CodePart Name Part NumberCodePart Name Part Number
2004 LAND CRUISER (EWD548U)
407
D21Door Lock Motor Front LHD21Door Unlock Detection SW Front LH
D22Door Lock Motor Front RHD22Door Unlock Detection SW Front RH90980-1 1150
D23Door Lock Motor Rear LH90980-11150
D23Door Unlock Detection SW Rear LH
D24Door Lock Motor Rear RHD24Door Unlock Detection SW Rear RH
D26DVD Automatic Changer90980-1 1971
D27Door Control Receiver90980-1 1909
E 1Electronically Controlled Transmission
Solenoid90980-12293
E 2Engine Coolant Temp. Sensor90980-10736
E 3Engine Hood Courtesy SW90980-1 1003
E 4Electronically Controlled Transmission
Pattern Select SW90980-10933
E 5Engine Control Module90980-12144
E 6Engine Control Module90980-12145
E 7Engine Control Module90980-12143
E 8Engine Control Module90980-12146
E 9Engine Control Module90980-12142
F 1Front Fog Light LH90980-1 1660F 2Front Fog Light RH90980-1 1660
F3Front Turn Signal Light LHF 3Side Marker Light LH90980-1 1020
F4Front Turn Signal Light RH90980-1 1020
F 4Side Marker Light RH
F 5Front Wiper Motor90980-1 1599
F 8Front Door Speaker LH90980-10935F 9Front Door Speaker RH90980-10935
F10Front Interior Light90980-12211F10Rear Personal Light90980-12211
F11Front Personal Light90980-10825
F12Fuel Pump90980-1 1077F12Fuel Sender90980-11077
F14Fuel Pump Resistor90980-1 1156
F15Fusible Link Block90980-1 1996
F16Fusible Link Block90980-1 1881
F17Fusible Link Block90980-1 1775
F18Fusible Link Block90980-10995
F19Fusible Link Block82675-60050
G 1Generator90980-1 1964
G 2Generator90980-09212
G 3Glove Box Light90980-1 1098
G 4Gateway ECU90980-1 1911
H 1Headlight LH (High)90980-1 1659
H 2Headlight LH (Low)90980-1 1660
H 3Headlight RH (High)90980-1 1659
H 4Headlight RH (Low)90980-1 1660
H 5Heated Oxygen Sensor (Bank 1 Sensor 1)90980-10869
H 6Heated Oxygen Sensor (Bank 1 Sensor 2)90980-1 1028
H 7Heated Oxygen Sensor (Bank 2 Sensor 1)90980-10869
H 8Heated Oxygen Sensor (Bank 2 Sensor 2)90980-1 1028
H 9Horn LH90980-10619H10Horn RH90980-10619
H11High Mounted Stop Light90980-1 1211
I 1Ignition Coil and Igniter No.1
I 2Ignition Coil and Igniter No.2
I 3Ignition Coil and Igniter No.3
I 4Ignition Coil and Igniter No.490980-1 1885I 5Ignition Coil and Igniter No.590980-1 1885
I 6Ignition Coil and Igniter No.6
I 7Ignition Coil and Igniter No.7
I 8Ignition Coil and Igniter No.8
I 9Injector No.1
I10Injector No.2
I11Injector No.3
I12Injector No.490980-1 1153I13Injector No.590980-11153
I14Injector No.6
I15Injector No.7
I16Injector No.8
I18Ignition SW90980-1 1615
I22Inner Mirror90980-1 1186
J 1Junction Connector90980-1 1398
J 2Junction Connector90980-1 1915
J 3Junction Connector90980-1 1398J 4Junction Connector90980-1 1398
J 5Junction Connector90980-1 1925
J 6Junction Connector90980-1 1927J 7Junction Connector90980-1 1927
J 8Junction Connector90980-10803
J 9Junction Connector90980-1 1927J10Junction Connector90980-1 1927
J11Junction Connector90980-10803
J12Junction Connector90980-1 1927
J13Junction Connector90980-1 1925
J14Junction Connector90980-1 1927
J15Junction Connector90980-1 1925

