 wiring diagram
and inspect the circuits connected to other parts.
±
BODY ELECTRICAL SYSTEM Lighting SystemBE±47
WhereEverybodyKnowsYourName
Page 846 of 4087

(Canada)
Check forTester connectionConditionSpecified value
ContinuityA4±GroundPassenger's CourtesyOFFNo continuityygy
ONContinuity
A5±GroundIgnition KeyPull offNo continuitygy
Put inContinuity
A6±GroundDriver's CourtesyOFFNo continuityy
ONContinuity
A8±GroundSeat BeltUnfastenContinuity
FastenNo continuity
A10±GroundConstantContinuity
A12±GroundConstantContinuity
B1±GroundPassenger's DoorUnlockContinuityg
LockNo continuity
B2±GroundParking Brake
Switch PositionOFF (Switch pin
pushed in)No continuity
ON (Switch pin re-
leased)Continuity
B3±GroundDriver's DoorUnlockContinuity
LockNo continuity
B7±GroundHeadlight Dimmer
Switch PositionLow Beam or High
BeamNo continuity
FlashContinuity
B8±GroundHeadlight DimmerLow BeamNo continuityg
Switch PositionHigh Beam or FlashContinuity
B10±GroundLight Control SwitchOFFNo continuityg
HEAD or TAILContinuity
B12±GroundConstantContinuity
B13±GroundLight Control SwitchOFF or TAILNo continuityg
HEADContinuity
VoltageA1±GroundConstantVoltageg
A2±GroundConstant*Voltage
A7±GroundIgnition SwitchONVoltageg
LOCK or ACCNo voltage
A9±GroundIgnition SwitchON*Voltageg
LOCK or ACCNo voltage
A11±GroundIgnition SwitchON or ACCVoltageg
LOCKNo voltage
B4±GroundEngineSTOPNo voltageg
RunningVoltage
B11±GroundConstantVoltage
* There is resistance because this circuit is grounded through the bulb.\
If the circuit is as specified, trying replacing the relay with a
new one.
If the circuit is not as specified, refer to BE±35 wiring diagram
and inspect the circuit connected to other parts.
BE±50
±
BODY ELECTRICAL SYSTEM Light System
WhereEverybodyKnowsYourName
Page 1140 of 4087
8. INSPECT CHARGING CIRCUIT WITH LOAD(a) With the engine running at 2,000 rpm, turn on the highbeam headlights and place the heater blower switch at
ºHIº.
(b) Check the reading on the ammeter.
Standard amperage: 30 A or more
If the ammeter reading is less than standard amperage, re-
pair the alternator. (See page CH±9)
HINT: With the battery fully charged, the indication will some-
times be less than standard amperage.
9. REINSTALL ENGINE UNDER COVER
CH±8
±
CHARGING SYSTEM On±Vehicle Inspection
WhereEverybodyKnowsYourName
Page 2772 of 4087
8. INSPECT CHARGING CIRCUIT WITH LOAD(a) With the engine running at 2,000 rpm, turn on the highbeam headlights and place the heater blower switch at
ºHIº.
(b) Check the reading on the ammeter.
Standard amperage: 30 A or more
If the ammeter reading is less than standard amperage, re-
pair the alternator. (See page CH±9)
HINT: With the battery fully charged, the indication will some-
times be less than standard amperage.
9. REINSTALL ENGINE UNDER COVER
CH±8
±
CHARGING SYSTEM On±Vehicle Inspection
WhereEverybodyKnowsYourName
Page 3860 of 4087
218COMBINATION METER
1E
81E 13
1E
12 1H 12
1J
1
3D
23A 3
3D
13D 11
1E
4
1G
9
1K
12
1E18 3D
13 3A
4
IG1
8BU1 4BU110 BU1 3
IG3
1 IK1
8
IK1
9IK2 24
IJ 1
5 1
IF BK
A
14 A 11 C 1
A
15 A 10 B 6A 8C8C 7C 9
C
21 C 22
132
L±R
FROM POWER SOURCE SYSTEM
(
SEE PAGE 56 )
4
Y
W±B W±B
B±O
W±R
YYY
Y±G Y±G Y±G Y±G B±Y
R
Y±B
B±W B±Y
B
Y±G
BR±B
BR
Y±G
B
B±Y
B±W Y±B
W±B B±Y
B±Y
W±B W±B
10A
GAUGE
15A
ECU±B
7. 5A
IGN
FUEL SENDER
IGNITER NO. 1 WATER TEMP.
SENDER
A
1A 2A 3
B
1 COMBINATION METER
TO CENTE R AIRB AG
SENSOR ASSEMBLY
TA CH
C12 , C1 3 , C 14
F1 7 ,
F18
I2 W3
ABC
B A SPEED SENSOR NO. 1
CHARGE
AIRBAG
HIGH BEAM
FUEL
FUEL
WATER. TEMP TACHO
S3
VCC OUT GND
2
B
7
R±W
15A
HEAD (
RH )
( FOR USA )
HEAD
( RH±LWR )
( FOR
CA NADA )
3B
2
B±Y
B±Y
TO CHECK CONNECTOR
( E/G )
3E
10
B±Y
TO CHECK CONNECTOR
( RM )
IK1
23
R
(
CANADA )
(USA )
TO DIMMER SW
[COMB. SW] R±W
IG1
9
IG1+ R
L±R
IK1
7
2 L
ALTERNAOR BR
IE1
12
R±W
IJ1
10
A1 0
WhereEverybodyKnowsYourName
Page 3920 of 4087

237
