1986 TOYOTA LAND CRUISER wiper

BE0RZ-03
I07176
OFF
INT
LO
HIWasher ON
I01313
2 7
16
I01314
2 7
16 17
INT time control
switch positionVoltage
0.6 - 2.6 secs.
Battery Positive
voltage
0 Volt
0 Volt 5.7 - 15.7 secs. FAST
SLOW
Battery Positive
voltage BE-52
- BODY ELECTRICALWIPER AND WASHER SYSTEM
2425 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT FRONT WIPER AND WASHER SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
OFF7 - 16Continuity
INT7 - 16Continuity
LO7 - 17Continuity
HI8 - 17Continuity
Washer OFF-No continuity
Washer ON2 - 11Continuity
If continuity is not as specified, replace the switch.
2. INSPECT FRONT WIPER INTERMITTENT OPERA-
TION
(a) Turn the wiper switch to INT position.
(b) Turn the intermittent time control switch to FAST position.
(c) Connect the positive (+) lead from the battery to terminal
16 and the negative (-) lead to terminal 2.
(d) Connect the positive (+) lead from the voltmeter to termi-
nal 7 and the negative (-) lead to terminal 2, check that
the meter needle indicates battery voltage.
(e) After connecting terminal 16 to terminal 17, connect to
terminal 2 to terminal 17, check the voltage rises from 0
volts to battery voltage within the times, as shown in the
table.
If operation is not as specified, replace the wiper and washer
switch.

I06436
Washer 2
ON
INT
OFF
Washer 1
I06438
51
I06439
4
5
I06440
51
- BODY ELECTRICALWIPER AND WASHER SYSTEM
BE-53
2426 Author
: Date
:
2004 LAND CRUISER (RM1071U)
3. INSPECT REAR WIPER AND WASHER SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
Washer 12 - 12Continuity
OFF-No Continuity
INT2 - 13Continuity
ON2 - 10Continuity
Washer 22 - 10 - 12Continuity
If continuity is not as specified, replace the switch.
4. Low speed:
INSPECT FRONT WIPER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 1 and
the negative (-) lead to terminal 5, check that the motor oper-
ates at low speed.
If operation is not as specified, replace the motor.
5. High speed:
INSPECT FRONT WIPER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 4 and
the negative (-) lead to terminal 5, check that the motor oper-
ates at high speed.
If operation is not as specified, replace the motor.
6. Stopping at stop position:
INSPECT FRONT WIPER MOTOR OPERATION
(a) Operate the motor at low speed and stop the motor opera-
tion anywhere except at the stop position by disconnect-
ing positive (+) lead from terminal 1.

I06441
1
52 3
I01975
2
1
I25796
3 2
I25797
3 2
I25798
1
2
3 4
BE-54
- BODY ELECTRICALWIPER AND WASHER SYSTEM
2427 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(b) Connect terminals 1 and 3.
(c) Connect the positive (+) lead from the battery to terminal
2 and negative (-) lead to terminal 5, check that the motor
stops running at the stop position after the motor operates
again.
If operation is not as specified, replace the motor.
7. INSPECT FRONT WASHER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 2 and
the negative (-) lead to terminal 1, check that the motor oper-
ates.
8. Low speed:
INSPECT REAR WIPER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 3 and
negative (-) lead to terminal 2, check that the motor operates
at low speed.
If operation is not as specified, replace the motor.
9. Stopping at stop position:
INSPECT REAR WIPER MOTOR OPERATION
(a) Operate the motor at low speed and stop the motor opera-
tion anywhere except at the stop position by disconnect-
ing positive (+) lead from terminal 3.
(b) Connect terminals 3 and 4.
(c) Connect the positive (+) lead from the battery to terminal
1 and negative (-) lead to terminal 2, check that the motor
stops running at the stop position after the motor operates
again.
If operation is not as specified, replace the motor.
NOTICE:
These tests must be performed quickly (within 20 seconds) to
prevent the coil from burning out.
If operation is not as specified, replace the motor.