L PART NUMBER OF CONNECTORS
Code Part Name Part NumberCodePart Name Part Number
Note : Not all of the above part numbers of the connector are established for the supply.
2004 LAND CRUISER (EWD548U)
408
J16Junction Connector90980-1 1915J17Junction Connector90980-1 1915
J18Junction Connector
J19Junction Connector90980-1 1661J20Junction Connector90980-1 1661
J21Junction Connector
J22Junction Connector
J23Junction Connector90980-1 1915J25Junction Connector90980-1 1915
J26Junction Connector
K 1Knock Sensor 190980-1 1166K 2Knock Sensor 290980-1 1166
K 3Key Interlock Solenoid90980-10825
L 1License Plate Light LH90980-1 1148L 2License Plate Light RH90980-1 1148
L 3Lumbar Support Control SW (Driver's Seat)90980-10601
M 1Mass Air Flow Meter90980-1 1317
M 2Moon Roof Control ECU90980-10997
M 3Moon Roof Control SW90980-10789
M 4Master Cylinder Pressure Sensor90980-1 1451
M 5Multi-Display90980-12203
M 6Multi-Display90980-12410
M 7Multi-Display90980-12012
M 9Multi-Display90980-12094
N 1Noise Filter (Ignition)90980-10843
N 2Navigation ECU90980-1 1973
N 3Navigation ECU90980-1 1923
N 4Navigation ECU90980-12221
O 2Oil Pressure Sender90980-1 1363
O 5Overhead J/B90980-12155
P 1Park/Neutral Position SW90980-1 1784
P 2Parking Light LH90980-1 1156P 3Parking Light RH90980-11156
P 4Power Outlet (Front)90980-10760
P 5Power Outlet (Rear Console Box)90980-10860
P 6Power Quarter Window SW LH90980-10797
P 7Power Quarter Window SW RH90980-10996
P 8Parking Brake SW90980-10871
P 9Power Outlet (Luggage Compartment)
P10Power Vent Window Motor LH90980-10860
P11Power Vent Window Motor RH
P12Power Window Master SW90980-12166
P14Power Window Motor Front LH
P15Power Window Motor Front RH90980-1 1599P16Power Window Motor Rear LH90980-11599
P17Power Window Motor Rear RH
P18Power Window Control SW Front RH
P19Power Window Control SW Rear LH90980-1 1947
P20Power Window Control SW Rear RH
P21Pretensioner LH90980-1 1862P22Pretensioner RH90980-1 1862
P23Power Seat Control SW (Driver's Seat)
P24Power Seat Control SW (Front Passenger's
Seat)90980-10803
P25Power Seat Motor (Driver's Seat Front
Vertical Control)
P26Power Seat Motor (Driver's Seat Lumbar
Support Control)
P27Power Seat Motor (Driver's Seat Rear
Vertical Control)
P28Power Seat Motor (Driver's Seat Reclining
Control)
P29Power Seat Motor (Driver's Seat Slide
Control)90980-10825
P30Power Seat Motor (Front Passenger's Seat
Front Vertical Control)
P31Power Seat Motor (Front Passenger's Seat
Rear Vertical Control)
P32Power Seat Motor (Front Passenger's Seat
Reclining Control)
P33Power Seat Motor (Front Passenger's Seat
Slide Control)
R 5Remote Control Mirror SW90980-1 1657
R 6Rheostat90980-10799
R 7Room Temp. Sensor (Front)90980-1 1918
R 8Rear A/C Control SW90980-1 1503
R 9Rear Air Mix Control Servo Motor90980-1 1319
R10Rear Combination Light LH90980-1 1587
R11Rear Combination Light LH90980-10908R12Rear Combination Light RH90980-10908
R13Rear Combination Light RH90980-1 1587
R14Rear Cooler Blower Motor90980-10214
R15Rear Cooler Magnetic Valve90980-10860
R16Rear Cooler Power Transistor90980-10171R17Rear Cooler Relay90980-10171
R19Rear Door Speaker LH90980-10935R20Rear Door Speaker RH90980-10935
R21Rear Evaporator Temp. Sensor90980-1 1918
R22Rear Heater Blower Motor90980-10860
R25Rear Heater Power Transistor90980-10171
R26Rear Inlet Air Temp. Sensor90980-1 1369
R27Rear Interior Light90980-10935
R28Rear Window Defogger90980-1 1097R29Rear Window Defogger90980-1 1097
R30Rear Wiper Motor90980-10795

