- BODYFRONT WIPER AND WASHER
2610 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL WASHER NOZZLES
2. INSTALL WIPER LINK
Install the wiper link through the service hole, then torque the
6 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
HINT:
When installing the wiper link, connect the claw of wiper link to
the panel.
3. INSTALL WIPER MOTOR
(a) Connect the wiper motor to wiper link.
(b) Torque the 4 bolts.
(c) Connect the connector.
4. INSTALL COWL TOP VENTILATOR LOUVERS
(a) Install the cowl top ventilator louver LH.
(b) Install the cowl top ventilator louver RH.
5. INSTALL HOOD TO COWL TOP SEAL
6. INSTALL WIPER ARMS
(a) Operate the wipers once and turn the wiper switch OFF.
(b) Install the wiper arms and tighten nuts by hand.
(c) Adjust the installation position of the wiper arms to the
positions shown in the illustration.
A: Approx. 40 mm (1.57 in.)
B: Approx. 16 - 26 mm (0.63 - 1.02 in.)
(d) Torque the nuts.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(e) Install the wiper arm caps.

BO1JS-03
H04841
H00735
- BODYFRONT WIPER AND WASHER
BO-33
2607 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE WIPER ARMS
(a) Remove the 2 caps and 2 nuts.
(b) Remove the 2 wiper arms.
2. REMOVE HOOD TO COWL TOP SEAL
3. REMOVE COWL TOP VENTILATOR LOUVERS
(a) Remove the cowl top ventilator louver RH.
(b) Remove the cowl top ventilator louver LH.
4. REMOVE WIPER MOTOR
(a) Disconnect the connector, unfasten the 4 bolts.
(b) Disconnect the wiper motor from the wiper link, then re-
move the wiper motor.
5. REMOVE WIPER LINK
(a) Loosen the 6 bolts.
(b) Remove the wiper link through the service hole.
6. REMOVE WASHER NOZZLE
(a) Disconnect the washer hose.
(b) Using a screwdriver, remove the washer nozzle.
HINT:
Tape the screwdriver tip before use.
(c) Employ the same manner described above to the other
side.

BO1JZ-03
BE3367
2 - 2.5 mm
(0.028 - 0.030 in.)0.7 - 0.75 mm(0.079 - 0.098 in.)
- BODYREAR WIPER AND WASHER
BO-41
2615 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the back door glass.

BO1JW-03
H18909
Rear Wiper Arm
Center Back Door Garnish
Back Door GarnishAssist Grip
Assist Grip PlugInside Handle Bezel Grommet
Rear Wiper Motor
and Link Assembly
5.4 (55, 48 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
- BODYREAR WIPER AND WASHER
BO-37
2611 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR WIPER AND WASHER
COMPONENTS

BO1JY-03
H18919
BA C
E
F D
G
BO-40
- BODYREAR WIPER AND WASHER
2614 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the back door glass is within the range indicated in the
illustration.
A: Approx. 40 mm (1.57 in.)
B: Approx. 180 mm (7.09 in.)
C: Approx. 40 mm (1.57 in.)
D: Approx. 30 mm (1.18 in.)
E: Approx. 120 mm (4.72 in.)
F: Approx. 90 mm (3.54 in.)
G: Approx. 15 mm (0.59 in.)

BO1K0-03
H18908
H05251
A BO-42
- BODYREAR WIPER AND WASHER
2616 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL REAR WIPER MOTOR AND LINK AS-
SEMBLY
(a) Install the wiper motor and link assembly with 5 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(b) Connect the connector.
2. INSTALL BACK DOOR GARNISH
3. INSTALL CENTER BACK DOOR GARNISH
4. INSTALL INSIDE HANDLE BEZEL
5. INSTALL ASSIST GRIP
Install the assist grip with the 2 screws, then install the 2 assist
grip plugs.
6. INSTALL REAR WIPER ARM
(a) Install the grommet.
(b) Operate the wiper once and turn the wiper switch OFF.
(c) Install the wiper arm and tighten the nut by hand.
(d) Adjust the installation position of the wiper arm to the posi-
tion as shown in the illustration.
A: Approx. 38 ± 10 mm (1.50 ± 0.39 in.)
(e) Torque the nut.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(f) Close the cover.

BO1JX-03
H04849
H04847
ab
a - ab - b : 9 Clips
ab
H04848
: 10 Clips BO-38
- BODYREAR WIPER AND WASHER
2612 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE REAR WIPER ARM
(a) Open the cover.
(b) Remove the nut and rear wiper arm.
(c) Remove the grommet.
2. REMOVE ASSIST GRIP
(a) Using a screwdriver, remove the 2 assist grip plugs.
HINT:
Tape up the screwdriver tip before use.
(b) Remove the 2 screws and assist grip.
3. REMOVE INSIDE HANDLE BEZEL
4. REMOVE CENTER BACK DOOR GARNISH
Using a screwdriver, remove the center back door garnish.
HINT:
Tape up the screwdriver tip before use.
5. REMOVE BACK DOOR GARNISH
Using a screwdriver, remove the back door garnish.
HINT:
Tape up the screwdriver tip before use.

H18908
- BODYREAR WIPER AND WASHER
BO-39
2613 Author
: Date
:
2004 LAND CRUISER (RM1071U)
6. REMOVE REAR WIPER MOTOR AND LINK AS-
SEMBLY
(a) Disconnect the connector.
(b) Remove the 2 bolts.
(c) Unfasten the 3 bolts and remove the rear wiper motor with
link assembly.
