1986 TOYOTA LAND CRUISER wiper

2004 LAND CRUISER (EWD548U)
197
When the ignition SW turned on, the current from the WIPER fuse flows to the front wiper and washer SW TERMINAL 17,
and the front wiper motor TERMINAL 2.
1. Low Position
When the front wiper SW is turned to LO position, the current flows from the front wiper and washer SW TERMINAL 17 to
TERMINAL 7 to the front wiper motor TERMINAL 1 to TERMINAL 5 to GROUND, and operates the front wiper motor at low
speed.
2. High Position
When the front wiper SW is turned to HI position, the current flows from the front wiper and washer SW TERMINAL 17 to
TERMINAL 8 to the front wiper motor TERMINAL 4 to TERMINAL 5 to GROUND, and operates the front wiper motor at high
speed.
3. INT Position
When the front wiper SW is turned to INT position, the relay operates and the current which is connected by the relay
function flows from the front wiper and washer SW TERMINAL 17 to TERMINAL 2 to GROUND, and operates the wipe.
The intermittent operation is controlled by the charge/discharge function of the condenser installed in the relay, and the
intermittent time is controlled by a time control SW to change the charging time of the condenser.
4. Washer Interlocking Operation
When the front washer SW is pulled up, the current flows from the washer motor TERMINAL 2 to TERMINAL 3 to the front
wiper and washer SW TERMINAL 11 to TERMINAL 2 to GROUND, operates the washer motor and the window washer
emits a water spray. This causes the current to flow to the washer continuous operation circuit in the front wiper and washer
SW TERMINAL 11 to TERMINAL 7 to front wiper motor TERMINAL 1 to TERMINAL 5 to GROUND, and operates the wiper.
C19 Combination SW
17-Ground : Approx. 12 volts with ignition SW at ON or ST position
7-Ground : Approx. 12 volts with front wiper and washer SW at LO position
: Approx. 12 volts 1.6 to 10.7 seconds intermittently with the front wiper and washer SW at INT position
16-Ground : Approx. 12 volts with ignition SW on unless the front wiper motor at STOP position
8-Ground : Approx. 12 volts with front wiper and washer SW at HI position
2-Ground : Always continuity
F5 Front Wiper Motor
2-Ground : Approx. 12 volts with ignition SW at ON or ST position
5-Ground : Always continuity
: Parts Location
CodeSee PageCodeSee PageCodeSee Page
C1970J371
F568W169
:Junction Block and Wire Harness Connector
CodeSee PageJunction Block and Wire Harness (Connector Location)
1A24Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1B24Engine Room No.2 Wire and Engine Room J/B (Engine Compartment Left)
2A28Engine Room No.2 Wire and Cowl Side J/B LH (Left Kick Panel)
2D28Dash Wire and Cowl Side J/B LH (Left Kick Panel)
3A40Engine Room No.2 Wire and Cowl Side J/B RH (Right Kick Panel)
3E40Dash Wire and Cowl Side J/B RH (Right Kick Panel)3G40Dash Wire and Cowl Side J/B RH (Right Kick Panel)
:Connector Joining Wire Harness and Wire Harness
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
EA276Engine Room Main Wire and Engine Room No.2 Wire (Engine Compartment Right)
II380Dash Wire and Column Wire (Near the Ignition SW)
System Outline
Service Hints

2004 LAND CRUISER (EWD548U)
198Front Wiper and Washer
:Ground Points
CodeSee PageGround Points Location
EB76Front Right Side of Fender Apron
II78Set Bolt of Cowl Side J/B RH

2004 LAND CRUISER (EWD548U)
200Rear Wiper and Washer
M
Wash
OFF
INT
ON
Wash
+
+1
- S
II 3E 35A A
J 3
15A
RR WIPER
2K 2
BP3 5
L
BH1 1
L
B15
L L
314
2
BJ BP3 6
W- B W- B
BH2 5
W- B
15A
WASHER Fr om Power Source System (
See Page 94)
3A 9
EA2 2
1 2
1A 48
1B 542D 39
14 2AII3 36 II34II35 II33 12 10 13 2
ID4 2ID43
L- B
L- Y
BP3 4 BP33
L- O
L- Y
BH1 3 BH1 4BA
BA
R30
W 1
W- BL- Y
P
L- B
P
P
L- B
L- Y L- B
L- Y
W- B L- O
L- Y
W- BL
LC19
L L
J22
PCombination SW
Rear Wiper Motor
Washer Motor
Junction
ConnectorJunction
Connector
3456 2
L- O
L- Y L- O L- O
L- Y
R31
Rear Wiper Relay
Rear Wi per SW Rear Washer SW
M BH2 1(
*1)
(
*2)
BH2 3(
*1)
(
*2)BH2 7BH28(
*1)
(
*2)
* 2 : w/o Navigation System * 1 : w/ Navigation System