L
CodePart Name Part NumberCodePart Name Part Number
2004 LAND CRUISER (EWD548U)
409
R31Rear Wiper Relay90980-10797
R32Remote Control Mirror LH90980-1 1573R33Remote Control Mirror RH90980-11573
R34Room Temp. Sensor (Rear)90980-1 1918
R36Radio and Player90980-12038
R37Radio and Player90980-12183
R38Radio and Player90980-12259
R39Rear Seat Audio Controller90980-12200
R40Roll Sensing of Curtain Shield Airbags
Cutoff SW90980-10957
S 1Starter90980-1 1400
S 2Starter90980-09585
S 3Seat Heater SW (Driver's Seat)90980-10797
S 4Seat Heater SW (Front Passenger's Seat)90980-10996
S 5Stop Light SW90980-1 1118
S 6Stereo Component Amplifier90980-10848
S 7Stereo Component Amplifier90980-10807
S 8Seat Belt Warning Occupant Detection
Sensor90980-10860
S 9Seat Heater (Driver's Seat)90980-10907S10Seat Heater (Front Passenger's Seat)90980-10907
S11Side Airbag Sensor Front LH
S12Side Airbag Sensor Front RH90980-12225S13Side Airbag Sensor Rear LH90980-12225
S14Side Airbag Sensor Rear RH
S15Seat Heater (Driver's Seat Cushion)
S16Seat Heater (Front Passenger's Seat
Cushion)90980-10794
S17Seat Position Sensor90980-12195
S18Side Airbag Squib LH90980-1 1864S19Side Airbag Squib RH90980-1 1864
T 1Theft Deterrent Horn90980-10619
T 4Telescopic Motor90980-10799
T 5Theft Deterrent ECU90980-12169
T 7Tilt and Telescopic ECU90980-10799
T 8Tilt and Telescopic ECU90980-10848
T 9Tilt Motor90980-10799
T10Ignition Key Cylinder Light90980-12092T10Transponder Key Amplifier90980-12092
T11Turn Signal Flasher90980-10799
T12Trailer Socket82824-34030
T13Tweeter LH90980-1 1300T14Tweeter RH90980-1 1300
T15Towing Converter Relay90980-1 1535
T16Throttle Control Motor and Sensor90980-1 1858
T17Turbine Speed Sensor90980-1 1156
T18Towing Brake Controller90980-1 1603
T19Transponder Key Computer90980-1 1911
T20Television Camera90980-12381
T21Television Camera ECU90980-12169
T22Television Camera ECU90980-10997
T23Towing Hitch Relay82660-20340
U 1Unlock Warning SW90980-10860
V 1Vapor Pressure Sensor90980-1 1143V 2Vehicle Speed Sensor (Combination Meter)90980-1 1143
V 3Vehicle Speed Sensor (Electronically
Controlled Transmission)
90980-1 1156
V 4VSV (EVAP)
90980 1 1156
V 6Vanity Light LH90980-1 1918V 7Vanity Light RH90980-1 1918
V 8VSC Warning Buzzer90980-10906
V 9VSV (Canister Closed Valve)90980-1 1162
V10VSV (Pressure Switching Valve)90980-1 1859
W 1Washer Motor90980-1 1294
W 4Woofer (Speaker)90980-10795
Y 1Yaw Rate Sensor90980-12080
Z 1Option Connector (Glass Breakage Sensor)90980-10825

2004 LAND CRUISER (EWD548U)
388J POWER SOURCE (Current Flow Chart)
FuseSystemPage
10AECU-B1
Multi-Display (w/o Navigation System)
Navigation System and TOYOTA Parking Assist
(Rear View Monitor)348
336
10AECU-IG1
Automatic Glare-Resistant EC Mirror with Compass
Automatic Light Control
Door Lock Control
Headlight
Interior Light
Key Reminder
Light Auto Turn Off
Moon Roof
Multi-Display (w/o Navigation System)
Multiplex Communication System
Navigation System and TOYOTA Parking Assist
(Rear View Monitor)
Power Window
Shift Lock
Theft Deterrent
VSC
Wireless Door Lock Control304
164
260
128
148
316
166
256
348
172
336
250
244
282
228
270
10AEFI OR ECD NO.2Engine Control108
10AGAUGE1
Air Conditioning (Front)
Center Differential Lock
Combination Meter
Cruise Control
Electronically Controlled Transmission and A/T Indicator
Engine Control
Illumination
Key Reminder
Multiplex Communication System
Navigation System and TOYOTA Parking Assist
(Rear View Monitor)
Power Rear Quarter Window
Seat Belt Warning356
246
350
222
212
108
142
316
172
336
306
320
15AA/C
Air Conditioning (Front)
Air Conditioning (Rear)
Seat Belt Warning356
366
320
15ACIGCigarette Lighter204
15APWR OUTLETPower Outlet206
15ARR WIPERRear Wiper and Washer200
15ASTOP
Cruise Control
Electronically Controlled Transmission and A/T Indicator
Engine Control
Multiplex Communication System222
212
108
172
*These are the page numbers of the first page on which the related system is shown.