I01272
2
1
I25793
- BODY ELECTRICALWIPER AND WASHER SYSTEM
BE-55
2428 Author
: Date
:
2004 LAND CRUISER (RM1071U)
10. INSPECT REAR WASHER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 2 and
the negative (-) lead to terminal 1, check that the motor oper-
ates.
NOTICE:
These tests must be performed quickly (within 20 seconds) to
prevent the coil from burning out.
If operation is not as specified, replace the motor.
11. INSPECT REAR WIPER RELAY CONTINUITY
Switch positionTester connectionSpecified condition
OFF--
INT1 - 4 - 6Continuity
LO3 - 5 - 6Continuity
Wash23 - 5 - 6Continuity
If continuity is not as specified, replace the relay.

BE0HN-1 1
I24742
Wiper Motor
Washer Tank

Rear Washer Motor

Front Washer Motor Combination Switch

Wiper and Washer Switch

Rear Wiper and Washer Switch
Cowl SIde J/B LH

RR WIPER FuseIgnition Switch
Rear Wiper Relay
Rear Wiper Motor
Cowl SIde J/B RH

WASHER Fuse

WIPER Fuse
- BODY ELECTRICALWIPER AND WASHER SYSTEM
BE-51
2424 Author
: Date
:
2004 LAND CRUISER (RM1071U)
WIPER AND WASHER SYSTEM
LOCATION

BO1KA-02
H06468
Back Door Glass

Spacer
Back Window Outside Moulding
Center Back Door Garnish
Back Door Garnish
Assist Grip
Assist Grip Plug
Inside Handle Bezel
Rear Wiper Arm
Clip

Spacer
Clip
5.4 (55, 48 in.´lbf): Specified torqueN´m (kgf´cm, ft´lbf)

Non-reusable part
- BODYBACK DOOR GLASS
BO-65
2639 Author
: Date
:
2004 LAND CRUISER (RM1071U)
BACK DOOR GLASS
COMPONENTS

H04081
a
A
B a
a-a
H04848
: 10 Clips BO-70
- BODYBACK DOOR GLASS
2644 Author
: Date
:
2004 LAND CRUISER (RM1071U)
7. APPLY ADHESIVE
(a) Cut off the tip of the cartridge nozzle.
HINT:
After cutting off the tip, use all adhesive within the time de-
scribed in the table below.
TemperatureTackfree time
35 °C (95 °F)15 minutes
20 °C (68 °F)100 minutes
5 °C (41 °F)8 hours
(b) Load the cartridge into the sealer gun.
(c) Coat the glass with adhesive, as shown in the illustration.
A: 8.0 mm (0.315 in.)
B: 12.0 mm (0.472 in.)
8. INSTALL BACK DOOR GLASS
(a) Install the glass to the body.
(b) Hold back window glass in place securely with protective
tape or equivalent until the adhesive hardens.
NOTICE:
Take care not to drive the vehicle during the time described
in the table below.
TemperatureMinimum time prior to moving a car
35 °C (95 °F)1.5 hours
20 °C (68 °F)5 hours
5 °C (41 °F)24 hours
9. INSPECT FOR LEAKS AND REPAIR
(a) Conduct a leak test after the hardening time has elapsed.
(b) Seal any leak with sealant.
Part No. 08833-00030 or equivalent.
10. INSTALL REAR WIPER ARM (See page BO-42)
11. INSTALL BACK DOOR GARNISH

BO21B-01
H04847
: 9 Clips
ba
a - a
b - b
ab
H04848
: 10 Clips
H04076
BO-66
- BODYBACK DOOR GLASS
2640 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE ASSIST GRIP
(a) Using a screwdriver, remove the 2 assist grip plugs.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 2 screws and assist grip.
2. REMOVE INSIDE HANDLE BEZEL
3. REMOVE CENTER BACK DOOR GARNISH
Using a screwdriver, remove the center back door garnish.
HINT:
Tape the screwdriver tip before use.
4. REMOVE BACK DOOR GARNISH
Using a screwdriver, remove the back door garnish.
HINT:
Tape the screwdriver tip before use.
5. REMOVE REAR WIPER ARM (See page BO-38)
6. REMOVE OUTSIDE BACK WINDOW MOULDING
Using a knife, cut off the moulding as shown in the illustration.
NOTICE:
Do not damage the body with the knife.