2004 LAND CRUISER (EWD548U)
201
When the ignition SW is turned on, the current flows from the WASHER fuse to washer motor TERMINAL 2, and the current
flows from the RR WIPER fuse to rear wiper relay TERMINAL 3, and the rear wiper motor TERMINAL 1 respectively.
1. Rear Wiper Normal Operation
When the ignition SW is turned on, and the rear wiper and washer SW is turned to ON position, the current flows from the
rear wiper relay TERMINAL 3 to TERMINAL 6 to the rear wiper and washer SW TERMINAL 10 to TERMINAL 2 to
GROUND, and turns on the rear wiper relay. As a result, the current flows from the rear wiper relay TERMINAL 3 to
TERMINAL 4 to the rear wiper motor TERMINAL 3 to TERMINAL 2 to GROUND, and operates the rear wiper.
2. Rear Wiper Intermittent Operation
When the ignition SW is turned on, and the rear wiper and washer SW is turned to INT position, the current flows from the
rear wiper relay TERMINAL 3 to TERMINAL 2 to the rear wiper and washer SW TERMINAL 13 to TERMINAL 2 to
GROUND, and the intermittent circuit in the rear wiper relay is controlled to operate the wiper intermittently.
3. Washer Operation
When the ignition SW is turned on, and the rear wiper and washer SW is turned from OFF to WASH position, the current
flows from the WASHER fuse to the washer motor TERMINAL 2 to TERMINAL 1 to the rear wiper and washer SW
TERMINAL 12 to TERMINAL 2 to GROUND. This activates the washer motor, and the window washer emits a water spray.
When the rear wiper and washer SW is turned to ON position, the window washer emits a water spray during rear wiper
normal operation.
W1 Washer Motor
2-Ground : Approx. 12 volts with ignition SW at ON or ST position
1-Ground : Continuity with rear wiper and washer SW at WASH position
R30 Rear Wiper Motor
1-Ground : Approx. 12 volts with ignition SW at ON or ST position
2-Ground : Always continuity
: Parts Location
CodeSee PageCodeSee PageCodeSee Page
C1970J2272R3173
J371R3073W169
:Junction Block and Wire Harness Connector
CodeSee PageJunction Block and Wire Harness (Connector Location)
1A24Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1B24Engine Room No.2 Wire and Engine Room J/B (Engine Compartment Left)
2A28Engine Room No.2 Wire and Cowl Side J/B LH (Left Kick Panel)
2D28Dash Wire and Cowl Side J/B LH (Left Kick Panel)
2K28Floor No.1 Wire and Cowl Side J/B LH (Left Kick Panel)
3A40Engine Room No.2 Wire and Cowl Side J/B RH (Right Kick Panel)
3E40Dash Wire and Cowl Side J/B RH (Right Kick Panel)
:Connector Joining Wire Harness and Wire Harness
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
EA276Engine Room Main Wire and Engine Room No.2 Wire (Engine Compartment Right)
ID478Dash Wire and Floor No.1 Wire (Left Kick Panel)
II380Dash Wire and Column Wire (Near the Ignition SW)
BH186Pillar No 1 Wire and Back Door Upper Wire (Left Side of Back Door)BH286Pillar No.1 Wire and Back Door Upper Wire (Left Side of Back Door)
BP388Pillar No.1 Wire and Floor No.1 Wire (Left Rear Side Quarter Panel)
System Outline
Service Hints

2004 LAND CRUISER (EWD548U)
202Rear Wiper and Washer
:Ground Points
CodeSee PageGround Points Location
II78Set Bolt of Cowl Side J/B RH
BJ86Under the Driver's Seat
:Splice Points
CodeSee PageWire Harness with Splice PointsCodeSee PageWire Harness with Splice Points
B1588Back Door Upper Wire

2004 LAND CRUISER (EWD548U)