2004 LAND CRUISER (EWD548U)
391J
FuseSystemPage
10ARADIO
Auto Antenna
Navigation System and TOYOTA Parking Assist
(Rear View Monitor)
Radio and Player (w/ Navigation System)
Radio and Player (w/o Navigation System)322
336
324
330
15ASEAT HTRSeat Heater308
15AWASHERFront Wiper and Washer
Rear Wiper and Washer196
200
20ADIFFCenter Differential Lock246
20AP/W (FL)
Door Lock Control
Interior Light
Multiplex Communication System
Power Window
Theft Deterrent
Wireless Door Lock Control260
148
172
250
282
270
20AP/W (FR)Multiplex Communication System
Power Window172
250
20AP/W (RL)Multiplex Communication System
Power Window172
250
20AP/W (RR)Multiplex Communication System
Power Window172
250
20ATIL & TELPower Tilt and Power Telescopic298
25AWIPERFront Wiper and Washer196
30ARH SEATPower Seat294
30ARR A/CAir Conditioning (Rear)366
Fusible Link Block (F15, F16, F17, F18, F19 on See Page 68)
FuseSystemPage
50AHTRAir Conditioning (Front)356
120AJ/B NO.1
Automatic Light Control
Illumination
Light Auto Turn Off
Multiplex Communication System
Taillight
Theft Deterrent164
142
166
172
138
282
120AJ/B NO.2
Air Conditioning (Rear)
Engine Control
Mirror Heater
Rear Window Defogger
Shift Lock366
108
314
312
244
120AJ/B NO.3Engine Control108
120AMAIN
Ignition
Multiplex Communication System
Starting100
172
98
*These are the page numbers of the first page on which the related system is shown.

2004 LAND CRUISER (EWD548U)
95
2C115A STOP7. 5A AM1
5
13
2
1
52
32E40 2E37
IFIG1 NO. 2
Relay
15A A/C
ACC Relay 30A LH SEAT
10A ECU- B1
25A SUN ROOF
7. 5A OBD- 2
25A DOOR
20A DEFOG
30A BATT CHARGE10A GAUGE1 10A ECU- IG1 15A RR WIPER
7. 5A IDLE UP
15A PWR OUTLET
15A CIG
7. 5A ACC2E39
2E41
2A10
DEFOG Relay
2B3 2A5
10A EFI OR ECD NO. 2
2Q77
L- B
B- GB- Y W- RL- O
B- G B- GW- R
L- BB- R
SB
L- B W- RL- O B- G
B- R 54
23
1

2004 LAND CRUISER (EWD548U)
96Power Source
I183C1
7. 5A SECURITY
20A TIL & TEL
30A RH SEAT20A P/W (
RR)
30A RR A/C20A P/W (
RL)
20A P/W (
FR)
20A P/W (
FL)
1 3
2 520A DIFF 10A RADIO
10A ECU- B2
10A DOME 3B25
3E4
7. 5A IGN
7. 5A MET 2
73
4
6
8 AM2 AM1ACC
IG1
IG2
ST2 B- WL- BBIG1 NO. 3 Relay B- G
10A ECU- IG2
15A WASHER
25A WIPER
10A GAUGE2
15A SEAT HTR
AA
J 4ACC CUT Relay
1 3
2 4
6B 46D 33Q50
II 3Q39
B- RL- BSB B- R W- RL- O B- G
W- RB- R
B- R
BSB
IX1 4 IX1 3
56B6D 2
B- R
B- R3Q52
SB SB
SB
Igni tion SWJunction
Connector 67A7A 5
B

2004 LAND CRUISER (EWD548U)
196Front Wiper and Washer
25A
WIPER From Power Source System (
See Page 94)
3A 7Front Wiper SW Front Washer SW
EW WF
ON OFF B1 +S INT2INT1
HI+1 +2 +B
LO INT OFF
17 8 7 16 11 2+B +2 +1 +S WF EW
II3 3 II3 35 II3 34 II3 32 II3 33
M
II 3E 35A
AJ 3 3G 8 3G 4 3G 12
3A 13 3A10 3A15
4123
+2 +1 B S
5 E
EB
W- B
W- B W- B W- BL- YL- WL- B L- RL
L- WL- B L- RL
3G 11
2D 38
2A 1 1A 56
1B 683 2EA2 215A
WASHER
3A 9
L- Y L- WL- B L- RL L L- Y L- YL L
LW 1
F 5 C19
Combination SW
Front Wiper Motor
Washer Motor
Junction
Connector II3 31
L- Y
M
